Frigidaire GLEB27T8A Manuel utilisateur

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET

GLEB27T8ABA GLEB27T8A 37056791F1061 black North America

GLEB27T8ASA GLEB27T8A 37056791F1011 white North America

Publication No.

5995360863

011112

-EN/SERVICE /ECL

377

ELECTRIC

WALL OVEN

Model No.

GLEB27T8A

FACTORY PARTS CATALOG

RANGE

WIRING DIAGRAM - # 318046110

OWNER’S GUIDE - # 318200919

TIMER INSTRUCTION SHEET - # 318200130

INSTALLATION INSTRUCTIONS - # 318201509

ELECTROLUX HOME PRODUCTS NORTH AMERICA

P.O. BOX 212378, Augusta, GA 30917

11/01 2

Publication No. GLEB27T8A

5995360863

CONTROL PANEL

# = Functional Parts 3 11/01

* = Non-Illustrated Parts

GLEB27T8A Publication No.

5995360863

CONTROL PANEL

A = GLEB27T8A (GLEB27T8ASA)

B = GLEB27T8A (GLEB27T8ABA)

POS. NO PART NO DESCRIPTION

15 5303302286 A B Support,backguard ,RH

15A 5303302287 A B Support,backguard ,LH

18 5303311208 A - End Cap,white ,RH

18 5303311231 - B End Cap,black ,RH

18A 5303311209 A - End Cap,white ,LH

18A 5303311232 - B End Cap,black ,LH

19 318030028 A - Panel,control ,white

19 318030029 - B Panel,control ,black

20 # 318010501 A B Clock/Timer,EOC

21 5303302283 A - Trim,canopy ,white ,top

21 5303300968 - B Trim,canopy ,black ,top

23 318015110 A B Bracket,clock mtg

42 5303318709 A - Trim,vent ,white

42 5303316983 - B Trim,vent ,black

78 318036901 A - Cover,oven vent ,white

78 318036900 - B Cover,oven vent ,black

80 # 318022001 A B Relay Board

81 # 318022002 A B Relay Board,w/transformer

82 318023600 A B Support,relay board ,(2)

82A 5303317199 A B Support,snap-in ,(3)

99 5303316956 A - Screw,6-32 x 3/8 ,white ,(2)

99 5303307406 - B Screw,6-32 x 3/8 ,(2)

* 3201861 A B Screw,6 x 0.375

* 5303320848 A B Screw,6-20 x 0.250

* 5303323136 A B Screw ground

11/01 4

Publication No. GLEB27T8A

5995360863

UPPER OVEN

# = Functional Parts 5 11/01

* = Non-Illustrated Parts

GLEB27T8A Publication No.

5995360863

UPPER OVEN

A = GLEB27T8A (GLEB27T8ASA)

B = GLEB27T8A (GLEB27T8ABA)

POS. NO PART NO DESCRIPTION

1A 318071000 A B Back,main ,upper

2 318070202 A B Cover,top

3 318070601 A B Panel,bodyside ,upper,RH

3A 318070600 A B Panel,bodyside ,upper,LH

6 5303299719 A B Rack,oven

6A 5303311206 A B Shelf,broiler pan

6B 318025202 A B Shelf,oven

9 5303317977 A B Pan,broiler

10 5303317976 A B Insert,broiler pan

12 318089910 A B Switch,oven light ,door frame

14 # 5308011085 A B Receptacle,oven light

15 # 3201908 A B Light,oven

16 3201911 A B Cover,oven light ,glass

17 5304400195 A B Retainer,light cover

37 # 316111203 A B Sensor,oven temp probe

41 5303310526 A B Cover,hinge cutout

54 5303310514 A B Housing,oven light

57 318072100 A B Plate-connection

58A 5303316994 A B Insulation,oven wrapper

58B 5303311219 A B Insulation,oven back

59 318072510 A B Tube,oven vent

62 # 5303310518 A B Terminal Block

66 # 5303322963 A B Element,broil

67 # 5303299718 A B Element,bake

68 5304403015 A B Support,element hanger

76 318056104 A B Front,oven

80 318192400 A B Spring,oven

81 5303320846 A B Plate,oven mtg

83 318089519 A B Liner,oven assy

86 5303310524 A B Receptacle,hinge

88 5303311222 A B Rod,latch

89 # 318095934 A B Motor,latch assy ,w/brkt & switch

89*# 318120710 A B Switch,cooktop shutoff

97 318066500 A B Wrapper,back & sides

99 318055200 A B Support

107 5303318711 A B Cover,fan

108# 318073012 A B Motor,blower

109 5303311203 A B Blade,fan

111 5303311205 A B Nut,fan retainer

119# 318005200 A B Switch,thermal ,lower

123 318071441 A B Shield,insulation ,top & sides

125# 5303311202 A B Motor,convection

127 5303310542 A B Adapter,vent tube ,with converter

128 5303311163 A B Bushing

129 5303311164 A B Spring

156 318024100 A B Bracket-vent tube

157 318071601 A B Divider,upper oven

187 318013501 A B Tube,latch rod

222 318080000 A B Plate,oven temp probe

263 5303322885 A B Spacer,fan blade

264 318143811 - B Shield,wire

* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box

* 5303211311 A B Screw,8 x 0.500

* 5303317199 A B Support,snap-in ,(3)

* 5304407813 A B Washer

* # 318078501 A B Box & wires assy

11/01 6

Publication No. GLEB27T8A

5995360863

LOWER OVEN

# = Functional Parts 7 11/01

* = Non-Illustrated Parts

GLEB27T8A Publication No.

5995360863

LOWER OVEN

A = GLEB27T8A (GLEB27T8ASA)

B = GLEB27T8A (GLEB27T8ABA)

POS. NO PART NO DESCRIPTION

6 5303299719 A B Rack,oven

6B 318025202 A B Shelf,oven

12 318089910 A B Switch,oven light ,door frame

14 # 5308011085 A B Receptacle,oven light

15 # 3201908 A B Light,oven

16 3201911 A B Cover,oven light ,glass

17 5304400195 A B Retainer,light cover

37 # 316111203 A B Sensor,oven temp probe

41 5303310526 A B Cover,hinge cutout

54 5303310514 A B Housing,oven light

56 5303302282 A - Trim,bodyside ,white ,(2)

56 5303300956 - B Trim,bodyside ,black ,(2)

58A 5303311218 A B Insulation,oven wrapper

58B 5303311219 A B Insulation,oven back

59 5303300951 A B Tube,oven vent

66 # 5303322963 A B Element,broil

67 # 5303299718 A B Element,bake

68 5304403015 A B Support,element hanger

71 318071120 A B Shield,rear wall

76 318056104 A B Front,oven

80 5303301261 A B Spring,oven

81 5303320846 A B Plate,oven mtg

82 5303304699 A B Shield,insulation

83 318089519 A B Liner,oven assy

86 5303310524 A B Receptacle,hinge

88 5303311222 A B Rod,latch

89 # 318095934 A B Motor,latch assy ,w/brkt & switch

89*# 318120710 A B Switch,cooktop shutoff

96 5303317197 A B Duct,oven vent ,assy

96A 3016325 A B Duct,oven vent ,center

96B 3016327 A B Duct,vent pipe

97 318066604 A B Wrapper,back & sides

98 318029332 A B Trim,side ,inner,RH

98A 318029333 A B Trim,side ,inner,LH

99 5303299686 A B Support,adjustable

101 318039512 A - Bracket,trim ,white

101 318039511 - B Bracket,trim ,black

103 318028701 A - Trim,base ,white

103 318028700 - B Trim,base ,black

107 5303318711 A B Cover,fan

109 5303311203 A B Blade,fan

111 5303311205 A B Nut,fan retainer

119# 318004900 A B Switch,thermal

121 318145002 A B Wrapper,base

123 318071441 A B Shield,insulation ,top & sides

125# 5303311202 A B Motor,convection

127 318072801 A B Adaptor assy

128 5303311163 A B Bushing

129 5303311164 A B Spring

142 318054900 A B Support

156 5303317198 A B Bracket,oven vent

187 318013501 A B Tube,latch rod

188 08007817 A B Spacer,(6)

222 318080000 A B Plate,oven temp probe

227 5303323955 A B Clip,retainer

263 5303322885 A B Spacer,fan blade

* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box

* 5303211311 A B Screw,8 x 0.500

* 5303302745 A B Screw,10-16x1-1/8 ,square drive

* 5304407813 A B Washer

* 5303935083 A - Screw 10-16X1-1/4

* 5303324184 - B Screw (8X5/16)

11/01 8

Publication No. GLEB27T8A

5995360863

DOOR

# = Functional Parts 9 11/01

* = Non-Illustrated Parts

GLEB27T8A Publication No.

5995360863

DOOR

A = GLEB27T8A (GLEB27T8ASA)

B = GLEB27T8A (GLEB27T8ABA)

POS. NO PART NO DESCRIPTION

3 318026110 A - Trim,oven door ,white

3 318026600 - B Trim,oven door ,black

4 318210504 A - Glass,oven door ,white ,outer

4 318210505 - B Glass,oven door ,black ,outer

6 318073502 A B Shield,air wash

7 318133751 A B Insulation,oven door

9 318048503 A B Liner,oven door

10 5303311217 A B Screw,handle ,door

12 318053100 A B Seal,oven door

16 318042300 A B Glass,oven door ,heat barrier ,(2)

17 318042000 A B Spacer,glass

18 318053000 A B Seal,rope

20 318014301 A - Spacer,handle ,white ,(2)

20 318014300 - B Spacer,handle ,black ,(2)

22 5303310511 A B Bar,glass retainer

23 5303310506 A B Hinge,oven door ,assembly

29 318014400 A B Spacer,door

31 318065102 A B Latch,door

39 316091107 A - Handle,door ,white ,oven

39 316091106 - B Handle,door ,black ,oven

54 5303308456 A B Screw,8-18 x 0.531 ,black ,door frame

59 3202113 A B Plug,button

* 08002868 A B Screw,10-24 x 0.500 ,probe,thrm brkt ,shield,drwr,box

* 5303211311 A B Screw,8 x 0.500

* 5303308450 A B Screw,8 x 0.375

* 5303323277 A B Screw (8-18X13/32)

11/01 10

Publication No. GLEB27T8A

5995360863

WIRING DIAGRAM
