PRIMERGY BX620 S4

2-way Server Blade

Options Guide

Edition May 2007

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected].

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

BX620 S4 Options Guide

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Documentation Overview . . . . . . . . . . . . . . . . . . . . 5

1.2 Extensions and Conversions . . . . . . . . . . . . . . . . . . 7

1.3 Structure of the Server Blade . . . . . . . . . . . . . . . . . . 8

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 10

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3 Notes on Safety . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

4.1 Opening the Server Blade . . . . . . . . . . . . . . . . . . . 17

5 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

5.1 Installing a Second Processor . . . . . . . . . . . . . . . . . 21

6 Main Memory . . . . . . . . . . . . . . . . . . . . . . . . . . 29

6.1 Fitting Rules . . . . . . . . . . . . . . . . . . . . . . . . . . 30

6.2 Upgrading / Exchanging Main Memory . . . . . . . . . . . . 32

7 Optional I/O Module . . . . . . . . . . . . . . . . . . . . . . 35

7.1 Installing an I/O Daughter Card . . . . . . . . . . . . . . . . 40

OptionsGuide BX620 S4

Contents

8 Storage Modules . . . . . . . . . . . . . . . . . . . . . . . . . 43

8.1 Storage Module Variants . . . . . . . . . . . . . . . . . . . . 44

8.2 Replacing a Storage Module . . . . . . . . . . . . . . . . . . 51

9 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

9.1 Closing the Server Blade . . . . . . . . . . . . . . . . . . . . 53

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

BX620 S4 Options Guide 5

1 Preface

The PRIMERGY BX620 S4 2-way Server Blade is an Intel-based server blade

with outstanding network qualities. Combined with Gbit Ethernet LAN SB9F

switch blades, it offers LAN connections via 6 onboard Ethernet channels in the

BX600 S3 basic unit. The server blade can also be operated in the BX600 S2

basic unit, in which case, however, only 2 of the 6 onboard Ethernet channels

of the server blade can be used.

The PRIMERGY BX620 S4 server blade offers several new forward-looking

technologies such as dual-core processors, FBD memory modules with

extended mirroring, modular hard disk controller configuration and 2.5-inch SAS

or SATA hard disks.

1.1 Documentation Overview

IPRIMERGY manuals are available in PDF format on the ServerBooks

DVD. The ServerBooks DVD is part of the ServerStart Suite supplied with

every server.

The PDF files of the manuals can also be downloaded free of charge

from the Internet. The overview page showing the online documentation

available on the Internet can be found using the URL:

http://manuals.fujitsu-siemens.com. The PRIMERGY server documentation

can be accessed using the Industry standard servers navigation option.

Concept and target groups

This Options Guide shows you how to extend and upgrade your server.

VCAUTION!

The activities described in this manual may only be performed by

technical specialists.

IThe installation and removal of the hot-plug components is described in

the Operating Manual supplied with the server.

6 OptionsGuide BX620 S4

Documentation Overview Preface

Additional Documentation About the Server

The PRIMERGY BX620 S4 documentation comprises the following additional

documents:

– „Quick Start Software - PRIMERGY ServerView Suite“ (leaflet)

– The “Guarantee” manual (print version supplied with the system; PDF file

available on the ServerBooks DVD supplied)

– The “Safety notes and other important information” manual (print version

supplied with the system; PDF file available on the ServerBooks DVD

supplied)

– The “Ergonomics” manual (PDF file available on the ServerBooks DVD

supplied)

– “Returning used devices” (PDF file available on the ServerBooks DVD

supplied)

– “Helpdesk” (leaflet with worldwide helpdesk telephone numbers)

– “BIOS Setup” (PDF file available on the ServerBooks DVD supplied)

– “PRIMERGY BX620 S4 Server Blade Operating Manual” (PDF file available

on the ServerBooks DVD supplied)

– The “ServerView Suite” contains the ServerStart CD and the ServerBooks DVD

as well as the printed version of the “PRIMERGY ServerView Suite - Server-

Start” manual. The manual is also available as a PDF file on the ServerBooks

DVD.

IYou can order an additional copy of the ServerBooks DVD by sending

an e-mail to the following address, quoting your server data: Reklamat-

[email protected]

Further sources of information:

– Technical Manual for the relevant rack

– Manual for the monitor

– Manual on ServerView Server Management

– Manual on the RemoteView Remote Test and Diagnostics System

– Documentation for boards and drives

– Documentation for your operating system

– Information files on your operating system

(See also chapter “Related publications” on page 59)

BX620 S4 Options Guide 7

Preface Extensions and Conversions

1.2 Extensions and Conversions

Second Processor

If only one processor is installed in your server blade, you can upgrade it to

include a second one. You may only use processors of the same type in the

server blade. The second processor must have the same clock frequency as the

first.

Extension of the Main Memory

The main memory sockets are suitable for "Fully Buffered DIMM" (FBD) 533-

MHz memory modules. Memory modules must be installed in pairs. The two

memory modules of one bank must always have the same capacity.

Optional I/O Modules

The server blade has one slot for an extension board (daughter card) which can

be used to provide two Fibre Channel (FC) connections or two additional

Ethernet connections. The following I/O modules are available:

– 2 Gbit Fibre Channel daughter card (PCI-X)

– 4 Gbit Fibre Channel daughter card (PCIe)

– 1 Gbit Ethernet daughter card (PCIe)

– 10 Gbit Ethernet daughter card (PCIe)

To be able to use the additional I/O functionality, at least one Fibre Channel or

Ethernet I/O blade must be installed in the NET3 and/or NET4 slots of the

BX600 basic unit. For further information on I/O blades, see the operating

manual for your BX600 basic unit (see “Related publications” on page 59).

Storage Modules

The hard disks are controlled by a storage module (controller) that can be

plugged into the motherboard and which may also have additional functions.

SATA only offers one storage module variant, while SAS offers a total of four

different variants: SAS, SAS/RAID, SAS/PCI-X and SAS/PCIe. The two PCI

variants allow the installation of low-profile PCI modules.

Storage modules can be installed/replaced via the front of the server blade

without having to take off the housing cover. However, they cannot be replaced

while the system is running (non-hot-plug) - the server blade must be switched

off.

8 OptionsGuide BX620 S4

Structure of the Server Blade Preface

1.3 Structure of the Server Blade

Figure 1: PRIMERGY BX620 S4 server blade

figure 1 shows the positions of the most important components of the BX620 S4

2-way server blade.

BX620 S4 Options Guide 9

Preface Structure of the Server Blade

IThe memory modules, the I/O daughter card and the storage module

must be installed in the server blade before it is placed in the basic unit.

DIP Switch Settings

The server blade comes with the DIP switches set in the following positions:

1 Sockets for FBD memory modules

2 Heat sink of the first processor

3 Control panel board with foil cable

4 2.5-inch hard disk module 1 (SAS or SATA)

5 2.5-inch hard disk module 2 (SAS or SATA)

6 Storage module

7 Socket for second processor

8 Dummy heat sink

9 I/O daughter card (Fibre Channel or Gigabit Ethernet), optional

10 Lithium battery (on the system board)

11 DIP switch (on the system board)

Switch Function Default

1 Delete password OFF

2 Clear CMOS memory OFF

3 Restore system BIOS OFF

4 Not assigned OFF

5 Switch for keyboard/mouse controller ON

6 Not assigned

Table 1: Preset DIP switches

10 OptionsGuide BX620 S4

Notational conventions Preface

The switch settings have the following meanings:

1.4 Notational conventions

The following notational conventions are used in this manual:

Switch 1 ON Delete password enabled

OFF Delete password disabled

Switch 2 ON Clear CMOS memory enabled

OFF Clear CMOS memory disabled

Switch 3 ON Restore system BIOS enabled

OFF Restore system BIOS disabled

Switch 4 ON Top block swap enabled

OFF Top block swap disabled

Switch 5 ON Keyboard/mouse controller cannot be programmed

(normal operation)

OFF Keyboard/mouse controller can be programmed

Switch 6 ON Not assigned

OFF Not assigned

Text in italics indicates commands, menu items or software programs.

„Quotation marks“ indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,

destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips.

Autres manuels pour PRIMERGY BX620 S4

Table des matières

Autres manuels Fujitsu Serveur

Fujitsu

Fujitsu S140 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX1310 M3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX1320 M3 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX200 S6 Manuel du propriétaire

Fujitsu

Fujitsu PRIMERGY TX1320 M4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY S60 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX200 S2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX140 S1 Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 3800E2 Manuel utilisateur

Fujitsu

Fujitsu SPARC Enterprise T5140 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY 10/40GbE Connection Blade 18/8+2 Manuel de la liste des pièces

Fujitsu

Fujitsu PRIMERGY RX200 S2 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX200 S3 Manuel du propriétaire

Fujitsu

Fujitsu PRIMERGY TX600 S3 Manuel du propriétaire

Fujitsu

Fujitsu CELVIN NAS QE807 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY RX900 S2 Manuel utilisateur

Fujitsu

Fujitsu Primergy RX100 S5 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY TX300 S3 Manuel du propriétaire

Fujitsu

Fujitsu SPARC Enterprise T5140 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY BX620 S4 Manuel utilisateur

Fujitsu

Fujitsu PRIMERGY ServerView Suite Manuel utilisateur

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Instructions de montage

Fujitsu

Fujitsu PRIMERGY BX900 S1 Manuel du propriétaire

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
