FunkTronic LIM-AC Manuel utilisateur
Line Interface
Modul AC
LIM-AC
- 2 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
- 3 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
Inhaltsverzeichnis
Begriffe und Abkürzungen 2
Technische Daten 2
Allgemeine Eigenschaften 3
Anschaltbeispiele Major 4a (5a), AC-gekoppelt 3
Steckerbelegung LIM-AC 4
Blockschaltplan 4
Abgleichanweisung 5
Programmieranweisung 6
Registerbelegung EEPROM LIM-AC 6
NF-Schwellwerte für die Register 00 und 01 7
Bestellinformationen 7
Allgemeine Sicherheitshinweise 8
Rücknahme von Altgeräten 8
Seite
Terms and Shortcuts
LIM-AC Line Interface Modul AC
Line 2-Wire Connection
Radio 2-Way Radio Base Station
ZR Reference Termination Impedance,
equivalent to a real 2-Wire Connection according to german TBR 15
Technical Data
Power Supply
Voltage +12 V DC +/- 30%
Current consumption 25 mA
AF-Input Level
Factory default 500 mV
Input impedance 600 Ohm
AF-Output Level
Factory default 500 mV
Adjustment range - 24 dBm to - 5 dBm
Input Level Line
Factory default - 8 dBm ( 500 mV at AF-Output)
Input impedance ZR
Output Level Line
Factory default - 6 dBm, AF (500 mV at AF-Input) plus pilot tone
Output impedance ZR
Weight 77 g
Dimensions (with flange) 100 x 32 x 75 mm
- 2 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
- 3 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
The LIM-AC (Line Interface Modul AC) connects a 2 way radio station to its operator device via lea-
sed line. It is certicated according to german TBR 15 and for this can be connected to private and
public/leased lines.
The 2 wire connection is plugged into the connector Line. The operator device is connected to the
plug named Major. The connection LIM-AC to the Major operator device is established through a one
-to-one cable. Standard network patch cords can be used.
On the opposit side the devices FT634a, FT634aC or FT633AC can be used.
All operator devices of the Major series (e.g. Major 4a, 5a, 6) can be directly connected to the LIM-
AC.
Exception:
The Major BOS 4 and Major BOS 8 feature a busy line instead of the 12V power supply on the 8 pole
plug. In this case the LIM-AC has to be powered via the separate power supply plug.
Common Characteristics
2
LIM AC incl.
notch lter
option
LIM AC incl.
notch lter option
2
LIM-AC (2 wire) FT634aC (with channel switching) or
FT633AC (with channel switching) or
FT634a (without channel switchong)
Parallel operation of multiple operator devices --> LIM AC requires notch lter option for pilot tone
2
2
FT624
FT634aC (with channel switching) or
FT633AC (with channel switching) or
FT634a (without channel switchong)
Examples Major 4a (5a), AC coupled
- 4 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
- 5 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
Connector Layout LIM-AC
Pin Layout Radio circuit ST1,
GND 1
AF-Output 2
Squelch-Output 3
GND 4
+12 V 5
PTT, active low 6
AF-Input 7
GND 8
Pin Layout Line ST2
nc 1
nc 2
a 3
b 4
2-wire connection
nc = not connected
Operator Device
Block Diagram
Power Supply
12 Volt
Tip Plus pole
Ring Ground
500 mV <==
500 mV ==>
<--
-->
-->
- 4 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
- 5 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
Adjustment
Optional notch lter, plugged in on multiple
operator devices in parallel operation.
ST3/GND
RS232/TTL
P1
AF-TX
P2
AF-RX
ST5/Pin 1
Jumper
P1 (AF-TX)
P1 sets the level of the pilot tone. The required AF level has to be set within the operator device.
The factory default of P1 is set to the max. permitted level according to TBR 15.
Pilot tone without AF --> - 10 dBm on line
AF Input 500 mV --> - 8 dBm on line
AF plus pilot tone --> - 6 dBm on line
P2 (AF-RX)
Feed line / 2 wire connection with required level and set AF-Output to 500 mV.
Remark:
In public communication networks it is mandatory to terminate the line with the reference terminating
impedance of Zr while sending or receiving. Because of this the FT624 has to be used to connect
multiple LIM-AC in parallel. This causes a higher insertion loss.
Please consider the programming capabilities of pilot tone and relais.
TXD
RXD
- 6 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
- 7 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
Programming Guide
Register Function
00 Vref for Squelch detection leveö (Factory default --> 0x0A = 280 mV)
01 Vref for Squelch turn off level (Factory --> 0x06 = 140 mV)
02 Number of consecutive slopes onf start of Squelch
A break of 3.6 ms without slope resets the counter
Fectory default --> 0x05 = 6 slopes without break longer than 3,6 ms is detected as
Squelch
03 Follow-up time for Squelch detection x 10 ms
Factory default --> 0x50 = 50 x 10 ms = 500 ms
04 Locking time past PTT for Squelch detection x 10 ms
Factory default --> 0x10 = 10 x 10 ms = 100 ms
05 TX-Mode Low-Nibble --> Pilotton bei TX 1 = an, 0 = aus
High-Nibble --> Relais bei TX
0 = TX-Relais on for TX, RX-Relais on for RX
1 = TX-Relais always on, RX-Relais on for RX - default
2 = TX-Relais an bei TX, RX-Relais immer an
3 = TX-Relais immer an, RX-Relais immer an
Factory default --> 0x11 = Relais and pilot tone on for TX
Register description EEPROM LIM-AC
Connect the plug ST3 of the LIM-AC to the serial interface of the PC via adapter TTL/RS232 (e.g.
FunkTronic RS232AD1). Start a perminal emulation prgramm (e.g. Hyperterminal, minicom). The
settings are 9600 baud, 8 data bits, no parity, one stopp bit and no ow control protocol.
Hit the ENTER key and you will receive the following display message:
LIM_AC (C) FunkTronic 02-03
Software: `LIM_AC` V1.1 vom 24.09.03
Pilotton: 3300 Hz
Rxx Read EEPROM Register xx
Pxx yy Program yy in EEPROM Register xx
X Reset
If you enter R followed by a two digit register number and a nal ENTER the setting of the correspon-
ding register will be displayed.
Programming a register works the same way but with the P button instead of R.
Enter P followed by the two digit register number followed by the register value and the nal ENTER
key.
Input of X resets the unit.
- 6 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
- 7 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
Register ca . AF level/mV
Value
00 1,0
01 20
02 45
03 60
04 95
05 125
06 140
07 160
08 185
09 230
0A 280
0B 325
0C 370
0D 415
0E 465
0F no Squelch detection
AF level for the registers 00 snd 01
Ordering Information
Part No. Description
692500 Line Interface Module AC, LIM-AC
901200 Option notch lter 3300 Hz
- 8 - lim-ac (01.11.2006)
Kompetent für Elektroniksysteme
Please read the operating instructions carefully before installation and setup.
The relevant regulations must be complied to when working with 230V line voltage, two-wire-
lines, four-wire-lines and ISDN-lines. It is also very important to comply to the regulations
and safety instructions of working with radio installations.
Please comply to the following safety rules:
- All components may only be mounted and maintained when power is off.
- The modules may only be activated if they are built in a housing and are
scoop-proof.
- Devices which are operated with external voltage - especially mains voltage -
may only be opened when they have been disconnected from the voltage source
or mains.
- All connecting cables of the electronic devices must be checked for damage
regularly and must be exchanged if damaged.
- Absolutely comply to the regular inspections required by law
according to VDE 0701 and 0702 for line-operated devices.
- Tools must not be used near or directly at concealed or visible power lines
and conductor paths and also not at and in devices using external voltage –
especially mains voltage - as long as the power supply voltage has not been
turned off and all capacitors have been discharged. Electrolytic capacitors
can be still charged for a long time after turning off.
- When using components, modules, devices or circuits and equipment the
threshold values of voltage, current and power consumption specified in the
technical data must absolutely be complied to. Exceeding these threshold
values (even if only briefly) can lead to significant damage.
- The devices, components or circuits described in this manual are only
adapted for the specified usage. If you are not sure about the purpose of the
product, please ask your specialized dealer.
- The installation and setup have to be carried out by professional personnel.
Factory returning of old equipment
According to German law concerning electronic devices old devices cannot be disposed off
as regular waste. Our devices are classified for commercial use only. According to § 11 of
our general terms of payment and delivery, as of November 2005, the purchasers or users
are obliged to return old equipment produced by us free of cost. FunkTronic GmbH will
dispose of this old equipment at its own expense according to regulations.
Please send old equipment for disposal to: FunkTronic GmbH
Breitwiesenstraße 4
36381 Schlüchtern
>>> Important hint: freight forward deliveries cannot be accepted by us.
February 2nd , 2006
Subject to change, Errors excepted
General Safety Instructions
