Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

Over-The-Range

Product Dimensions

Height 16-13/32"

Width 29-7/8"

Depth 15-1/32"

More Easy-To-Use Features

Two-Speed Ventilation

Over-the-range microwave doubles

as a hood with two fan speeds.

Extra-Large 13-1/2" Diameter

Glass Turntable

2 Metal Cooking Racks

10 Cooking Power Levels

Auto-Reheat Options

Control Lock Option

Electronic Clock & Timer

Vent Filters

Dishwasher-safe.

Auto-Start Heat Sensor Vent Fan

Ductless Vent Installation

Option Included

Attractive Stainless Steel Exterior

Available in:

Microwave

FFMV154CL S

Stainless

(S)

Featuring Bake & Brown Convection

Multi-Stage Cooking

Our Multi-Stage Cooking option allows

you to program power levels and

cooking times in advance, so you can

program it to defrost, cook and keep a

meal warm all at once.

Ready-Select™ Controls

Easily select options with the touch

of a button.

Bake & Microwave Option

One-touch button combines the speed

and freshness of microwave cooking

with baking in your microwave.

Bake & Brown

Convection Option

10 Preset Temperature / One-Touch

buttons from 100 to 425 degrees so you

can bake and brown in your microwave.

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

Microwave

FFMV154CL S Over-The-Range

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Product Dimensions

A - Height

B - Width

C - Depth

16-13/32"

29-7/8"

15-1/32"

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

Over-the-Range Microwave Oven

Frigidaire Baseline

Cutout Dimensions

Height (Min.)

Height (Max.)

Width (Min.)

Depth (Min.)

Depth (Max.)

16-3/4"

17"

30"

12"

13"

Features

Control / Timing System

Exterior Door Finish

Handle Design

Microwave Capacity (Cu. Ft.)

Convection

Watts (IEC-705 Test Procedure)

Interior Light

Interior Color

Turntable Diameter

Turntable On / O

Control Lock

Clock

Touch Pad Buttons

Power Levels

Accessory Metal Rack

Microwave Control Options

Popcorn Button

Chicken Nugget Button

Baked Potato Button

Sensor Reheat Button

Snack Button

Beverage

Auto Melt / Soften Options

Auto Reheat Options

Snack Menu Options

Auto Cook Options

Auto Defrost Options

Multi-Stage Cooking Option

Keep Warm

Add-30-Seconds

Sensor Cooking Options

Vegetable Cook Sensor

Delay Start

User Preferences

Ventilation System

Ducted / Ductless

Installation Option

Exhaust Fan (CFM)

Cooktop Light

Auto-Start Heat Sensor

Dishwasher-Safe Vent Filter

(Ductless Installation)

Power Ratings

Frequency (Mhz)

Watts @ 120 Volts

Amps @ 120 Volts

Optional Accessories

36" Stainless Steel Trim Kit

36" White Trim Kit

36" Black Trim Kit

Speciﬁcations

Oven Interior (HxWxD)

Power Supply Connection Location

Voltage Rating

Connected Load

(kW Rating) @ 120 Volts1

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Ready-Select™

Stainless Steel

1.5

Bake & Brown Convection

900

Yes

Stainless Steel

13-1/2"

Yes

High (1 – 9)

Yes

Weight / Time

Yes

2-Speed

170 / 300

Yes

2,450

1,550

PN # 5304463784

8-7/8" x 20-1/4" x 13-15/32"

Right Top Rear

120V / 60Hz / 15A

1.4

1For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.
