FujiFilm Instax mini Link 2 Manuel utilisateur

User's Guide (Full version)

WW_EN

model number: FI023W FI023-EN-WW-01

Table of Contents

Before Use��3

Notes on Disposing of the Printer�� 3

Part Names��3

Installing the App��4

Charging the Battery ��4

LED charging status indicator ��4

Loading/Unloading the“instax mini” Film Pack ��5

Loading the Film Pack��5

Unloading a Used Film Pack ��5

Turning the Printer on/off ��6

Printer Status – LED Light Indicator��6

Connecting and Printing��6

When Connecting to the Printer for the First Time ��6

When the Printer and Smartphone are Already Connected��9

Reprinting an Image ��10

Controlling the App with the Orientation of the Printer

and the Power Button��11

Changing the App Mode When the Home Screen Is

Selected on the App�� 11

Controlling Zoom and Shutter When Using the instax

Camera on the App�� 11

Feature ��11

Specifications ��12

Troubleshooting ��12

IMPORTANT SAFETY NOTICE��13

Simple Printer Care�� 14

Bluetooth® Devices: Cautions�� 15

Independent JPEG Group (IJG) Licenses

This software is based in part on the work of the Independent

JPEG Group.

Before Use

Before using the printer, check the following has been included

with your printer.

Supplied Accessories

• Micro USB cable for

charging (1)

(BOD700-200)

• User’s Guide (1)

The battery has not been fully charged at the factory, be sure

to charge the battery before using the printer.

Notes on Disposing of the Printer

A built-in lithium ion battery is used for this printer.

When you dispose of the printer, follow your local regulations and

dispose of it properly.

Please refer to the supplied CONTACT INFORMATION sheet for

inquiry.

If your country or region is not included in the sheet, please

contact your local distributor.

CAUTION

Do not remove the built-in battery by yourself; otherwise, you may

be injured.

Disposal of Electric and Electronic Equipment in Private

Households

Disposal of used Electrical & Electronic Equipment

(Applicable in the European Union and other European

countries with separate collection systems)

This symbol on the product, in the manual and in the warranty,

and/or on its packaging indicates that this product should not be

treated as household waste. Instead it should be taken to an

appropriate collection point for the recycling of electrical and

electronic equipment.

By ensuring this product is disposed of correctly, you will help

prevent potential negative consequences to the environment and

human health, which could otherwise be caused by inappropriate

waste handling of this product.

The recycling of materials will help to conserve natural resources.

For more detailed information about recycling this product, please

contact your local city office, your household waste disposal

service or the shop where you purchased the product.

In Countries outside of EU: If you wish to discard this product,

please contact your local authorities and ask for the correct way of

disposal.

This Symbol on the batteries or accumulators indicates

that those batteries should not be treated as household

waste.

For customers in Turkey:

EEE Complies with Directive.

Read “IMPORTANT SAFETY NOTICE”(p. 13) for safety use.

Part Names

When using the printer for the first time, ensure that the battery

is fully charged.

Front

Rear

1 Film ejection slot

2 Feature button

3 Power button/LED*1

4 Micro USB port cover

5 Micro USB port

6 Reset button*2

7 Film door lock

8 Side LED

9 Film door

*1 For details on the LED indication status, see pages 4 and 6.

*2 If the printer does not work properly, press the reset button to

reset the printer.

Installing the App

Please install the mini Link Smartphone App before using the

printer.

• If you are using an Android OS smartphone, please search for

the mini Link Smartphone App in Google Play Store and install

it.

*Requirements for Android OS smartphones: Android Ver. 7.0

or higher with Google Play Store installed

• If you are using an iOS smartphone, please search for the

mini Link Smartphone App in the App Store and install it.

*Requirements for iOS smartphones: iOS Ver. 12.0 or higher

• Even if you have downloaded the app and your smartphone

meets the above requirements, you may not be able to use the

mini Link Smartphone App. This is dependent upon your

smartphone model.

Access instax mini Link app download site for the latest

information on system requirements�

Android OSiOS

Scan to download the mini Link Smartphone App

The text QR Code itself is a registered trademark and wordmark of

Denso Wave Incorporated.

Charging the Battery

Ensure Micro USB is correctly attached as indicated.

Connect the printer using the supplied Micro USB cable to a USB

AC adapter (supplied with your smartphone) then connect the

USB AC adapter to an indoor power supply.

• You can print an image while charging is in progress.

• Charging time is approximately 80 to 120 minutes.

LED charging status indicator

Check the charging status with your smartphone when connected

to the app.

Indication Charging status

LED lights up in white Not charging

LED flashes in white Charging

* When the printer is turned off, the LED goes off after the

charging is completed. When the printer is turned on and not

connected with the app, the LED lights up in white after the

charging is completed.

Charging from a PC:

• Connect the printer and PC directly. Do not connect via a USB

hub or keyboard.

• If the PC goes into sleep mode while charging, charging is

discontinued. To continue charging, exit sleep mode and then

reconnect the Micro USB cable.

• The battery may not be able to charge depending on the

specifications, settings or conditions of the PC.

Notes

• The battery has not been fully charged at the factory, be sure

to charge the battery before using the printer.

• The battery cannot be removed.

• For notes about the battery, see “Simple Printer Care”. (p.14)

Loading/Unloading the“instax mini” Film

Pack

Caution

Do not open the film door until you have used up the film;

otherwise, the rest of the film will become exposed and turn

white, then the film can no longer be used�

• When you load the film pack, never press the two rectangular

holes on the back of the film pack.

• Never use a film pack beyond its shelf life; otherwise, it may

damage the printer.

Use FUJIFILM instax mini Instant Film only. The instax SQUARE

film or instax WIDE film cannot be used.

Notes on the film pack

• Each FUJIFILM instax mini film pack contains one black film

protective cover and 10 film sheets.

• Do not remove the film pack from its inner foil packaging

until you are ready to load the film into the printer.

• The film cover is ejected automatically when the film door is

closed.

For details, refer to the instructions and warnings on FUJIFILM

instax mini Instant Film packaging.

Loading the Film Pack

1 Slide and hold the film door lock down, then open

the film door.

2 Insert film pack by aligning the yellow marks on the

film pack and body of the printer�

Note

Be sure to align the yellow marks on the printer and on the

film pack.

3 Close the film door�

4 A black film cover will automatically be ejected,

remove and dispose�

Unloading a Used Film Pack

1 Slide and hold the film door lock, then open the film

door�

2 Grasp the rectangular holes on the film pack and

remove the empty film cartridge, and dispose�

Turning the Printer on/off

• Press and hold the Power button for approximately 1 second to

turn the printer on or off.

• The LED lights up when the printer is turned on.

• The printer turns off automatically when not in use for a certain

period of time.

Printer Status – LED Light Indicator

The LED light indicates the printer status.

Indication Status

LED flashes in blue Firmware is being updated

LED flashes in purple Reprinting

LED lights up in yellow (The

printer will be turned off after 3

seconds.)

Cannot be charged

Low battery

LED flashes in yellow Film ejection error occurred

Connecting and Printing

You can enjoy creating various prints such as adding text and

applying filters to images with the functions of the instax mini Link

App.

For details on how to use the App, refer to the following site.

https://instax.com/mini_link_2

When Connecting to the Printer for the First Time

1 Press and hold the Power button for approximately

1 second to turn the printer on�

The LED lights up.

2 Open the “instax mini Link” app�

3 Set up for accessing to the printer�

4 Read the terms of use, then put a checkmark in the

[Agree to this content] box, and tap [Agree to this

content →]�

5 Tap [Set]�

[Bluetooth connection] can also be set in the process of

printing.

6 When a printer is detected, tap [Connect]�

If multiple printers are detected, select the printer to

connect from the list.

The printers identifier (device name) is located on the

bottom of the printer.

Note

When your Bluetooth settings are switched off, tap [Please

turn on Bluetooth] to put the Bluetooth settings on.

Note

If your Bluetooth settings are switched off, the following

screen appears. In this case, select [instax mini Link 2].

7 When the message is displayed, put a checkmark in

the check box and tap [PAIR]�

8 When a printer is connected, tap [Close]�

11 Set up ‘Print with video download settings’ and tap

[OK]�

12 Select an image that you wish to print�

To edit images

The following image editing options are available before

printing.

Enters text or adds a sticker on images.

Zooms up/down or rotates images.

Applies a filter to images.

Adjusts the brightness of images.

13 Tap or swipe up on the screen�

The printer starts printing.

You can also select the number of copies to print during

image transfer.

9 Set up for a four-digit password�

10 Quick instructions are displayed� Read the

instructions and tap [Let’s Play! →]�

14 When the film has been ejected (the printer stops

making a sound), hold the edge of the film and

remove from the printer�

You can view the number of prints remaining on the app.

When the Printer and Smartphone are Already

Connected

1 Press and hold the Power button for approximately

1 second to turn the printer on�

The LED lights up.

2 Open the “instax mini Link” app�

3 Select an image that you wish to print�

To edit images

The following image editing options are available before

printing.

Enters text or adds a sticker on images.

Zooms up/down or rotates images.

Applies a filter to images.

Adjusts the brightness of images.

4 Tap or swipe up on the screen�

The printer starts printing.

You can also select the number of copies to print during

image transfer.

5 When the film has been ejected (the printer stops

making a sound), hold the edge of the film and

remove from the printer�

You can view the number of prints remaining on the app.

Reprinting an Image

The last image printed can be reprinted by turning the printer over

with the film ejection slot facing downwards and pressing the

power button.

Notes

• When the printer is connected to the app and the app is in

instax Camera Mode, you cannot use the reprint function.

• The last stored image that has been printed is deleted when the

printer is turned off. In this case, you are able to print the image

from the app.

• When reprinting with the film ejection slot facing downwards,

keep at least 10 cm distance between the printer and other

objects.

Autres manuels pour instax mini Link 2

Table des matières

Autres manuels FujiFilm Imprimante

FujiFilm

FujiFilm ApeosPort - VII C4421 Manuel utilisateur

FujiFilm

FujiFilm instax SHARE SP-2 Manuel utilisateur

FujiFilm

FujiFilm ASK-500 Manuel utilisateur

FujiFilm

FujiFilm Revoria Press SC170 Manuel utilisateur

FujiFilm

FujiFilm CX-400 Manuel utilisateur

FujiFilm

FujiFilm DryPix 7000 Manuel utilisateur

FujiFilm

FujiFilm instax SHARE SP-2 Manuel utilisateur

FujiFilm

FujiFilm ApeosPro C810 Manuel utilisateur

FujiFilm

FujiFilm instax Link WIDE FI022W Manuel utilisateur

FujiFilm

FujiFilm Frontier-S DX100 Manuel utilisateur

FujiFilm

FujiFilm ApeosPort 2560 Manuel utilisateur

FujiFilm

FujiFilm Instax Share SP-1 Manuel utilisateur

FujiFilm

FujiFilm ApeosPro C810 Manuel utilisateur

FujiFilm

FujiFilm C 9070 9065 Manuel utilisateur

FujiFilm

FujiFilm instax mini Link 2 Manuel utilisateur

FujiFilm

FujiFilm ApeosPrint C325 dw Manuel utilisateur

FujiFilm

FujiFilm Apeos 3560 Manuel d'instructions

FujiFilm

FujiFilm Thermal Photo Printer Manuel utilisateur

FujiFilm

FujiFilm ASK-300 Manuel utilisateur

FujiFilm

FujiFilm ApeosPort-VII C4421 Manuel utilisateur

FujiFilm

FujiFilm Pictrography series Manuel utilisateur

FujiFilm

FujiFilm CR-IR 362 Manuel utilisateur

FujiFilm

FujiFilm instax SHARE SP-3 Manuel utilisateur

FujiFilm

FujiFilm Pictrography 3500 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
