Fujitsu FI-4120C Manuel

perator's

uid

i-4120


canner

P3P

-E657-01EN

fi 4120C Image Scanner Operator

’

s Guide i

CONTENTS

INTRODUCTION.............................................................................v

■ Regulatory Information ......................................................... v

■ Note, Liability ........................................................................ ix

■ Safety Pre autions ............................................................... xi

Chapter 1 BASIC SCANNER OPERATIONS............................1

1.1 Turning the S anner ON ....................................................2

1.2 Loading Do uments on the ADF for S anning................ 3

1.3 S anning Do uments.........................................................6

1.4 How to Use the S anner Driver......................................... 9

Chapter 2

SCANNING VARIOUS TYPES OF DOCUMENTS

.25

2.1 S anning Double Sided Do uments............................... 26

2.2 S anning Different-width Do uments............................. 28

2.3 Saving S anned Images in PDF Format.........................29

2.4 Ex luding a Color in the Image (dropout olor) ............ 36

2.5 Dete ting Double-feeds.................................................... 38

Chapter 3 DAILY CARE ..........................................................41

3.1 Cleaning Materials and Lo ations requiring Cleaning.. 42

3.2 Cleaning the ADF.............................................................. 43

Chapter 4 REPLACING CONSUMABLES.............................47

4.1 Consumable and Repla ement Cy le.............................48

4.2 Repla ing the Pad ASSY.................................................. 53

4.3 Repla ing the Pi k Roller................................................. 57

Chapter 5 TROUBLESHOOTING............................................65

5.1 Removing Jammed Do uments...................................... 66

5.2 Remedying Typi al Troubles...........................................68

5.3 Items to Che k Before Conta ting the Agent Where

You Bought the S anner.............................................. 80

5.4 Che king Labels on the S anner.................................... 82

Chapter 6 ADF AND PAPER SPECIFICATION......................83

6.1 Do ument Size..................................................................84

6.2 Do ument Quality.............................................................85

6.3 Maximum Do ument Loading Capa ity.......................... 87

6.4 Area not to be perforated.................................................88

6.5 Double-feed Dete tion Conditions..................................89

Chapter 7 SCANNER SPECIFICATION..................................91

7.1 Basi Spe ifi ations......................................................... 92

7.2 Installation Spe ifi ations ...............................................93

7.3 External Dimensions........................................................ 94

fi 4120C Image Scanner Operator

’

s Guide iii

GLOSSARY OF TERMS ..........................................................GL-1

INDEX........................................................................................ IN-1

fi 4120C Image Scanner Operator

’

s Guide v

INTRODUCTION

Thank you for purchasing the fi-4120C Duplex Color Scanner product.

This document describes how to handle fi-4120C Duplex Color and basic operation methods. Before you

start using fi-4120C Duplex Color be sure to thoroughly read this manual to ensure correct use.

■ Regulatory Information

FCC De laration

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is located.

•Consult your dealer or an experienced radio/TV technician.

FCC warning: Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

NOTICE The use of a shielded interface cable is required to com-

ply with the Class B limits of Part 15 of FCC rules.

The length of the AC cable must be 2 meters (6.6 feet)

or less.

Canadian DOC Regulations

This digital apparatus does not exceed the Class B limit for radio noise emissions from digital

apparatus set out in the Radio interference Regulations of the Canadian Department of

Communications.

This Class B digital apparatus complies with Canadian ICES-003.

Le pésent appareil numérique n’ément pas de bruits radioélectriques dépassant les limites applicables

aux appareils numériques de la classe B prescridtes dans le Réglesment sur le brouillage

radioélectrique dicté par le ministere des Communications du Canada.

Cet appareil numérique de la classe B est conformme à la norme NMB-003 du Canada.

Bes heimigung des Herstellers / Importeurs

Hiermit wird bescheinigt, daß der/die/das fi-4120C

•In Übereinsstimmung mit den Bestimmungen der EN45014 (CE) funkentstört ist.

•Laut Maschinenlärminformationsverordnung 3. GS GV, 18.01.1991: Der höchste Schalldruckpegel

beträgt 70 dB (A) oder weniger gemäß ISO/7779.

International ENERGY STAR® Program

As an ENERGY STAR®Partner, PFU LIMITED has determined that this product

meets the ENERGY STAR®guidelines for energy efficiency.

The International ENERGY STAR®Office Equipment Program is an international

program that promotes energy saving through the penetration of energy efficient

computers and other office equipment. The program backs the development and dissemination of

products with functions that effectively reduce energy consumption. It is an open system in which

business proprietors can participate voluntarily. The targeted products are office equipment such as

computers, monitors, printers, facsimiles, copiers, scanners, and multifunction devices. Their

standards and logos ( ) are uniform among participating nations.

Use in High-safety Appli ations

This product has been designed and manufactured on the assumption that it will be used in office,

personal, domestic, regular industrial, and general-purpose applications. It has not been designed and

manufactured for use in applications (simply called "high-safety applications" from here on) that

directly involve danger to life and health when a high degree of safety is required, for example, in the

control of nuclear reactions at nuclear power facilities, automatic flight control of aircraft, air traffic

control, operation control in mass-transport systems, medical equipment for sustaining life, and

missile firing control in weapons systems, and when provisionally the safety in question is not

ensured. The user should use this product with adopting measures for ensuring safety in such high-

safety applications. PFU LIMITED assumes no liability whatsoever for damages arising from use of

this product by the user in high-safety applications, and for any claims or compensation for damages

by the user or a third party.

fi 4120C Image Scanner Operator

’

s Guide vii

About the Use of Mer ury

The scanner lamps contain mercury.

To avoid unexpected injury, read the following carefully.

Doing the following actions may result in serious personal injuries:

•Do not put the substance in the lamp in your mouth as it contains mercury.

•Do not incinerate, crush, or shred the lamps or scanner.

•Do not breathe the chemical liquid contained in the scanner lamps.

Disposing of the scanner should be conducted as required by local ordinances or regulations.

Trademarks

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation in the

United States and/or other countries.

ISIS, QuickScan and their respective logos are trademarks or registered trademarks of Pixel

Translations, a division of Captiva Software Corporation in the United States.

Adobe, the Adobe logo, and Acrobat are either registered trademarks of Adobe Systems Incorporated

in the United States and/or other countries.

Other product names are the trademarks or registered trademarks of the respective companies.

How Trademarks Are Indi ated In This Manual

References to operating systems (OS) are indicated as follows:

Where there is no distinction between the different versions of the above operating system, the general

term "Windows" is used.

Windows 95 Microsoft®Windows®95 operating system.

Windows 98 Microsoft®Windows®98 operating system.

Windows Me Microsoft®Windows®Millennium Edition operating system.

Windows NT 4.0 Microsoft®Windows® NT 4.0 Server operating system,

Microsoft®Windows®NT 4.0 Workstation operating system.

Windows 2000 Microsoft®Windows®2000 Professional operating system.

Windows XP Microsoft®Windows®XP Professional operating system,

Microsoft®Windows®XP Home Edition operating system.

viii

Manufa turer

PFU LIMITED

Image Products Sales Dept., Imaging Products Division, Products Group

Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 212-8563, Japan

Phone: (81-44) 540-4538
