FS S5850-48S8C Manuel utilisateur
SWITCHS MANAGEABLES L3 POUR CENTRES DE DONNÉES
MANAGED L3-SWITCHES FÜR RECHENZENTREN
MANAGED L3 DATA CENTER SWITCHES
V1.0
Quick Start Guide
Quick Start Anleitung
Guide de Démarrage Rapide
1
Introduction
Power Cord x2
Grounding Cable x1 Rubber Pad x4 M4 Screw x10
Sliding Rail x2
Console Cable （DB9 to RJ45）x1 Cat 5e Cable x1
Accessories
EN
Thank you for choosing S5850 Series switches. This guide is designed to familiarize you with the layout
of the switches and describes how to deploy the switches in your network.
Rear Mounting Bracket x2
Front Mounting Bracket x2
S5850-48S8C-DC
S5850-48B8C
S5850-48S8C
Hardware Overview
Front Panel Ports
Front Panel LEDs
SS5850-48S8C-DC
2
EN
Ports Description
SFP28
QSFP28
SFP28 ports for 1/10G transceivers
QSFP28 ports for 40/100G transceivers
ID
SYS
ID indication function enable.
Blue
On
On
On
On
O
Green
O
O
Amber
Loop Blinking
O
ID indication function disable.
The system is normally running.
Alarm or error occurs in the system.
No power or the system is not running or abnormality.
MGT
Breakout
Green
Port is linked.
Port is not linked.
One or more 100G/40G ports are breakout.
None of the 100G/40G ports is breakout.
LEDs State Description
25G SFP28
100G QSFP28
S5850-48S8C-DC
Breakout
ID
MGT
SYS
25G SFP28
100G QSFP28
3
Back Panel
S5850-48S8C/S5850-48B8C
S5850-48S8C-DC
EN
SFP28
On
Blinking
Green
25G port is linked.
25G packets are receiving or transmitting.
On
Blinking
Amber
10G/1G port is linked.
10G/1G packets are receiving or transmitting.
O Port is not linked
QSFP28
On
Blinking
Green
100G/40G port is linked.
100G/40G packets are receiving or transmitting.
On
Blinking
Amber 10G/1G port is linked.
10G/1G packets are receiving or transmitting.
O Port is not linked.
LEDs State Description
ID SYS
CON
ETH
PS2 PS1
ID SYS
CON
ETH
PS2 PS1
ID
Power Supply Module
SYS
CONETH USB
ID
Power Supply Module
Grounding
point
SYS
CONETH USB
Installation Requirements
Safety Precaution
Back Panel LEDs
Power source should be removed before cleaning switches. Do not use wet rags to wipe
switches and clean switches with liquid.
The following precautions should be followed to avoid equipment damage and personal injury
caused by improper use:
Do not place switches near water or in a wet environment, and prevent water or moisture
from entering switch chassis.
Do not place switches on an unstable case or table, since the dropping would cause serious
harm to switches.
Maintain good indoor ventilation and clear air holes of switches.
Switches shall work normally under correct voltage, so make sure the operating voltage
agrees with the voltage marked on switches.
To reduce the risk of electric shock, do not remove its enclosure when a switch is working,
and don't do so at will even if it is not powered.
4
EN
ID
SYS
ID indication function enable.
Blue
On
On
On
On
O
Green
O
Blinking
O
Amber
ID indication function disable.
The system is normally running.
Alarm or error occurs in the system.
No power or the system is not running or
abnormality.
ETH Green
Port is linked.
Port is receiving or transmitting packets.
Port is not linked.
LEDs State Description
A power supply module port
Power Supply Module
RJ45 Console Port (CON)
ETH
USB
An RJ45 console port for serial management
An Ethernet management port
A USB management port
Ports Description
5
Anti-static gloves must be worn when replacing interface board to prevent static electricity
from damaging veneer.
Installation Site
Ensure that there are some spaces at the inlet and outlet of switch for heat dissipation of switch
chassis.
To ensure a normal work environment, S5850 series switches should have the following
requirements for workplace:
Ensure that rack and working platform have good ventilation and heat dissipation systems.
Ensure that rack and working platform are rm enough to support the weight of a switch and
its accessories for installation.
Ensure rack and working platform are well earthed.
Mounting the Switch
1. Install the front mounting brackets and the sliding rails on the switch.
Rack Mounting
EN
2. Fix the rear mounting brackets to the rack.
6
EN
3. Push the switch slightly into the rack along the sliding rails, and x the other end of front
mounting brackets upon the front hold strip of rack using screws and matching nuts.
7
1. Connect one end of the grounding cable to a proper earth ground, such as the rack in which the
switch is mounted.
2. Secure the grounding lug to the grounding point on the switch back panel with the washer and
screws.
Grounding the Switch
NOTE: 1. Only S5850-48S8C-DC can be grounded.
2. The earth connection cannot be removed unless all connections are disconnected.
EN
WARNING: Do not install power cables while the power is on.
1. Plug the AC power cord into the power port on the back of the switch.
2. Connect the other end of the power cord to a power source.
(The S5850-48S8C-DC power port is dierent from the power ports of S5850-48S8C and
S5850-48B8C. )
Connecting the Power
1. Plug the compatible SFP28 transceiver into the SFP28 port.
2. Connect a ber optic cable to the ber transceiver. Then connect the other end of the cable to
other ber devices.
Connecting the SFP28 Ports
8
EN
9
1. Plug the compatible QSFP28 transceiver into the QSFP28 port.
2. Connect a ber optic cable to the ber transceivers. Then connect the other end of the cable to
other ber devices.
Connecting the QSFP28 Ports
1. Connect the DB9 female connector of the mini USB to RS-232 serial port on the computer.
2. Insert the mini USB connector into USB port on the back of the switch.
Connecting the USB port
EN
USB
