Options Guide - English

PRIMERGY BX924 S2

Server Blade

Options Guide

March 2011

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]ujitsu.com.

Certified documentation

according to DIN EN ISO 9001:2008

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2008.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

– The contents of this manual may be revised without prior notice.

– Fujitsu assumes no liability for damages to third party copyrights or other

rights arising from the use of any information in this manual.

– No part of this manual may be reproduced in any without the prior written

permission of Fujitsu.

Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of

Microsoft Corporation in the USA and other countries.

Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the USA and other countries.

BX924 S2 Options Guide

Before reading this manual

For your safety

This manual contains important information for safely and correctly using this

product.

Carefully read the manual before using this product. Pay particular attention to

the accompanying manual "Safety Notes and Regulations" and ensure these

safety notes are understood before using the product. Keep this manual and the

manual "Safety Notes and Regulations" in a safe place for easy reference while

using this product.

Radio interference

This product is a "Class A" ITE (Information Technology Equipment). In a

domestic environment this product may cause radio interference, in which case

the user may be required to take appropriate measures. VCCI-A

Aluminum electrolytic capacitors

The aluminum electrolytic capacitors used in the product's printed circuit board

assemblies and in the mouse and keyboard are limited-life components. Use of

these components beyond their operating life may result in electrolyte leakage

or depletion, potentially causing emission of foul odor or smoke.

As a guideline, in a normal office environment (25°C) operating life is not

expected to be reached within the maintenance support period (5 years).

However, operating life may be reached more quickly if, for example, the product

is used in a hot environment. The customer shall bear the cost of replacing

replaceable components which have exceeded their operating life. Note that

these are only guidelines, and do not constitute a guarantee of trouble-free

operation during the maintenance support period.

High safety use

This product has been designed and manufactured for general uses such as

general office use, personal use, domestic use and normal industrial use. It has

not been designed or manufactured for uses which demand an extremely high

level of safety and carry a direct and serious risk to life or body if such safety

cannot be ensured.

OptionsGuide BX924 S2

These uses include control of nuclear reactions in nuclear power plants,

automatic airplane flight control, air traffic control, traffic control in mass

transport systems, medical devices for life support, and missile guidance control

in weapons systems (hereafter, "high safety use"). Customers should not use

this product for high safety use unless measures are in place for ensuring the

level of safety demanded of such use. Please consult the sales staff of Fujitsu if

intending to use this product for high safety use.

Measures against momentary voltage drop

This product may be affected by a momentary voltage drop in the power supply

caused by lightning. To prevent a momentary voltage drop, use of an AC

uninterruptible power supply is recommended.

(This notice follows the guidelines of Voltage Dip Immunity of Personal

Computer issued by JEITA, the Japan Electronics and Information Technology

Industries Association.)

Technology controlled by the Foreign Exchange and Foreign Trade

Control Law of Japan

Documents produced by Fujitsu may contain technology controlled by the

Foreign Exchange and Foreign Trade Control Law of Japan. Documents which

contain such technology should not be exported from Japan or transferred to

non-residents of Japan without first obtaining authorization in accordance with

the above law.

Harmonic Current Standards

This product conforms to harmonic current standard JIS C 61000-3-2.

Only for the Japanese market:

About SATA hard disk drives

The SATA version of this server supports hard disk drives with SATA / BC-SATA

storage interfaces. Please note that the usage and operation conditions differ

depending on the type of hard disk drive used.

Please refer to the following internet address for further information on the

usage and operation conditions of each available type of hard disk drive:

http://primeserver.fujitsu.com/primergy/harddisk/

BX924 S2 Options Guide

Only for the Japanese market:

IAlthough described in this manual, some sections do not apply to the

Japanese market. These options and routines include:

– USB Flash Module (UFM)

– CSS (Customer Self Service)

OptionsGuide BX924 S2

BX924 S2 Options Guide

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 9

1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 9

1.3 Extensions and conversions . . . . . . . . . . . . . . . . . 11

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 12

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 15

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1 Opening the server blade . . . . . . . . . . . . . . . . . . . 19

5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 23

5.1 Expanding/replacing main memory . . . . . . . . . . . . . . 25

6 Mezzanine cards . . . . . . . . . . . . . . . . . . . . . . . . 27

6.1 Population rules for mezzanine cards . . . . . . . . . . . . 28

6.2 Installing mezzanine cards . . . . . . . . . . . . . . . . . . 36

7 Trusted Platform Module (TPM) . . . . . . . . . . . . . . . . 41

7.1 Installing a TPM . . . . . . . . . . . . . . . . . . . . . . . . 41

8 USB Flash Module (UFM) . . . . . . . . . . . . . . . . . . . 45

OptionsGuide BX924 S2

Contents

8.1 Installing an UFM . . . . . . . . . . . . . . . . . . . . . . . . 45

9 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

9.1 Closing the server blade . . . . . . . . . . . . . . . . . . . . 49

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

BX924 S2 Options Guide 9

1 Preface

The PRIMERGY BX924 S2 server blade is an Intel-based dual-socket server

blade. It is ideal for use in data centers belonging to enterprises or Internet

service providers, and makes an excellent large application server, terminal

server for compute-intensive applications or DBMS server.

1.1 Concept and target groups

This Options Guide shows you how to extend and upgrade your server.

VCAUTION!

The activities described in this manual may only be performed by

technical specialists.

IThe installation and removal of the hot-plug components is described in

the Operating Manual supplied with the server.

1.2 Documentation overview

IPRIMERGY manuals are available in PDF format on the

ServerView Suite DVD 2. The ServerView Suite DVD 2 is part of the

ServerView Suite supplied with every server.

If you no longer have the ServerView Suite DVDs, you can obtain the

relevant current versions using the order number U15000-C289 (the

order number for the Japanese market: please refer to the configurator

of the server http://primeserver.fujitsu.com/primergy/system.html).

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL (for EMEA market):

http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can

be accessed using the Industry standard servers navigation option.

For the Japanese market please use the URL:

http://primeserver.fujitsu.com/primergy/manual.html.

More information on your PRIMERGY BX924 S2 can be found in the following

documents:

10 OptionsGuide BX924 S2

Preface

– "Quick Start Software - Quick Installation Guide" DVD booklet

(only included with the ServerView Suite as a printed copy) except for the

Japanese market

– "Safety Notes and Regulations" manual

"安全上のご注意 " for the Japanese market

– "Warranty" manual

"保証書 " for the Japanese market

– "ServerView Suite Local Service Concept - LSC" manual

– "Returning used devices" manual and "Service Desk" leaflet

"サポート＆サービス " for the Japanese market

– "PRIMERGY BX924 S2 Server Operating Manual"

– "PRIMERGY BX924 S2 Server Options Guide"

– "System Board D2952 for PRIMERGY BX924 S2 Technical Manual"

Further sources of information:

– PRIMERGY Abbreviations and Glossary on the ServerView Suite DVD 2

– Manual for the monitor

– Documentation for the boards and drives

– Operating system documentation

– Information files in your operating system
