GAI-Tronics MDC-1200 Manuel utilisateur
Pub. 43003-040A
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
VISIT WWW.GAI-TRONICS.COM FOR PRODUCT LITERATURE AND MANUALS
GAI-TRONICS® CORPORATION
A HUBBELL COMPANY
Model TDN9413A
Stat-Alert Signaling Module Kit
Field Installation Kit Instructions
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains
sensitive business and technical information that is confidential and proprietary to GAI-Tronics.
GAI-Tronics retains all intellectual property and other rights in or to the information contained herein,
and such information may only be used in connection with the operation of your GAI-Tronics product or
system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any
third party.
General Information
The Model TDN9413A Stat-Alert Signaling Module Kit is intended for upgrading existing dispatch
consoles manufactured by GAI-Tronics or for replacement of existing Stat-Alert modules. This kit
includes the following components:
Qty Description
1 MDC-1200 Interface Module
1 Module mounting bracket
1 lot Hardware and labels
Installation
Desktop Console
1. Disconnect power from the Desktop Console and remove all attached cables from the rear cover.
2. Remove the four screws securing the rear panel. Gently pull the rear cover from the housing and
disconnect the ribbon cables (SLV-CBL-P) attached to the surge suppression PCBA. Lay the rear
panel flat. See Figure 1.
Pub. 43003-040A
Model TDN9413A Stat-Alert Signaling Module Kit Page: 2 of 3
\\s_eng\gtcproddocs\radio products-current release\43003\43003-040a\43003-040a.doc
05/05
Figure 1.
3. Remove the seven screws securing the top panel and gently lift the cover exposing the attached
speaker cable and master display cable. See Figure 2.
Figure 2.
4. Disconnect the speaker cable at the male-to-female connection point. Unplug the master display
cable from the top cover.
Pub. 43003-040A
Model TDN9413A Stat-Alert Signaling Module Kit Page: 3 of 3
\\s_eng\gtcproddocs\radio products-current release\43003\43003-040a\43003-040a.doc
05/05
5. Remove the four screws attaching the mounting plate to the base. This allows you to remove the
mounting plate giving access to the main control PCBA. See Figure 2.
6. Disconnect all of the cables from the main PCBA.
7. Remove the nine screws holding the main PCBA to the base. See Figure 3.
Figure 3.
8. Lift the main PCBA out of the main enclosure. Then, attach the Stat-Alert module to the main PCBA
using the hardware provided with the kit. See Figure 3.
9. After the Stat-Alert is attached, you can reassemble the desktop console by reversing the disassembly
procedure. Verify that all of the cables have been reconnected back to their respective connectors as
you proceed through the steps.
10. Stat-Alert signaling must be programmed with Card Suite Programming Software, using the
XCP0170A Programming Cable. Refer to the Card Suite application’s Digital Signaling tabs (unit
archive) for console, channel, and station/message alias programming.
11. Install button function label to lower left-hand corner of the front panel if buttons are not already
labeled.
