FujiFilm instax SHARE SP-2 Manuel utilisateur
JP
EN
BOB708-100
使用説明書/困ったときには/安全にご使用いただくために
User’s Guide/Trouble shooting/Safety precautions
29
EN
Parts Name........................................... 30
Before Use............................................. 31
Inserting/Charging the Battery..... 31
Inserting the Battery.....................................31
Charging the Battery ....................................32
Charging Indicator ........................................32
Loading the INSTAX mini Film Pack
.... 33
Turning on/o the Printer............... 34
Checking Remaining Battery Life.............34
Connecting and Printing................. 35
When establishing connection for the rst
time:....................................................................35
When connection is already established: .....
37
Reprinting............................................. 38
Deleting an Image............................. 39
Unloading a used INSTAX mini lm
pack......................................................... 39
About the LED Indication................ 40
SPECIFICATIONS ................................. 41
TROUBLE SHOOTING ........................ 42
IMPORTANT SAFETY NOTICE ......... 46
Handling the Battery ........................ 53
Contents
ENGLISH
After reading this User’s Guide, keep it in a safe, easy
to nd place where you can refer to it if needed.
30
EN
1Print exit 5USB connector 9Back cover
2POWER button 6Film remaining LED 10 Battery cover
3REPRINT button 7Battery remaining LED
4USB connector cover 8Back cover lock
Parts Name
3
1
7
4
5
6
2
8
9
10
31
EN
Before Use
Before using the printer, install the instax SHARE application on your device.
• When you are using an Android OS device, search for“instax SHARE”in the Google Play, then install the application.
* System requirements of an Android OS device: Android Ver 4.0.3 or later and Google Play are installed.
• When you are using an iOS device, search for“instax SHARE” in the App Store, then install the application.
* System requirements of an iOS device: iOS Ver 7.1 or later is installed.
You may not be able to print from some devices even if you have installed the instax SHARE application and your device
meets the requirements listed here.
Access instax SHARE website for the latest information on system requirements.
Inserting/Charging the Battery
Inserting the Battery
Push up the battery cover lock to
open the battery cover.
Insert the battery according to the arrow on it.
Make sure the yellow line on the battery aligns
with the mark on the printer.
Push the battery cover
lock until it clicks into
place.
~ Ÿ !
32
EN
Inserting/Charging the Battery (Continued)
Charging the Battery Charging Indicator
Indication Battery status/Action
Lights red (ON)
Flashes red (OFF) Charging is in progress.
Lights green (ON)
Flashes green (OFF)
Charging is more than half
completed.
Flashes green, then
goes off (OFF) Charging is completed.
Flashes green and
red alternately
An error is being occurred. Stop
charging.
Charging from a PC:
• Connect the printer and PC directly. Do not connect
them via a keyboard or USB hub.
• If the PC enters the sleep mode while charging is in
progress, charging will stop. If you continue charging,
resume the PC and reconnect the USB cable.
• You may not charge the printer from a PC depending
on your PC specifications, settings, or status.
Connect the printer and an AC power adapter supplied
with your smartphone using the supplied USB cable, then
connect the AC power adapter to an indoor power outlet.
The battery remaining LED indicates the battery charge
status. For details, see the table on the right column.
• Use an AC adapter to meet the rated output below:
DC 5.0 V/1000 mA
• You can print an image while charging is in progress.
• Charging time is approximately 90 minutes.
33
EN
Loading the INSTAX mini Film Pack
~Ÿ
Caution
Do not open the back cover until you have used up the film; otherwise, the rest of the film is exposed
and turns white. The film can no longer be used.
• When you load the film pack, never press the two rectangular holes on the back of the film pack.
• Never use a film pack beyond its shelf life; otherwise, it may damage the printer.
Use FUJIFILM instax mini Color Film only. No other type of film (e.g. FUJIFILM instax Digital Mobile
Printer Photo Pack) can be used.
Notes on the film pack
• Each FUJIFILM INSTAX mini film pack contains 1 black film protective cover and 10 film sheets.
• Do not remove the film pack from its inner bag before loading it into the printer.
• The film cover is ejected automatically when the back cover is closed.
For details, refer to the instructions and warnings on FUJIFILM INSTAX mini film.
Continued on the next page
Press down the back cover lock and slide it right to
open the back cover.
Hold both sides of the film pack, align the yellow marks on
the printer and the film pack, then insert it straight.
34
EN
Loading the INSTAX mini Film Pack
(Contunued)
⁄
!
Close the back cover. Make sure the
back cover lock clicks into place.
The film cover (black) is ejected
automatically when the back
cover is closed. Remove the film
cover from the print exit.
Turning on/o the Printer
Press and hold the POWER button for approx. 1 second
to turn the printer on or off.
Turning the printer on lights up the battery remaining
LED and it turns off after a certain period of time.
If no operation occurs for a certain period of time, the
printer turns off automatically.
Checking Remaining Battery Life
Use the battery remaining LED to check when turning
the printer on or while printing is in progress.
Indication Remaining battery life
Green At more than half capacity
Red Low. Charging the battery is
recommended. (See page 32.)
Printer turns off
after flashing red.
No battery capacity remains.
Charge the battery. (See page 32.)
35
EN
Connecting and Printing
~
Ÿ
!
Continued on the next page
Wireless LAN Setup for iOS Devices
When you are using an iOS device, follow the procedure
below to perform wireless LAN setup.
1. Select “ON” for “Wi-Fi” in the “Settings” menu of your
device.
2. Tap the network name (printer name) under“Choose
a Network”.
When establishing connection for
the first time:
Press and hold the POWER button for approx.
1 second to turn the printer on.
The battery remaining LED lights up and it
turns off after a certain period of time.
Start the downloaded application “instax SHARE”.
Select the picture to print or take a picture.
36
EN
⁄
Connecting and Printing (Continued)
@
Tap “Connect and print”.
When a printer is detected,
tap “Connect”. If multiple
printers are detected, select
the printer to connect from
the list.
Printer's identifier (SSID) is
located on the bottom of the
printer.
#
Enter the factory default
password (1111) or the one you
specified, then tap “OK”.
The printer starts printing.
To reset the password to the factory default
(1111), turn the printer on while holding the
REPRINT button.
When the film has been ejected (the
printer stops making a sound), grasp
the edge of the film, then take it out.
1 film remaining LED turns off every
time you print an image.
¤
Before tapping “Connect
and print”, tapping on
the upper right displays
the edit menu. You can add
a template or adjust an
image on this menu.
Tap “Done” to exit from the
menu.
When printing, stabilize the
printer by putting it on a
steady place such as a desk.
INSTAX-1111
1111
37
EN
When connection is already established:
Connecting and Printing
~
Ÿ
Start the downloaded application “instax SHARE”.
!
Continued on the next page
Select the picture to print or
take a picture.
Tap “Print”.
The printer starts printing.
⁄
• When printing, stabilize
the printer by putting it
on a steady place such
as a desk.
• Before tapping “Print”,
tapping on the
upper right displays the
edit menu. You can add
a template or adjust an
image on this menu.
Tap “Done” to exit from
the menu.
Press and hold the POWER button for approx.
1 second to turn the printer on.
The battery remaining LED lights up and it
turns off after a certain period of time.
