Frigidaire EFIC121-SS Manuel utilisateur

This ice maker is not designed to keep ice frozen. After each use, remove all

ice cubes, drain the water.

ICE MAKER

12 KGS

26 LBS

USER MANUAL

EFIC121-SS/EFIC121-SSBLACK/EFIC121-SSRED

is a pending or registered trademark used under license from

Electrolux Home Products, Inc.

Made In China

For service assistance and product information, please call: 1-800-968-9853.

Curtis International Ltd.

7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3 www.curtisint.com

TABLE OF CONTENTS

TECHNICAL PARAMETERS.......................................................10

WARRANTY CARD......................................................................11

To reduce the risk of fire, explosion,electricshock,orinjury

when using your ice maker, follow these important safety

instructions:

Before using check that the voltage power corresponds to

the one shown on the appliance nameplate.

Do not remove any safety, warning, or product information

labels from your ice maker.

Plug the ice maker into an exclusive grounded power outlet.

No other appliance should be plugged into the same outlet.

Be sure that the plug is fully inserted into the receptacle.

This appliance must be grounded. It is equipped with a

power cord having a grounding plug. The plug must be

plugged into an outlet that is properly installed and grounded.

Avoid the use of an extension cord because it may overheat

and cause a risk of fire. However, if it is necessary to use an

extension cord:

1) Use only extension cord with grounding plug.

2) The marked rating of an extension cord must be equal to or

greater than the rating of this appliance.

3) It should be positioned such that it does not drape over the

counter or tabletop where it can be pulled on by children

intentionally.

Do not operate any appliance with a damage cord or plug

or after the appliance malfunction or has been damaged in any

manner. Return the appliance to the nearest authorized service

facility for examination, repair or adjustment.

If the supply cord is damaged, it must be replaced by the

manufacturer or its service agent or a similarly qualified

person in order to avoid a hazard.

Do not let cord hang over edge of table or counter.

When using electrical appliances, basic safety precautions

should always be followed including the following

Do not place on or near a hot gas or electric burner, or in a

heated oven.

Place power cord in such a way it cannot be pulled on by

children or cause a tripping hazard.

Place power cord in such a way that it is not in contact

with hot surfaces.

The use of attachment not recommended or sold by

manufacturer may cause fire, electric shock or injury.

Do not touch the evaporator when using the ice maker or

making ice to avoid being suffer from frostbite.

Do not immerse any part of the product in water.

To disconnect, turn any control to “OFF”, then remove

plug from wall outlet.

Do not plug or unplug product with wet hands.

Unplug the product before cleaning, maintaining and when not

in use.

Do not use with water that is microbiologically unsafe or

of unknown quality.

Do not clean your ice maker with any flammable fluids.

The fumes may create a fire hazard or explosion.

Do not overturn the ice maker. If the ice maker is

overturned accidentally, make it stand steadily for 2 hours

before powering it on again.

If the ice maker is brought in from outside in wintertime,

do not use for a few hours, allowing the unit to warm up to the

room temperature before operating.

Never put flammable, explosive and corrosive articles into

the ice maker.

Never use the ice maker when there is flammable gas

leakage.

Never store or use gas and other flammable articles near

the ice maker to avoid any fire.

Unplug the ice maker before moving it to avoid damaging

the refrigerating system.

Do not attempt to disassemble, repair, modify, or replace

any part of your product.

This appliance is not intended for used by persons

(including children) with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of

the appliances by a person responsible for their safety.

Children should be supervised to ensure that they do not

play with the appliance.

Close supervision is necessary when any appliance is used

by or near children.

Do not leave the appliance unattended while in use.

Do not use outdoors.

Do not use the appliance for other than intended use.

Please dispose of the ice maker according to local regulations

as it uses flammable blowing gas and refrigerant.

34. Please refer to local regulations regarding disposal of the

appliance for its flammable refrigerant and blowing gas.

SAVE THESE INSTRUCTIONS

HOUSEHOLD USE ONLY

(Productmay be subject to changewithout priornotice)

Hole plug

Key (with indicator)

Function

ON/OFF

Start or stop the appliance

POWER

Standby mode: “POWER” indicator blinks;

Working condition: “POWER” indicator

lights solidly.

ICE FULL

“ICE FULL” indicator lights up when the

ice basket is full.

ADD WATER

“ADD WATER” indicator lights up when

the water reservoir is lack of water.

1. Unpack the appliance, then check and make sure that all the accessories including ice

basket and ice scoop etc. are included. Please contact the client service department

if some accessories are missed.

2. Please ensure the ice maker is level and on a stable table or platform to avoid

malfunction.

3. The incline angle of the ice maker cabinet should not exceed 45°during transportation

or use. Do not turn the ice maker upside down. Doing so could cause the compressor or

refrigerating system to operate incorrectly. Please allow time for the fluids in the

compressor to settle after the ice maker is moved or transported. Before using the ice

maker for the first time, please wait for 2 hours after the unit has been leveled and

positioned in the proper place.

4. The appliance must be placed on a dry and level surface with sufficient ventilation, far

from heat sources such as ovens, heaters and corrosive gases. Leave about a 6-inch

(15cm) clearance on all sides of the ice maker for proper ventilation.

5. Do not fill the water reservoir with hot water. This may damage the ice maker. It is

best to fill the water reservoir with water of room temperature or lower.

6. Do not use the appliance in a very cold environment (lower than 5℃).

7. Clean the appliance by following the operation of “CLEANING AND

MAINTENANCE” before you operate.

1. Ensure that the drain plug at the bottom of water reservoir is closed well.

2. Plug the ice maker into the wall outlet, until the “POWER” indicator blinks.

NOTE: Please let the ice maker rest for 30 minutes before plug if it has been

moved.

3. Open the top lid and remove the ice basket.

4. Fill the water reservoir with drinking water.

NOTE: Do not fill above the MAX water level mark.

5. Replace the ice basket and close the top lid.

6. Press “ON/OFF” key, and the “POWER”indicator lights solidly.

7. The ice-making cycle will last approximately 7-15 minutes, depending on the ambient

temperature and water temperature.

8. The ice-making cycle starts with water being pumped into the ice tray situated below

the evaporator. Over the next 7-15 minutes ice forms on the evaporator. Oncethishas

completed, the ice tray will tilt backwards and the remaining water in the ice tray is

drained back into the water reservoir. The ice cubes are then dropped from the evaporator

and pushed forward into the ice basket by the ice shovel. The ice tray will automatically

move back into position under the evaporator and start the next cycle.

9. The “ICE FULL” indicator will light up when the ice basket is full and then the ice

maker will stop the ice-making cycle automatically. Gently remove the ice from the ice

basket with the ice scoop. About 5 seconds later, the ice maker will restart its ice making

function automatically.

10. The “ADD WATER” indicator will light up when the water reservoir is lack of water

and the ice-making cycle will stop automatically. At that time, remove the ice basket and

add water to the water reservoir, and then press “ON/OFF” key again to restart the

ice-making cycle. The appliance will start working automatically after about 20 minutes

if the operator forgets to restart the appliance after refill.

11. When you have got your desired amount of ice, stop the ice making cycle by pressing

the “ON/OFF” key and unplug the unit from the wall outlet.

12. Open the top lid and transfer the ice to a freezer.

13. Allow the ice maker to reach room temperature.

14.We suggest replacing the water every a week. Please empty the water reservoir if the ice

maker is not used for a long time.

To keep your ice tasting fresh and your ice maker looking great, we recommend cleaning

your ice maker once per week.

1. Stop the ice-making cycle by pressing the “ON/OFF” key, unplug the ice maker from

the wall outlet and allow it to warm up to room temperature.

2. If residual water is found in the ice tray, gently push the ice tray back so that all water

drains into the water reservoir.

3. Move the appliance forward to a place 60mm away from the working table and open

the drain plug to drain out excess water (see Fig.1, Fig.2 and Fig.3).

4. Remove the ice basket.

5. Clean the ice maker interior with a soft cloth soaked with warm water and vinegar,

then rinse with clean water and then drain all the water.

6. Replace the drain plug well in position. Wash the ice basket and ice scoop in warm

soapy water. Rinse and dry.

7. Clean the exterior of the ice maker with a soft damp cloth. Use a mild dishwashing

soap, if necessary.

NOTE:

1) Do not use organic solvent, boiled water, detergent, strong acid and strong alkali etc.

for cleaning.

2) Do not clean the evaporator.

8. Please empty the water reservoir and dry it for storage if the ice maker is not used for a

long time.

（Fig.1）

（Fig.2）（Fig.3）

Problem

Possible causes

Solution

“ADD WATER”

indicator turns on

1.Low water level or lack of

water

2.The water screen at the bottom

of water reservoir is blocked.

3.Pump malfunction.

1.Stop making ice, refill

water and then press

“ON/OFF”keytorestart

ice-making cycle.

2.Clean

3.Send it to the authorized

department for repair.

“ICE FULL” indicator

lights up

1.Ice basket is full and the

infrared light is blocked by the

ice.

2. Infrared light-emitting diode

& light-receiving diode do not

work

1. Remove the ice from ice

basket.

2a. Wipe up the foreign

objects on the infrared

light-emitting diode &

light-receiving diode and

restart the ice maker.

2b. Call Customer Service if

the infrared light-emitting

diode & light-receiving

diode still can not work

after wiping up the foreign

objects on them and

restarting the ice maker.

“ADD WATER” and

“ICE FULL” indicators

turn on simultaneously

1. The ice tray is not in the right

position.

2. The “ICE FULL” condition

can not be detected as the

infrared light module is

interfered by the sunlight.

1. Unplug the appliance and

checkiftheicetrayis

blocked by something.

2. Unplug the appliance and

move it to a place which is

not exposed to the sunlight,

then plug the appliance and

activate it again.

The ice collects

together.

Making ice takes too much time.

Stop making ice and restart

the ice-making cycle after

the ice melts.

The water in the water reservoir

Fill the water reservoir with

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Frigidaire Machine à glaçons

Frigidaire

Frigidaire EFIC117-SS Manuel utilisateur

Frigidaire

Frigidaire EFIC102-RED Manuel utilisateur

Frigidaire

Frigidaire EFIC108-C Manuel utilisateur

Frigidaire

Frigidaire EFIC128-BLACK-6COM Manuel du propriétaire

Frigidaire

Frigidaire FGHS2655PF6B Manuel utilisateur

Frigidaire

Frigidaire EFIC206-B-TG-SILVER Manuel du propriétaire

Frigidaire

Frigidaire FFTR1835VS Manuel utilisateur

Frigidaire

Frigidaire EFIC123-SS Manuel utilisateur

Frigidaire

Frigidaire EFIC239 Manuel du propriétaire

Frigidaire

Frigidaire EFIC120-SS-SC Manuel utilisateur

Frigidaire

Frigidaire EFIC157-BLACK Manuel du propriétaire

Frigidaire

Frigidaire FXIC151-SS Manuel du propriétaire

Frigidaire

Frigidaire IM115 - Ice Maker Kit Manuel utilisateur

Frigidaire

Frigidaire 242102400 Manuel utilisateur

Frigidaire

Frigidaire EFIC236-WHITE Manuel du propriétaire

Frigidaire

Frigidaire EFIC237 Manuel du propriétaire

Frigidaire

Frigidaire EFIC245-SS Manuel du propriétaire

Frigidaire

Frigidaire EFIC130-SS Manuel du propriétaire

Frigidaire

Frigidaire EFIC113 Manuel utilisateur

Frigidaire

Frigidaire EFIC117-SSCOPPER-B-COM Manuel utilisateur

Frigidaire

Frigidaire EFIC103-AMZ-SC Manuel du propriétaire

Frigidaire

Frigidaire EFIC235 Manuel utilisateur

Frigidaire

Frigidaire EFIC121-B-SS Manuel du propriétaire

Frigidaire

Frigidaire EFIC450 Manuel utilisateur

Manuels Machine à glaçons populaires d'autres marques

Hoshizaki

Hoshizaki KMD-460MWJ Manuel utilisateur

Sub-Zero

Sub-Zero 315I Instructions d'utilisation

Unold

Unold 48945 Manuel utilisateur

Kenmore

Kenmore 2217402A Manuel utilisateur

Cornelius

Cornelius WM600 Mode d'emploi

GE XPIO43SCSS Manuel utilisateur

Hoshizaki

Hoshizaki KMD-901MAH Manuel utilisateur

Whynter

Whynter FIM-450HA Manuel utilisateur

U-Line

U-Line UMCR014-SC01A Manuel d'installation

Andrew James

Andrew James AJ000522 Manuel utilisateur

Scotsman

Scotsman CME1356 Manuel utilisateur

Scotsman

Scotsman ACM 25 Manuel utilisateur

Kärcher

Kärcher IP 120 Manuel utilisateur

U-Line

U-Line SS1095 Manuel utilisateur

Maytag

Maytag MIM1554WRS - Ice Maker Manuel utilisateur

Hoshizaki

Hoshizaki KM-630MAH Manuel utilisateur

Princess

Princess Yonanas Manuel utilisateur

Unold

Unold 48946 Manuel utilisateur
