Frigidaire FEF326A Manuel utilisateur

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF326ASA FEF326A white North America

FEF326AUA FEF326A black/bisque North America

FEF326AWA FEF326A black/white North America

Publication No.

5995356804

010731

-EN/SERVICE /ECL

369

ELECTRIC

RANGE

Model No.

FEF326A

FACTORY

PARTS CATALOG

ELECTROLUX HOME PRODUCTS NORTH AMERICA

P.O. Box 212378, Augusta, GA 30917

SERVICE DATA SHEET - # 316259148

WIRING DIAGRAM - #316255123

OWNER’S GUIDE - # 316257103

INSTALLATION INSTRUCTIONS -# 316259200

07/01 2

Publication No. FEF326A

5995356804

BACKGUARD

# = Fast-moving Parts 3 07/01

* = Non-Illustrated Parts

FEF326A Publication No.

5995356804

A = FEF326A (FEF326ASA)

B = FEF326A (FEF326AWA)

C = FEF326A (FEF326AUA)

POS. NO PART NO DESCRIPTION

1 316239900 A B C Shield,backguard ,rear wall

1* 316248900 A B C Spacer,shield ,rear wall

11 316241000 A B C Shield,end cap ,RH

11A 316241001 A B C Shield,end cap ,LH

14 316022503 A B C Light/Lamp,indicator ,surface ,250 V

15 316220202 A - - Support,backguard ,white ,RH

15 316220204 - B C Support,backguard ,black ,RH

15A 316220203 A - - Support,backguard ,white ,LH

15A 316220205 - B C Support,backguard ,black ,LH

18 316240900 A - - End Cap,white ,RH

18 316240905 - B C End Cap,black ,RH

18A 316240901 A - - End Cap,white ,LH

18A 316240904 - B C End Cap,black ,LH

19 316246615 A - - Panel,backguard ,white

19 316246616 - B C Panel,backguard ,black

20 # 316222801 A B C Clock/Timer,electronic

20A 316220700 A - - Overlay,clock ,white

20A 316220701 - B C Overlay,clock ,black

24 # 316246000 A - - Switch,rocker ,white ,oven light

24 # 316246001 - B C Switch,rocker ,black ,oven light

31 316223000 A - - Knob,control ,white

31 316223002 - B C Knob,control ,black

46 316040201 A B C Lens,indicator light ,red

54 # 316021500 A B C Switch,infinite ,small element

54A# 316021501 A B C Switch,infinite ,large element

56 316234007 A - - Shield,backguard ,white ,inner

56 316234008 - B C Shield,backguard ,black ,inner

69 5303288565 A B C Screw,truss sqdr ,8-32 x 3/16 ,switch mtg

* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome

* 316021110 A B C Screw,8-18 x 0.5 ,black

BACKGUARD

07/01 4

Publication No. FEF326A

5995356804

BODY

# = Fast-moving Parts 5 07/01

* = Non-Illustrated Parts

FEF326A Publication No.

5995356804

A = FEF326A (FEF326ASA)

B = FEF326A (FEF326AWA)

C = FEF326A (FEF326AUA)

POS. NO PART NO DESCRIPTION

1 316201300 A B C Back,main

3 316230102 A B - Panel,bodyside ,white ,RH

3 316230103 A B - Panel,bodyside ,white ,LH

3 316230108 - - C Panel,bodyside ,bisque ,RH

3 316230109 - - C Panel,bodyside ,bisque ,LH

4 316201401 A B C Burner Box

5 316129200 A B C Screw,leveling ,plastic ,with stop

6 316067902 A B C Rack,oven

7 316205008 A B C Hinge,oven door ,RH

7A 316205009 A B C Hinge,oven door ,LH

8 3203540 A B C Panel,oven bottom

9 316081900 A B C Pan,broiler

10 316082000 A B C Insert,broiler pan

14 316116400 A B C Receptacle,oven light

15 5303013071 A B C Bulb/Lamp,oven light

21 3014099 A B C Spacer,bodyside

26 316206300 A B C Support,chassis ,(2)

29 3051162 A B C Glide,drawer ,front

37 # 316233900 A B C Probe,oven temp

41 316233400 A B C Cover,hinge cutout ,RH

41A 316233500 A B C Cover,hinge cutout ,LH

42 316206200 A B C Shield,wool ,lower

57 316081100 A B C Cover,access

58 3200847 A B C Insulation,oven bottom

58A 316047707 A B C Insulation, 1" ,oven wrapper

58B 316054202 A B C Insulation, 1" ,oven back

59 316073605 A B C Tube,oven vent

60 316239100 A B C Cover,oven front

62 # 5303935061 A B C Terminal Block Kit

62* 5303308427 A B C Nut,hex ,10-32

63 5301145190 A B C Plate,grounding strap

66 # 316203200 A B C Element,broil

67 # 316075103 A B C Element,bake

68 316203400 A B C Support,broil element

71 316015810 A B C Shield,rear wall ,galv steel

87 316081200 A B C Bracket,cable mtg

170 5303935180 A B C Anti-tip Kit,w/bracket,screw

170* 316107200 A B C Bracket,anti-tip

170* 316112500 A B C Template,anti-tip

170* 316116000 A B C Screw,concrete tpg ,1.75 inch ,anti-tip brkt

* # 316253105 A B C Wiring Harness,main

* 316073400 A B C Plate,weight ,(3)

* 3203550 A B C Plug,button ,oven bottom

* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome

* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312

* 5303285179 A B C Screw,wafer head ,8-32T x 0.500 ,black

* 5308014215 A B C Screw,6-20 x 0.312

* 5303271648 A B C Screw,wafer hd sq dr ,8-18AB x 0.5

BODY

07/01 6

Publication No. FEF326A

5995356804

TOP/DRAWER

# = Fast-moving Parts 7 07/01

* = Non-Illustrated Parts

FEF326A Publication No.

5995356804

A = FEF326A (FEF326ASA)

B = FEF326A (FEF326AWA)

C = FEF326A (FEF326AUA)

POS. NO PART NO DESCRIPTION

1 316011503 A B C Drawer

2 316231500 A B C Liner,drawer

4 316231305 A B - Panel,drawer ,white

4 316231309 - - C Panel,drawer ,bisque

7 3051163 A B C Glide,drawer ,rear

15 # 5303012223 A B C Element,surface ,8" ,large

15A# 08067762 A B C Element,surface ,6" ,small

16 316202307 A B - Main Top,white

16 316202309 - - C Main Top,bisque

17 316057601 A B C Rod,support ,main top

18 316235900 A B C Hinge,main top ,RH

18A 316235901 A B C Hinge,main top ,LH

19 # 318067055 A - - Pan,surface element ,large ,chrome ,w/clip

19 318067051 - B C Pan,surface element ,large ,black ,w/clip

19A# 318067045 A - - Pan,surface element ,small ,chrome ,w/clip

19A 318067041 - B C Pan,surface element ,small ,black ,w/clip

27 # 5303912666 A B C Terminal Block Kit,surface element

28 3017801 A B C Medallion,stainless steel ,surf elem

28 5303017715 A B C Medallion,1 1/2"dia ,black ,surface element

* # 316253501 A B C Wiring Harness,surface element

* 316058600 A - - Clip,surface element ,chrome ,(4)

* 316058601 - B C Clip,surface element ,black ,(4)

* 316021108 A B C Screw,cup pt ,8-18 x 0.375 ,chrome

* 316021110 A B C Screw,8-18 x 0.5 ,black

* 5303280311 A B C Screw,wafer hd sq dr ,10-32 x 0.312

* 5308014215 A B C Screw,6-20 x 0.312

TOP/DRAWER

07/01 8

Publication No. FEF326ASA

5995356804

DOOR

# = Fast-moving Parts 9 07/01

* = Non-Illustrated Parts

FEF326ASA Publication No.

5995356804

POS. NO PART NO DESCRIPTION

5 316050300 Glass,oven door ,white ,outer

6 316222709 Shield,oven door ,wool

7 316076401 Insulation,oven door

8 316088600 Glass,oven door ,inner

9 316230604 Liner,oven door

10 5303285179 Screw,wafer head ,8-32T x 0.500 ,black

10B 316008401 Washer,3/4 OD x 1/4 ID ,steel

12 316239700 Seal,oven door

13 316202702 Panel,oven door ,white

20 316248401 Spacer,handle ,white ,(2)

22 5303272476 Retainer,glass ,(2) ,angle

39 316248301 Handle,oven door ,white

60B 5303280311 Screw,wafer hd sq dr ,10-32 x 0.312

* 316245600 Seal,door ,air gap

* 316021110 Screw,8-18 x 0.5 ,black

* 316001014 Screw,waf hd sq ,10-24 x 1.6 ,handle ,(2)

DOOR

07/01 10

Publication No. FEF326AUA & FEF326AWA

5995356804

DOOR
