Frigidaire FPMC3085PF Feuille d'instructions

Signature Features

PowerPlus® Preheat

Preheat in less than six minutes.1

PowerPlus® Dual Convection

Dual convection fan circulates hot air

throughout the oven for faster and

more even multi-rack baking

Smudge-Proof™ Stainless Steel

Reduces fingerprints and smudges so

it’s easy to clean.

Fits-More™ Microwave Oven

Extra-large microwave provides 2.0

cu. ft. of cooking space.

frigidaire.com

Product Dimensions

Height 42-3/4"

Width 30"

Depth 24-1/2"

More Easy-To-Use Features

Eortless™ Convection

Takes the guesswork out of convection

cooking — our oven automatically

adjusts standard baking temperatures

to convection temperatures for consistent

results.

PowerPlus® Broil

Added power means you can broil

food faster.

SpaceWise® Half Rack

Flexible rack system that adjusts to cook

multiple dishes at once. Remove the half

rack and you'll have extra height for tall

dishes.

PowerPlus® Clean

For a heavy-duty clean with 25% more

cleaning power.

Eortless™ Reheat

Reheat almost anything at the touch

of a button.

One-Touch™ Keep Warm Setting

Just one touch of a button keeps food

warm until everything — and everyone —

is ready.

Built with American Pride

Appliances that are high-performing,

more accessible, and more innovative than

ever — designed, built, and engineered in

the U.S.A.

“My Favorite” Setting

Easily program your most used setting

with the touch of a button.

Pro-Select® Controls

Precise control at your fingertips.

Sabbath Mode (Star-K® Certiﬁed)

Available in:

Based on single rack cooking performance, not set

temperature, using PowerPlus® Preheat.

Stainless

(F)

Microwave Combination Oven

FPMC3085PF

30" Electric

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

Microwave Combination Ovens

Frigidaire Baseline

Spacer

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Product Dimensions

A - Height

B - Width

C - Depth

D - Height (Wrapper)

E - Width (Wrapper)

Depth with Door Open 90˚

42-3/4"

30"

24-1/2"

40-15/16"

28-1/4"

45-1/2"

Cutout Dimensions

Height (Min.) / (Max.)

Width (Min.) / (Max.)

Depth (Min.)

41-1/8" / 41-1/4"

28-1/2" / 29"

23-1/2"

Microwave Combination Oven

FPMC3085PF 30" Electric

Features

Control / Timing System

Exterior Door Finish

Handle Design

Microwave Features

Microwave Capacity (Cu. Ft.)

Watts (IEC-705 Test Procedure)

Window

Interior Light

Interior Color

Turntable Diameter

Turntable On / O

Control Lock / Clock

Touch Pad Buttons / Power Levels

Microwave Control Options

Popcorn Button

Chicken Nugget Button

Baked Potato Button

Reheat Button / Snack Button

Auto Melt / Soften Options

Auto Reheat Options

Snack Menu Options

Auto Cook Options

Auto Defrost Options

Keep Warm / Add-30-Seconds

Sensor Cooking Options

Vegetable Cook Sensor

Delay Start / User Preferences

Oven Features

Oven Capacity (Cu. Ft.)

Oven Window

Oven Lights

Hidden Bake Element

Convection System

Baking System

Broiling System

PowerPlus® Preheat

Bake / Broil Element (Watts)

Oven Rack Conﬁguration

Oven Cleaning System

Oven Controls

Convection Conversion

My Favorite / Slow Cook

Eortless™ Temperature Probe

Chicken Nugget Button / Pizza Button

Keep Warm / Add-a-Minute

Optional Accessories

3"-High Bottom Trim – Stainless Steel

10'-Long Armored Power Cable

Certiﬁcations

Sabbath Mode (Star-K® Certiﬁed)

Speciﬁcations

Microwave Oven Interior ( H x W x D )

Oven Interior ( H x W x D )

Power Supply Connection Location

Voltage Rating

Connected Load (kW Rating)

@ 240 / 208 Volts1

Amps @ 240 / 208 Volts

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Pro-Select®

Smudge-Proof™

Stainless Steel

2.0

1,200

Large

Yes

White

16"

Yes / Yes

28 / 10

Yes

Yes / Yes

Yes

Yes / Yes

4.6

Extra-Large with

Pro-Tint Finish

2 Halogen

Yes

PowerPlus® Convection

Even Baking Technology

PowerPlus® Broil

Yes

2,000 / 4,000

1 Heavy Duty, 1 SpaceWise®

Half Rack, 1 Oset Rack

Self Clean / Steam Clean

Eortless™

Yes / Yes

Yes

Yes / No

PN # 318259707

PN # 903056-9010

Yes

10-1/2" x 17-3/8" x 18-5/8"

17-1/2" x 24-1/8" x 18-3/4"

Left Bottom Rear

240V / 208V / 60Hz

7.5 / 5.6

31.3 /26.9

250 Lbs.

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web

at frigidaire.com.

1Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt,

60 Hertz AC only electrical supply with ground required on

separate circuit fused on both sides of line.

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Microwave Combination Oven

FPMC3085PF 30" Electric

Microwave Combination Oven Specifications

• Product Shipping Weight (approx.) – 250 Lbs.

• Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz

AC only electrical supply with ground required on separate circuit

fused on both sides of line.

• Connected Load (kW Rating) @ 240 / 208 Volts = 7.5 / 5.6

• Amps @ 240 / 208 Volts = 31.3 /26.9

• Recommended Circuit Breaker – 30 Amps

• Always consult local and national electric codes.

• Minimum 21" clearance for oven door depth when open.

• Suggested distance from floor is 11-1/2". Minimum required distance

is 4-1/2".

• To adapt Microwave Combination Oven to fit cutout height greater

than 41-11/16", add one 2"-wide wood shim of appropriate height

to each side of opening under oven side rails. Lifting oven will hide

larger cutout opening at top and oven's 1"-high bottom trim will hide

shims at bottom. (Standard 1"-High Bottom Trim included.)

• To adapt Microwave Combination Oven to fit cutout height greater

than 42-3/16", optional 3"-High Bottom Trim available.

• Minimum 23-1/2" deep cutout dimension is critical for proper

installation, to ensure that oven's faceplate will fit flush against

cabinet front.

• Full oven base of solid plywood or similar material required,

capable of supporting 225 Lbs.

• Base must be level and cabinet front must be square.

• Microwave Combination Oven is NOT approved to be

used in stackable or side-by-side installation.

Note: For planning purposes only. Refer to Product Installation Guide

on the web at frigidaire.com for detailed instructions.

Optional Accessories

• 3"-High Stainless Steel Bottom Trim – (PN # 318259707).

• 10'-Long Armored Power Cable – (PN # 903056-9010).

30" Microwave / Wall Oven Combination

Professional

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

General Installation Guidelines

with Side-by-Side Refrigerator

Top

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Specifications

subject to change.

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Top

General Installation Guidelines

with Top Mount Refrigerator

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Top

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

General Installation Guidelines

with French Door Refrigerator

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Top

General Installation Guidelines

with All Refrigerator or All Freezer

Table des matières

Autres manuels Frigidaire Four à micro-ondes

Frigidaire

Frigidaire FMV156E Mode d’emploi

Frigidaire

Frigidaire FMV158FM Manuel utilisateur

Frigidaire

Frigidaire FFMV152CLB Manuel utilisateur

Frigidaire

Frigidaire MWV150KB - 1.5 cu. Ft. Microwave Manuel de service

Frigidaire

Frigidaire 316137234 Manuel utilisateur

Frigidaire

Frigidaire GLMV169H Manuel utilisateur

Frigidaire

Frigidaire M044K Series Manuel du propriétaire

Frigidaire

Frigidaire FFCT1278LS Manuel utilisateur

Frigidaire

Frigidaire PLMBZ209GC - 2.0 cu. Ft. Microwave Oven Manuel utilisateur

Frigidaire

Frigidaire FMV156DCB Guide de démarrage rapide

Frigidaire

Frigidaire LEVM30FE Manuel utilisateur

Frigidaire

Frigidaire GLEB27M9FBC Manuel utilisateur

Frigidaire

Frigidaire Gallery FGBM19WNVD Manuel utilisateur

Frigidaire

Frigidaire FMOS1846BD Manuel utilisateur

Frigidaire

Frigidaire MWV150K Manuel utilisateur

Frigidaire

Frigidaire PLBMV188HC - Microwave Manuel utilisateur

Frigidaire

Frigidaire FMOW1852AS Manuel utilisateur

Frigidaire

Frigidaire FGMV174KFC Manuel du propriétaire

Frigidaire

Frigidaire FMV157GS - Microwave Manuel utilisateur

Frigidaire

Frigidaire FGBM185KB - Microwave Manuel utilisateur

Frigidaire

Frigidaire CFMV145BC Manuel utilisateur

Frigidaire

Frigidaire FFCM1134L W Instructions d'utilisation et de sécurité

Frigidaire

Frigidaire FFMV1645TW Manuel du propriétaire

Frigidaire

Frigidaire FFMV154CLS Instructions d'utilisation et de sécurité

Manuels Four à micro-ondes populaires d'autres marques

Daewoo

Daewoo KOG-574R0S Manuel utilisateur

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Daewoo

Daewoo KOC-984T2S13 Manuel utilisateur
