Frigidaire FMT144 Manuel utilisateur

Microwave

Use & Care Manual

Over-the-Range Microwave Oven

Product

Registration . . . . . . . Cover

Important

Safety Information . . 2–8

Grounding Instructions 9

Operating

Instructions . . . . . . 12–25

Features . . . . . . . . .10, 26

Care and

Cleaning . . . . . . . . 27–31

Troubleshooting . . 32–33

Consumer

Services

Warranty & Service . . . 34–36

Questions ? 1-800-944-9044

READ AND SAVE THESE INSTRUCTIONS

(United States)

Record All Information For

Future Reference

Brand: __________________________________

Model #: _______________________________

Serial #:_________________________________

(See Features page for location)

Date of

Purchase: _______________________________

Please fill

in completely,

sign and return

promptly!

FMT144

Getting Started . . . . . .11

49-400661v03 9/13/00 3:44 PM Page 1

Do Not Attempt to operate this oven

with the door open since open-door

operation can result in harmful

exposure to microwave energy. It is

important not to defeat or tamper with

the safety interlocks.

Do Not Place any object between the

oven front face and the door or allow soil

or cleaner residue to accumulate on

sealing surfaces.

Do Not Operate the oven if it is

damaged. It is particularly important

that the oven door close properly and

that there is no damage to the:

1.door (bent)

2.hinges and latches (broken or

loosened)

3.door seals and sealing surfaces.

The Oven Should Not be adjusted or

repaired by anyone except properly

qualified service personnel.

PRECAUTIONS TO AVOID

POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY

For your safety the information in this manual must be followed to

minimize the risk of fire or explosion or to prevent property damage,

personal injury or loss of life.

Before you call for service, there are a

few things you can do to help us serve

you better.

Read this manual.

It contains instructions to help you use

and maintain your microwave properly.

If you received a damaged

oven...immediately contact the dealer

(or builder) that sold you the oven.

Save time and money.

Check the section titled “Troubleshooting”

before calling. This section helps you solve

common problems that might occur. If you

do need service, you can relax knowing help

is only a phone call away. A list of toll-free

customer service numbers is included in

the back of this manual. Or call Frigidaire

Consumer Services at 1-800-944-9044,

24 hours a day, 7 days a week.

NEED HELP? Help us, help you: 1-800-944-9044.

IMPORTANT SAFETY INFORMATION

READ ALL INFORMATION

BEFORE USING

49-400661v03 9/13/00 3:44 PM Page 2

WARNING!

To reduce the risk of fire, burns, electric shock, injury to persons, or

exposure to excessive microwave energy when using your appliance,

follow basic precautions, including the following sections.

•Read and follow the specific “Precautions

to Avoid Possible Exposure to Excessive

Microwave Energy” on page 2.

•This appliance must be grounded.

Connect only to properly grounded

outlet. See Grounding Instructions

section on page 9.

•Do not mount this appliance over a sink.

•Install or locate this appliance only in

accordance with the provided

Installation Instructions.

•This over-the-range oven was designed

for use over ranges no wider than 42

inches. It may be installed over both gas

and electric cooking equipment.

•Do not operate this appliance if it has a

damaged power cord or plug, if it is not

working properly, or if it has been

damaged or dropped.

•Do not cover or block any openings on

the appliance.

•Use this appliance only for its intended

use as described in this manual. Do not

use corrosive chemicals or vapors in this

appliance. This microwave oven is

specifically designed to heat, dry or cook

food, and is not intended for laboratory

or industrial use.

SAFETY PRECAUTIONS

This microwave oven is UL listed for installation over electric and gas ranges.

This microwave oven is not approved or tested for marine use.

IMPORTANT SAFETY INFORMATION

49-400661v03 9/13/00 3:44 PM Page 3

•Do not store this appliance outdoors.

Do not use this product near water—

for example, in a wet basement, near a

swimming pool or near a sink.

•Keep power cord away from heated

surfaces.

•Do not immerse power cord or plug in

water.

•See door surface cleaning instructions in

the Care and Cleaning section(s) of this

manual.

•This appliance should be serviced only

by qualified service personnel. Contact

nearest authorized service facility for

examination, repair or adjustment.

•As with any appliance, close supervision

is necessary when used by children.

•To reduce the risk of fire in the oven

cavity:

— Do not overcook food. Carefully attend

appliance if paper, plastic or other

combustible materials are placed inside

the oven while cooking.

— Remove wire twist-ties and metal

handles from paper or plastic containers

before placing them in the oven.

— Do not use the oven for storage

purposes. Do not leave paper products,

cooking utensils or food in the oven

when not in use.

— If materials inside oven should ignite,

keep the oven door closed, turn the

oven off and disconnect the power cord,

or shut off power at the fuse or circuit

breaker panel. If the door is opened,

the fire may spread.

SAVE THESE

INSTRUCTIONS.

IMPORTANT SAFETY INFORMATION

READ ALL INFORMATION

BEFORE USING

49-400661v03 9/13/00 3:44 PM Page 4

Arcing is the microwave term for sparks in

the oven. Arcing is caused by:

•The temperature probe in the

microwave but not inserted in the food.

•The metal shelf not installed correctly so

it touches the microwave wall.

•Metal or foil touching the side of

the oven.

•Foil not molded to food (upturned

edges act like antennas).

•Metal, such as twist-ties, poultry pins, or

gold-rimmed dishes, in the microwave.

•Recycled paper towels containing small

metal pieces being used in the

microwave.

Arcing

•Do not pop popcorn in your microwave

oven unless in a special microwave

popcorn accessory or unless you use

popcorn labeled for use in microwave

ovens.

•Some products such as whole eggs and

sealed containers—for example, closed

jars—will explode and should not be

heated in this microwave oven. Such use

of the microwave oven could result in

injury.

•Do not boil eggs in a microwave oven.

Pressure will build up inside egg yolk

and will cause it to burst, possibly

resulting in injury.

•Operating the microwave with no food

inside for more than a minute or two

may cause damage to the oven and could

start a fire. It increases the heat around

the magnetron and can shorten the life

of the oven.

•Foods with unbroken outer “skin” such

as potatoes, hot dogs, sausages,

tomatoes, apples, chicken livers

and other giblets, and egg yolks should

be pierced to allow steam

to escape during cooking.

Foods

IMPORTANT SAFETY INFORMATION

Special Notes About Microwaving

If you see arcing, press the CLEAR/OFF pad and correct the problem.

49-400661v03 9/13/00 3:44 PM Page 5

•Avoid heating baby food in glass jars,

even with the lid off. Make sure all infant

food is thoroughly cooked. Stir food to

distribute the heat evenly. Be careful to

prevent scalding when warming formula

or breast milk. The container may feel

cooler than the milk really is. Always test

the milk before feeding the baby.

•Spontaneous boiling—Under certain

special circumstances, liquids may start

to boil during or shortly after removal

from the microwave oven. To prevent

burns from splashing liquid, we

recommend the following: before

removing the container from the oven,

allow the container to stand in the oven

for 30 to 40 seconds after the oven has

shut off. Do not boil liquids in narrow-

necked containers such as soft drink

bottles, wine flasks and especially

narrow-necked coffee cups. Even if the

container is opened, excessive steam can

build up and cause it to burst or

overflow.

•Do not defrost frozen beverages in

narrow-necked bottles (especially

carbonated beverages). Even if the

container is opened, pressure can build

up. This can cause the container to

burst, possibly resulting in injury.

•Hot foods and steam can cause burns. Be

careful when opening any containers of

hot food, including popcorn bags,

cooking pouches and boxes. To prevent

possible injury, direct steam away from

hands and face.

•Do not overcook potatoes. They could

dehydrate and catch fire, causing

damage to your oven.

•Cook meat and poultry thoroughly—

meat to at least INTERNAL 160°F.

and poultry to at least INTERNAL

180°F. Cooking to these internal

temperatures usually protects against

foodborne illness.

Safety Fact

–

SUPERHEATED WATER

Microwaved water and other liquids do not always bubble when they reach

the boiling point. They can actually get superheated and not bubble at all.

Superheated liquid will bubble up out of the cup when it is moved or when

something like a spoon or tea bag is put into it.

To prevent this from happening and causing injury, do not heat any liquid for

more than 2 minutes per cup. After heating, let the cup stand in the

microwave for 30 seconds before moving it or putting anything into it.

IMPORTANT SAFETY INFORMATION

READ ALL INFORMATION

BEFORE USING

49-400661v03 9/13/00 3:44 PM Page 6

Make sure all cookware used in your

microwave oven is suitable for

microwaving. Most glass casseroles,

cooking dishes, measuring cups, custard

cups, pottery or china dinnerware which

does not have metallic trim or glaze with a

metallic sheen can be used. Some

cookware is labeled “suitable for

microwaving.”

•If you are not sure if a dish is microwave-

safe, use this test: Place in the oven both

the dish you are testing and a glass

measuring cup filled with 1 cup of

water—set the measuring cup either in or

next to the dish. Microwave 1 minute at

high. If the dish heats, it should not be

used for microwaving. If the dish

remains cool and only the water in the

cup heats, then the dish is microwave-

safe.

•If you use a meat thermometer while

cooking, make sure it is safe for use in

microwave ovens.

•Some styrofoam trays (like those that

meat is packaged on) have a thin strip of

metal embedded in the bottom. When

microwaved, the metal can burn the

floor of the oven or ignite a paper towel.

•Do not use recycled paper products.

Recycled paper towels, napkins and

waxed paper can contain metal flecks

which may cause arcing or ignite. Paper

products containing nylon or nylon

filaments should be avoided, as they may

also ignite.

•Do not use the microwave to dry

newspapers.

•Not all plastic wrap is suitable for use in

microwave ovens. Check the package for

proper use.

•Paper towels, waxed paper and plastic

wrap can be used to cover dishes in order

to retain moisture and prevent

spattering. Be sure to vent plastic wrap

so steam can escape.

•Cookware may become hot because of

heat transferred from the heated food.

Pot holders may be needed to handle the

cookware.

•“Boilable” cooking pouches and tightly

closed plastic bags should be slit, pierced

or vented as directed by package. If they

are not, plastic could burst during or

immediately after cooking, possibly

resulting in injury. Also, plastic storage

containers should be at least partially

uncovered because they form a tight

seal. When cooking with containers

tightly covered with plastic wrap, remove

covering carefully and direct steam away

from hands and face.

Microwave-Safe Cookware

How to test for a microwave-safe dish.

IMPORTANT SAFETY INFORMATION

Special Notes About Microwaving

49-400661v03 9/13/00 3:44 PM Page 7

•Use foil only as directed in this manual.

TV dinners may be microwaved in foil

trays less than 3/4″high; remove the top

foil cover and return the tray to the box.

When using foil in the microwave oven,

keep the foil at least 1 inch away from

the sides of the oven.

•Plastic cookware—Plastic cookware

designed for microwave cooking is very

useful, but should be used carefully. Even

microwave-safe plastic may not be as

tolerant of overcooking conditions as are

glass or ceramic materials and may

soften or char if subjected to short

periods of overcooking.

In longer exposures to over-cooking, the

food and cookware could ignite. Follow

these guidelines:

1. Use microwave-safe plastics only and use

them in strict compliance with the

cookware manufacturer’s

recommendations.

2. Do not microwave empty containers.

3. Do not permit children to use plastic

cookware without complete supervision.

The Exhaust Fan

The fan will operate automatically under

certain conditions (see Automatic Fan

feature). Take care to prevent the starting

and spreading of accidental cooking fires

while the exhaust fan is in use.

•Clean the underside of the microwave

often. Do not allow grease to build up on

the microwave or the fan filters.

•In the event of a grease fire on the

surface units below the microwave oven,

smother a flaming pan on the surface

unit by covering the pan completely with

a lid, a cookie sheet or a flat tray.

•Use care when cleaning the exhaust fan

filters. Corrosive cleaning agents, such as

lye-based oven cleaners, may damage the

filters.

•When flaming foods under the

microwave, turn the exhaust fan off.

The fan, if operating, may spread the

flame.

•Never leave surface units beneath your

microwave oven unattended at high heat

settings. Boilovers cause smoking and

greasy spillovers that may ignite and

spread if the microwave exhaust fan is

operating. To minimize automatic fan

operation, use adequate sized cookware

and use high heat on surface units only

when necessary.

IMPORTANT SAFETY INFORMATION

READ ALL INFORMATION

BEFORE USING

Microwave-Safe Cookware (continued)

49-400661v03 9/13/00 3:44 PM Page 8

WARNING

Improper use of the grounding

plug can result in a risk of

electric shock.

This appliance must be grounded. In

the event of an electrical short circuit,

grounding reduces the risk of electric

shock by providing an escape wire for

the electric current.

This appliance is equipped with a power

cord having a grounding wire with a

grounding plug. The plug must be

plugged into an outlet that is properly

installed and grounded.

Consult a qualified electrician or service

technician if the grounding instructions

are not completely understood, or if

doubt exists as to whether the appliance

is properly grounded.

If the outlet is a standard 2-prong wall

outlet, it is your personal responsibility

and obligation to have it replaced with a

properly grounded 3-prong wall outlet.

Do not under any circumstances cut or

remove the third (ground) prong from

the power cord.

Do not use an adapter plug with this

appliance.

Do not use an extension cord with this

appliance. If the power cord is too short,

have a qualified electrician or service

technician install an outlet near the

appliance.

For best operation, plug this appliance

into its own electrical outlet to prevent

flickering of lights, blowing of fuse or

tripping of circuit breaker.

Grounding Instructions

Optional Kits

Filler Panel Kits

JX40WH or JX46WH—White

JX41 or JX46BL—Black

JX40AL or JX46AL—Almond

When replacing a 36″or 42″range hood,

filler panel kits fill in the additional width

to provide a custom built-in appearance.

For installation between cabinets only; not

for end-of-cabinet installation. Each kit

contains two 3″-wide filler panels. Two kits

are needed for a 42″opening.

Filter Kits

JX81A—Recirculating Charcoal Filter Kit

Filter kits are used when the microwave

oven cannot be vented to the outside.

Available at extra cost from your

Frigidaire supplier.

Ensure proper ground

exists before use.

IMPORTANT SAFETY INFORMATION

Grounding Instructions/Optional Kits

49-400661v03 9/13/00 3:44 PM Page 9

1.Door Handle. Pull to open the door.

The door must be securely latched for

the microwave to operate.

2.Door Latches.

3.Window with Metal Shield. Screen

allows cooking to be viewed while

keeping microwaves confined

in the oven.

4.Touch Control Panel Display.

5.Cooktop Lights.

6.Grease Filters.

7.Removable Turntable. Turntable and

support must be in place when using

the oven. The turntable may be

removed for cleaning.

NOTE: Rating plate, oven vent(s) and

oven light are located on the inside walls

of the microwave oven. Model and serial

numbers are on a label inside the oven.

NOTE: This manual covers several models so the illustration may not look exactly

like your model. However, operating instructions for each of the features and functions

of your microwave will be found in this manual.

Microwave Features

Here is a quick guide to the features and

controls of your microwave oven.

,,,,

,,,,,,

,,,,,,,,

,,,,,,,,,

,,,,,,,

,,,,,

,,,

321

900 Watts

49-400661v03 9/13/00 3:44 PM Page 10

Table des matières

Autres manuels Frigidaire Four à micro-ondes

Frigidaire

Frigidaire LEVM30FE Manuel utilisateur

Frigidaire

Frigidaire 16495056 Manuel utilisateur

Frigidaire

Frigidaire CFMV145 Manuel utilisateur

Frigidaire

Frigidaire Gallery FGMV174K F Manuel utilisateur

Frigidaire

Frigidaire FGMV173KQ - Gallery Series Microwave Manuel utilisateur

Frigidaire

Frigidaire FPMO3077T Manuel utilisateur

Frigidaire

Frigidaire FGBM185KB - Microwave Manuel de service

Frigidaire

Frigidaire FFCM1134LS Manuel utilisateur

Frigidaire

Frigidaire CPLMZ169GCC Manuel utilisateur

Frigidaire

Frigidaire CPLMB209DC Manuel utilisateur

Frigidaire

Frigidaire PMBD3080AF Manuel du propriétaire

Frigidaire

Frigidaire FGMV185KWB Manuel utilisateur

Frigidaire

Frigidaire FFCT1278LS Manuel utilisateur

Frigidaire

Frigidaire Gallery FGMV153CL Manuel utilisateur

Frigidaire

Frigidaire FFMV152CL W Instructions d'utilisation et de sécurité

Frigidaire

Frigidaire Gallery FGMO205K F Manuel utilisateur

Frigidaire

Frigidaire MWV150KB - 1.5 cu. Ft. Microwave Manuel de service

Frigidaire

Frigidaire Gallery FGMV185K Manuel utilisateur

Frigidaire

Frigidaire PLMVZ169HC - 1.6 cu. Ft. Microwave Oven Manuel utilisateur

Frigidaire

Frigidaire plmv169dcd Manuel utilisateur

Frigidaire

Frigidaire FPMC3085KF - Microwave Oven Combination Manuel utilisateur

Frigidaire

Frigidaire FGMO206NTD Manuel du propriétaire

Frigidaire

Frigidaire FGBM185KB - Microwave Manuel utilisateur

Frigidaire

Frigidaire FMT144G1B1 Manuel utilisateur

Manuels Four à micro-ondes populaires d'autres marques

Daewoo

Daewoo KOG-574R0S Manuel utilisateur

LG MH7040SS Manuel utilisateur

Sharp

Sharp R-895(AL)M Manuel utilisateur

Dometic

Dometic DOTRM13W Manuel utilisateur

Sanyo

Sanyo EM-X680 Manuel utilisateur

Sharp

Sharp R-393M Manuel utilisateur

KitchenAid

KitchenAid KMCX4510 Instructions d'installation

Smeg

Smeg S45MCX1 Manuel utilisateur

Russell Hobbs

Russell Hobbs RHM2044 Manuel utilisateur

Sunbeam

Sunbeam SMW759 Manuel utilisateur

Gallet

Gallet FMOE230S Manuel utilisateur

Bosch

Bosch CEG732X.1B Manuel utilisateur

Dometic

Dometic Roadmate 230 Manuel utilisateur

Samsung

Samsung SJ0396W Manuel utilisateur

Sanyo

Sanyo EM-P494WS Manuel utilisateur

Sharp

Sharp R-240 Manuel utilisateur

Electrolux

Electrolux EMS2840 Manuel utilisateur

Daewoo

Daewoo KOC-984T2S13 Manuel utilisateur
