Cleaning and Maintenance

fi-6130 / fi-6230

fi-6130 / fi-6230 Image Scanner Operator's Guide

TROUBLESHOOTING

CONTENTS MAP

TOP

Chapter 4 DAILY CARE

This chapter describes how to clean the scanner.

CAUTION

When operating the scanner, the ADF's glass becomes very hot.

Before you clean inside the scanner, turn off its power and unplug the AC adapter from the

outlet. Wait for at least 15 minutes for the ADF glass to cool down.

Do not turn off the scanner when you clean the Feed and Eject rollers.

WARNING

Do not use any aerosol sprays or alcohol based sprays to clean the scanner.

Dust blown up by strong air from the spray may enter the inside of the scanner. This may

cause the scanner to fail or malfunction.

Sparks, caused by static electricity, generated when blowing off dust and dirt from the

outside of the scanner may cause a fire.

fi-6130 / fi-6230 Image Scanner Operator's Guide

TROUBLESHOOTING

CONTENTS MAP

TOP

4.1 Cleaning Materials and Locations Requiring Cleaning

Cleaning Materials

The table below shows the cleaning materials that are used on this scanner.

Cleaning Materials Part No. Remarks

Cleaner F1 PA03950-0352 1 bottle (100 ml)

Moisten cloth with this fluid and wipe the scanner

clean. (*1)

Cleaning wipe PA03950-0419 24 sheets per pack (*1)(*2)

Soft, dry cloth Commercially available.

*1: For details on Cleaner F1, consult the agent where you bought your scanner or an authorized FUJITSU service provider.

*2: Pre-moistened with Cleaner F1, Cleaning Wipes are used instead of moistened cloths.

HINT

It may take long before the cleaner vaporizes if a large quantity is used. When cleaning the

scanner parts, dampen a cloth with modest quantities of the cleaner. In addition, wipe off

the cleaner completely with a soft lint-free cloth to leave no residue on the surface of the

cleaned parts.

Locations and Cycle for Cleaning

Location Standard Cleaning Cycle

Brake roller Clean every 5,000 scanned sheets.

Pick roller

Feed roller

Plastic roller

Eject roller

Glass

Ultrasonic sensor

ATTENTION

The scanner must be cleaned more frequently when the following documents are used:

mDocuments of coated paper

mDocuments with printed text or graphics almost covering the entire surface

mChemically treated documents such as carbonless paper

mDocuments containing a large amount of calcium carbonate

mDocuments written by pencil

mDocuments on which the toner is not fused sufficiently

Detergent for cleaning windows or glass cleaner can be used instead of Cleaner F1. However,

do not use paint thinner or other organic solvents.

fi-6130 / fi-6230 Image Scanner Operator's Guide

TROUBLESHOOTING

CONTENTS MAP

TOP

4.2 Cleaning the Flatbed [fi-6230 only]

1. Open the document cover.

2. Clean the following locations using a soft cloth moistened with Cleaner F1.

Plastic cover

Document bed

ATTENTION

Do not allow moisture to get inside the device during cleaning.

3. Wait for cleaned parts to dry.

4. Gently close the document cover.

fi-6130 / fi-6230 Image Scanner Operator's Guide

TROUBLESHOOTING

CONTENTS MAP

TOP

4.3 Cleaning the ADF

As a Guideline, clean the ADF every 5,000 scanned sheets. Note that this guideline varies according to the type of documents

you scan. For example, it may be necessary to clean the ADF more frequently if documents are scanned when the toner is not

sufficiently fixed on the printout.

CAUTION

The glass surface of the ADF becomes hot during the operation of the scanner.

Before you start to clean the inner parts of the scanner, disconnect the AC adapter from the

power outlet, and wait at least 15 minutes to let the glass cool down.

1. Open the ADF by pushing on the ADF open lever and turning the ADF to the front.

ADF open lever

CAUTION

Be careful, the ADF may close and pinch your finger.

2. Clean the following locations with a soft, dry cloth moistened with Cleaner F1.

No. Item

1 Brake rollers (x 2)

2 Feed rollers (x 2)

3 Eject rollers (x 2)

4 Glasses (x 2)

5 Pick rollers (x 2)

6 Plastic rollers (x 4)

7 Ultrasonic sensors (x 2)

ATTENTION

To avoid damaging the document sensors, take care that the cloth does not get hooked into

them when cleaning the inside of the ADF.

Document sensor

Brake roller

Lightly clean the Brake roller along the grooves on the roller taking care not to scratch the roller surface.

When cleaning the Brake roller, remove it from the scanner. For how to remove the Brake Roller, see Section "5.3

Replacing the Brake Rollers."

Pick roller

Lightly clean the Pick roller along the grooves on the roller taking care not to scratch the roller surface. Take particular

care in cleaning this roller as black debris on it adversely affects the pickup performance.

Plastic roller

Lightly clean the Plastic roller taking care not to damage the roller surface. Take particular care when cleaning this

roller as black debris on it affects document pick performance. Be careful not to damage the sponges attached around

the middle of the roller.

Glass

Clean lightly.

HINT

If the glass is dirty, vertical streaks may apper in the scanned images.

Ultrasonic sensor

Clean lightly with a dry cloth.

With the movie below, review the procedure to clean the Brake roller, Pick roller, Plastic roller, and ADF glass surfaces:

Feed roller/Eject roller

1) Open the ADF when the indication of the Function Number display is not "P" or "0".

If you open the ADF when the indication of the Function Number display is "P" or "0", the Feed rollers/Eject rollers

will not rotate even you perform the operation of step 2 below.

2) Simultaneously hold down the [Send to] and [Scan] buttons on the Operator Panel.

The Feed rollers/Eject rollers start to rotate slowly.

3) Hold a soft cloth moistened with cleaning fluid against the surface of the rotating Feed rollers so that it lightly

cleans the surface of the rollers. Take particular care when cleaning these rollers as black debris on these rollers

affects pickup performance. As a guideline, seven presses of the [Send to] and [Scan] buttons make the Feed

rollers/Eject rollers to rotate one full turn.

[Send to] Button

[Scan] Button

CAUTION

In step 2, all the Feed rollers/Eject rollers turn at the same time. When cleaning the Feed

rollers or Eject rollers, be careful not to touch the other rotating Feed rollers/Eject rollers.

With the movie below, review the procedure to clean the Feed rollers/Eject rollers:

3. Press down on the center of the ADF to return it to its original position until the ADF button locks.

Press center of ADF.

ATTENTION

When the ADF has returned to its original position, make sure that it is completely closed.

Feeding errors may occur if the ADF is not closed completely.

fi-6130 / fi-6230 Image Scanner Operator's Guide

TROUBLESHOOTING

CONTENTS MAP

TOP

Chapter 5 REPLACING CONSUMABLES

This chapter describes how to replace scanner consumables.

In this chapter Windows XP screenshots are illustrated.

The screens and operations may differ slightly if the OS that you are using is other than Windows XP.

Also, when the FUJITSU TWAIN32 or FUJITSU ISIS scanner driver is updated the screens and operations noted in this chapter will

differ slightly.

Refer to the manuals provided with the update.

WARNING

When operating the scanner, the ADF's inside glass becomes very hot.

Before you replace the consumables, turn off its power and unplug the AC adapter from the

outlet. Wait for at least 15 minutes.
