FujiFilm Revoria Press SC170 Manuel utilisateur
April 2023 GM1766E2-1 Edition1
FUJIFILM Business Innovation Corp.
Reference Guide
Optional Units
Revoria Press SC180
Revoria Press SC170
Revoria Press EC1100
Optional Units
2
Contents
1 High Capacity Feeder B1 4
LoadingPaper;PaperJams
2 High Capacity Feeder B1-S/C3-DS/C1-DS 9
LoadingPaper;PaperJams;CleaningMachine
3 Air Suction Feeder C1-DS/C1-DSXL 28
LoadingPaper
4 Interface Decurler Module D1 42
CurlCorrection;PaperJams
5 Inserter D1 46
LoadingPaper;PaperJams
6 High Capacity Stacker A1 51
OutputtingPaper;PaperJams
7 Crease / Two-Sided Trimmer D2 59
WasteContainer;PaperJams
8 Folder Unit CD2 69
PaperJams
9 Finisher D 72
OutputtingPaper;StapleCartridge;PaperJams
10 Square Back Fold Trimmer D1 90
WasteContainer;PaperJams
3
Preface
Preface
A guide describing the operations for optional units, such as the Finisher.
Refer
• Descriptions for the following optional products are provided in different guides.
-Offset catch tray, Long catch tray: “Reference Guide- Main Unit”
-Print / scan function-related products (Revoria Press SC180/SC170) : “Reference Guide - Operations”
-Print function-related products (Revoria Press EC1100) : “Reference Guide - Operations”
-Print server and related products: Manual included in the product
-IC card reader (Revoria Press SC180/SC170 only) : Official site of our company
• This manual may not be edited, modified or copied in whole or part without the written con-
sent of the publisher.
• Some parts of this manual are subject to change without prior notice.
• The screen shots and the illustrations in this manual are used as examples. They may differ
from yours depending on the model, the software, or the OS.
In this manual, safety instructions are preceded by the symbol . Always read and follow the
instructions before performing the required procedures.
Regarding the notations and trademarks in this document, see the “Reference Guide- Main Unit”.
Description in this manual such as feed capacity assumes 80 g/m2paper.
Optional Units
4
1 High Capacity Feeder B1
High Capacity Feeder Tray B1 can be used with Revoria Press SC180/SC170.
Device Components
23 1
No. Component Function
1 Remaining Volume Display You can check the remaining paper volume.
2 High Capacity Tray (Paper Tray 6) Load paper here.
3 Top Cover Open this cover to clear paper jams.
Main Specifications
Item Specification
Paper size A4 , Letter (8.5 x 11") , JIS B5 , 7.25 x 10.5" (184 x 267 mm)
Paper weight (g/m2) 64 to 220
Tray capacity (sheets) 2,000 (90g/m2)
Dimensions (mm) Width 389 x Depth 610 x Height 377
Weight (kg) 29
High Capacity Feeder B1 5
Loading Paper
After loading paper, configure the Paper Tray settings on the Home screen.
Refer
For details, refer to “Setup” in “Reference Guide - Operations”.
Images are printed on the face side of the loaded paper.
1. Pull out the Paper Tray toward you until it stops.
2. Remove any paper remaining in the Paper Tray.
3. If changing the Paper Size, adjust the guide position.
(1) Open the end guide (
1
), remove the screw for the guide
in the back (
2
), and remove the guide from the Paper
Tray.
(2) Insert the protrusions under the guide into the Paper Size
holes.
(3) Insert the Paper Tray protrusions into the Paper Size
holes on top of the guide and tighten the screw.
(4) Remove the screw for the guide in front and remove the
guide from the Paper Tray.
1
2
Optional Units
6
(5) Insert the protrusions under the guide into the Paper Size
holes.
(6) Insert the Paper Tray protrusions into the Paper Size
holes on top of the guide and tighten the screw.
(7) Pull the handle for the end guide up (
1
), align with the
Paper Size while moving the handle along the groove
(
2
), and lower the handle (
3
).
Note
The groove on the left side of the end guide 8.5" is not used.
4. Fan the paper well and load sheets with the printed
side facing up, and the paper edges aligned in the di-
rection of the arrow.
5. Close the end guide completely.
6. Push in the Paper Tray.
Special Media Setting
■Hole Punched Paper
Orientation: Place the holes of paper on the right side when you face the front side of machine.
3
1
2
High Capacity Feeder B1 7
Paper Jams
If paper is jammed, the machine stops and an alarm sounds. Follow the instructions displayed on
the screen to remove the jammed paper.
Gently remove the paper being careful not to tear it. If paper is torn while it is being removed
from the machine, remove all the torn pieces making sure that none remain inside the machine.
When you have finished clearing the paper jam, printing is resumed from the state before the
paper jam occurred. If a paper jam occurred during copying, tap on [Start]. Copying is resumed
from the state before the paper jam occurred.
Note
Clear the paper jams while the machine is on.
Paper Tray
1. Pull out the Paper Tray toward you until it stops.
2. Remove the jammed paper.
3. Push in the Paper Tray.
Exit
1. Hold the handle and move the unit all the way to the
left.
2. Remove the jammed paper.
3. Move the unit to the right and connect it with the
main unit.
Optional Units
8
Inside of the Upper Cover
1. Hold the handle and move the unit all the way to the
left.
2. Pull the handle (
1
) and open the cover (
2
).
3. Remove the jammed paper.
4. Close the cover.
5. Move the unit to the right and connect it with the
main unit.
1
2
High Capacity Feeder B1-S/C3-DS/C1-DS 9
2
High Capacity Feeder B1-S/C3-DS/C1-DS
High Capacity Feeder Tray B1-S can be used with Revoria Press SC180/SC170.
Device Components / Caution Labels
B1-S (Revoria Press SC180/SC170 only)
7
654 3
1
2
C3-DS/C1-DS
8
7
6543
2
1
Optional Units
10
No. Component Function
1 Bypass Tray (Paper Tray 5) Load paper here.
2
Error Indicator When paper jam occurs, the indicator is turned on.
When the priority device indicator (top lamp) blinks, first of all
perform the paper jam operation.
3 Right Cover Open this cover to clear paper jams.
4
Remaining Volume Indicator When the Paper Tray is in operation, the top lamp is turned on.
You can check the remaining volume of paper with the 4 lamps
(each lamp indicates 25%) at the center.
When Paper Replenish Indicator is turned on, paper is empty.
5
B1-S Consumables Storage Unit Stores papers and consumables.
C3-DS/C1-DS High Capacity Tray
(Paper Tray 6 or 8)
Load paper here.
6
B1-S High Capacity Tray
(Paper Tray 6)
Load paper here.
C3-DS/C1-DS High Capacity Tray
(Paper Tray 7 or 9)
7Ground Fault Interrupter A switch to automatically switch the machine off when a current
leakage is detected.
8 Upper Cover Pull this cover to clear paper jams.
Ground Fault Interrupter
When not using for an extended period or when moving
the unit, set the switch to the lower position to turn the
machine power off.
Note
Do not operate the switch under normal circumstances because it
is turned off when a current leakage is detected.
For the current leakage, refer to “User's Manual”.
Switch
TEST button
