Thank you for purchasing the fi-4860C Duplex Color Scanner.

The fi-4860C is an image scanner designed to scan various documents in large

quantities. FUJITSU fi series image scanners are known for high reliability and this

scanner is no exceptions. The fi-4860C is designed to give you the best results for

your scanning need.

The fi-4860C has the following features.

High speed, high quality color scanning capabilities

Scans documents of Letter/A4 size at the speed of 60ppm/120ipm

@200dpi.

Highly reliable document handling

Accepts various thicknesses, sizes and types of documents.

Production ready

High capacity hopper 500 sheets of 20 lb or 80 g/m2Letter/A4 size and

imprinter options. Duplex capability is available as standard feature.

About this manual

The manual provides the following information.

1. BASIC OPERATIONS

This chapter describes basic scanner operations and basic document

scanning.

2. SCANNING DOCUMENTS

This chapter describes how to scan various type of documents.

3. DAILY CARE

This chapter describes how to clean the scanner.

4. REPLACING CONSUMABLES

This chapter describes how to replace scanner consumables.

INTRODUCTION

5. SOLVING COMMON PROBLEMS

This chapter describes how to remedy document jams, other trouble,

and items to check before contacting the agent where you bought the

scanner, and how to check device labels.

6. ADF DOCUMENT SPECIFICATIONS

This chapter describes documents that can be used with this scanner.

7. OPERATOR PANEL MENUS

This chapter describes Setup-mode and Test-mode.

8. OPTIONS

This chapter describes the options available for this product.

9. SCANNER SPECIFICATIONS

This chapter lists the scanner specifications.

The “Installation Guide” is attached to this Scanner.

This guide contains necessary information for the scanner and the driver

installation, please also read the Installation Guide.

1. SCANNER BASICS

This chapter describes how to prepare the scanner for use.

2. INSTALLATION AND CONNECTIONS

This chapter describes how to install and connect the scanner, and how

to install the scanner application.

We hope that this manual is useful in taking full advantage of the fi-4860C Duplex

Color Scanner's features.

■ Regulatory Information

FCC Regulations

This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

xReorient or relocate the receiving antenna.

xIncrease the separation between the equipment and receiver.

xConnect the equipment into an outlet on a circuit different from that to which the

receiver is located.

xConsult your deealer or an expeerienced radio/TV technician.

FCC warning: Changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate the

equipment.

Canadian DOC Regulations

This digital apparatus does not exceed the Class A limit for radio noise emissions

from digital apparatus set out in the Radio interference Regulations of the Canadian

Department of Communications.

This Class A digital apparatus complies with Canadian ICES-003.

ATTENTION

xThe use of a shielded interface cable is required to comply

with the Class A limits of Part 15 of FCC rules. The length of

the SCSI interface cable must be 1.5 meters (5 feet) or less.

xThe length of the AC cable must be 3 meters (10 feet) or

less.

Le pésent appareil numérique n’ément pas de bruits radioélectriques dépassant les

limites applicables aux appareils numériques de la classe A prescridtes dans le

Réglesment sur le brouillage radioélectrique dicté par le ministere des

Communications du Canada.

Cet appareil numérique de la classe A est conformme à la norme NMB-003 du

Canada.

Bescheinigung des Herstellers / Importeurs

Hiermit wird bescheinigt, daß der/die/das

fi-4860C

xIn Übereinsstimmung mit den Bestimmungen der AmtsblVfg 243/1991

funkentstört ist.

xDer Deutschen Bundesport wurde das Inverkehrbringen dieses Gerätes angezeigt

und die Berechtigung zur Überprüfung der Serie auf Einhaltung der

Bestimmungen eingeräumt.

xMaschinenlärminformationsverordnung 3. GS GV, 18.01.1991:Der höchste

Schalldruckpegel beträgt 70 dB (A) order weniger gemäß ISO/7779.

International ENERGY STAR® Program

As an ENERGY STAR® Partner, PFU LIMITED has determined

that this product meets the ENERGY STAR® guidelines for energy

efficiency.

The International ENERGY STAR® Office Equipment Program is

an international program that promotes energy saving through the penetration of

energy efficient computers and other office equipment. The program backs the

development and dissemination of products with functions that effectively reduce

energy consumption. It is an open system in which business proprietors can

participate voluntarily. The targeted products are office equipment such as

computers, monitors, printers, facsimiles, copiers, scanners, and multifunction

devices. Their standards and logos ( ) are uniform among participating

nations.

Use in High-safety Applications

This product has been designed and manufactured on the assumption that it will be

used in office, personal, domestic, regular industrial, and general-purpose

applications. It has not been designed and manufactured for use in applications

(simply called "high-safety applications" from here on) that directly involve serious

danger to life and health when an extremely high degree of safety is required, for

example, in the control of nuclear reactions at nuclear power facilities, automatic

flight control of aircraft, air traffic control, operation control in mass-transport

systems, medical equipment for sustaining life, and missile firing control in weapons

systems, and when provisionally the safety in question is not ensured. The user

should use this product with adopting measures for ensuring safety in such high-

safety applications. PFU LIMITED assumes no liability whatsoever for damages

arising from use of this product by the user in high-safety applications, and for any

claims or compensation for damages by the user or a third party.

About the use of mercury

The scanner lamps contain mercury.

To avoid unexpected injury, read the followings carefully.

Doing following actions may result in serious personal injuries:

xDo not put the substance in the lamp into your mouth as it contains mercury.

xDo not incinerate, crush, or shred the lamps or scanner.

xDo not breath the chemical liquid contained in the scanner parts.

Disposing of the scanner should be conducted as required by local ordinances or

regulations.

Illegal Copying

Reproducing bills, coins, government securities and passports, licenses issued by

public author or civilian organizations, official documents, private paper is illegal

and brought to justice

Literary works like books, paintings, wood block prints, maps, drawings, and

photographs should not be reproduced without the rightful person’s permission.

Trademarks

Microsoft, Windows and Windows NT are registered trademarks of Microsoft

Corporation in the United States and/or other countries.

ISIS, QuickScan and their respective logos are trademarks or registered

trademarks of Pixel Translations, a division of Captiva Software Corporation in the

United States.

Adobe, the Adobe logo, and Acrobat are either registered trademarks of Adobe

Systems Incorporated in the United States and/or other countries.

Other product names are the trademarks or registered trademarks of the respective

companies.

How Trademarks Are Indicated In This Manual

References to operating systems (OS) are indicated as follows:

Windows 95: Microsoft®Windows®95 operating system.

Windows 98: Microsoft®Windows®98 operating system.

Windows Me: Microsoft®Windows®Millennium Edition operating system.

Windows 2000: Microsoft®Windows®2000 Professional operating system.

Windows XP: Microsoft®Windows®XP Professional operating system, and

Microsoft®Windows®XP Home Edition operating system.

Windows NT: Microsoft®Windows NT®4.0 Server operating system and

Microsoft®Windows NT®4.0 Workstation operating system.

Where there is no distinction between the different versions of the above operating

system, the general term "Windows“ is used.

Manufacturer

PFU LIMITED

Image Products Sales Dept, Imaging Products Division, Products Group

Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa

212-8563, Japan

Phone: (81-44) 540-4538
