Freescale Semiconductor M68HC08RG Manuel utilisateur

M68HC08RG/AD

Rev. 2, 3/2002

M68HC08

Family Reference Guide

Reference Guide

Programming Model

A ACCUMULATOR (A)

15 8 7 0

H X INDEX REGISTER (H:X)

15 0

STACK POINTER (SP)

15 0

PROGRAM COUNTER (PC)

CONDITION CODE

V11HINZC

CARRY/BORROW FLAG (C)

TWO’S COMPLEMENT OVERFLOW

FLAG(V) ZEROFLAG(Z)

HALF-CARRYFLAG(H) NEGATIVE FLAG (N)

INTERRUPT MASK (I)

Figure 1. Programming Model

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

2M68HC08 Family Reference Guide MOTOROLA

Stacking

Figure 2. Interrupt Stack Frame

NOTE: To maintain compatibility with the M6805 Family, H (the high byte of the index

routine modifies H or uses the indexed addressing mode, it is

the user’s responsibility to save and restore it prior to returning.

IRQINT PSHH

|Interrupt service routine

PULH

RTI

Figure 3. H Register Storage

CONDITION CODE REGISTER

ACCUMULATOR

INDEX REGISTER (LOW BYTE X)(1)

PROGRAM COUNTER HIGH

1. High byte (H) of index register is not stacked.

PROGRAM COUNTER LOW

•

$00FF (DEFAULT ADDRESS

UNSTACKING

ORDER

STACKING

ORDER

ON RESET)

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

MOTOROLA M68HC08 Family Reference Guide 3

Interrupt Vector Locations

Notation Used in Instruction Set Summary

See Table 2 for the instruction set summary.

Table 1. M68HC08 Vectors

Address Reset Priority

FFFE Reset 1

FFFC SWI 2

FFFA IREQ[0] 3

:::

FF02 IREQ[124] 127

FF00 IREQ[125] 128

Operators

( ) = Contents of register or memory location shown inside parentheses

←= Is loaded with (read: “gets”)

&= Boolean AND

|= Boolean OR

⊕= Boolean exclusive OR

×= Multiply

÷= Divide

:= Concatenate

+=Add

–= Negate (two’s complement)

«= Sign extend

CPU Registers

A = Accumulator

CCR = Condition code register

H = Index register, higher order (most significant) eight bits

X = Index register, lower order (least significant) eight bits

PC = Program counter

PCH = Program counter, higher order (most significant) eight bits

PCL = Program counter, lower order (least significant) eight bits

SP = Stack pointer

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

4M68HC08 Family Reference Guide MOTOROLA

Memory and Addressing

M= A memory location or absolute data, depending on addressing

mode

M:M + $0001 = A 16-bit value in two consecutive memory locations. The higher-

order (most significant) eight bits are located at the address of M,

and the lower-order (least significant) eight bits are located at the

next higher sequential address.

rel =The relative offset, which is the two’s complement number stored

in the last byte of machine code corresponding to a branch

instruction

Condition Code Register (CCR) Bits

V=Two’s complement overflow indicator, bit 7

H= Half carry, bit 4

I= Interrupt mask, bit 3

N= Negative indicator, bit 2

Z= Zero indicator, bit 1

C= Carry/borrow, bit 0 (carry out of bit 7)

Bit Status BEFORE Execution of an Instruction (n = 7, 6, 5, ... 0)(1)

1. For 2-byte operations such as LDHX, STHX, and CPHX, n= 15 refers to bit 15 of the

2-byte word or bit 7 of the most significant (first) byte.

Mn=Bitnof memory location used in operation

An=Bitnof accumulator

Hn=Bitnof index register H

Xn=Bitnof index register X

bn=Bitnof the source operand (M, A, or X)

Bit Status AFTER Execution of an Instruction(1)

1. For 2-byte operations such as LDHX, STHX, and CPHX, n= 15 refers to bit 15 of the

2-byte word or bit 7 of the most significant (first) byte.

Rn=Bitnof the result of an operation (n= 7, 6, 5, …0)

CCR Activity Figure Notation

– = Bit not affected

0 = Bit forced to 0

1 = Bit forced to 1



=Bit set or cleared according to results of operation

U = Undefined after the operation

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

MOTOROLA M68HC08 Family Reference Guide 5

Machine Coding Notation

dd =Low-order eight bits of a direct address $0000–$00FF (high byte assumed

to be $00)

ee =Upper eight bits of 16-bit offset

ff =Lower eight bits of 16-bit offset or 8-bit offset

ii =One byte of immediate data

jj =High-order byte of a 16-bit immediate data value

kk =Low-order byte of a 16-bit immediate data value

hh =High-order byte of 16-bit extended address

ll =Low-order byte of 16-bit extended address

rr =Relative offset

Explanation of Italic Expressions in Source Form Column

n=Any label or expression that evaluates to a single integer in the range 0–7

opr8i =Any label or expression that evaluates to an 8-bit immediate value

opr16i =Any label or expression that evaluates to a 16-bit immediate value

opr8a =Any label or expression that evaluates to an 8-bit value. The instruction

treats this 8-bit value as the loworder eight bits of an address inthe direct

page of the 64-Kbyte address space ($00xx).

opr16a =Any label or expression that evaluates to a 16-bit value. The instruction

treats this value as an address in the 64-Kbyte address space.

oprx8 =Any label or expression that evaluates to an unsigned 8-bit value; used

for indexed addressing

oprx16 =Any label or expression that evaluates to a 16-bit value. Since the

MC68HC08S has a 16-bit address bus, this can be either a signed or an

unsigned value.

rel =Any label or expression that refers to an address that is within –128 to

+127 locations from the next address after the last byte of object code for

the current instruction. The assembler will calculate the 8-bit signed

offset and include it in the object code for this instruction.

Address Modes

INH =Inherent (no operands)

IMM =8-bit or 16-bit immediate

DIR =8-bit direct

EXT =16-bit extended

IX =16-bit indexed no offset

IX+ =16-bit indexed no offset, post increment (CBEQ and MOV only)

IX1 =16-bit indexed with 8-bit offset from H:X

IX1+ =16-bit indexed with 8-bit offset, post increment (CBEQ only)

IX2 =16-bit indexed with 16-bit offset from H:X

REL =8-bit relative offset

SP1 =Stack pointer relative with 8-bit offset

SP2 =Stack pointer relative with 16-bit offset

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

6M68HC08 Family Reference Guide MOTOROLA

Table 2. Instruction Set Summary (Sheet 1 of 8)

Source

Form Operation Description Effect

on CCR

Address

Mode

Opcode

Operand

Cycles

VH I NZC

ADC #opr8i

ADC opr8a

ADC opr16a

ADC oprx16,X

ADC oprx8,X

ADC ,X

ADC oprx16,SP

ADC oprx8,SP

Add with Carry A ←(A) + (M) + (C)



–



IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED9

9EE9

hh ll

ee ff

ADD #opr8i

ADD opr8a

ADD opr16a

ADD oprx16,X

ADD oprx8,X

ADD ,X

ADD oprx16,SP

ADD oprx8,SP

Add without Carry A ←(A) + (M)



–



IMM

DIR

EXT

IX2

IX1

SP2

SP1

9EDB

9EEB

hh ll

ee ff

AIS #opr8i Add Immediate Value

(Signed) to Stack Pointer SP ←(SP) + (M)

M is sign extended to a 16-bit value ––––––IMM A7 ii 2

AIX #opr8i Add Immediate Value

(Signed) to Index

H:X ←(H:X) + (M)

M is sign extended to a 16-bit value ––––––IMM AF ii 2

AND #opr8i

AND opr8a

AND opr16a

AND oprx16,X

AND oprx8,X

AND ,X

AND oprx16,SP

AND oprx8,SP

Logical AND A ←(A) & (M) 0 ––



–

IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED4

9EE4

hh ll

ee ff

ASL opr8a

ASLA

ASLX

ASL oprx8,X

ASL ,X

ASL oprx8,SP

Arithmetic Shift Left

(Same as LSL)



––



DIR

INH

IX1

SP1

9E68

ASR opr8a

ASRA

ASRX

ASR oprx8,X

ASR ,X

ASR oprx8,SP

Arithmetic Shift Right



––



DIR

INH

IX1

SP1

9E67

BCC rel Branch if Carry Bit Clear Branch if (C) = 0 ––––––REL 24 rr 3

Cb0

b7 0

b7 C

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

MOTOROLA M68HC08 Family Reference Guide 7

BCLR n,opr8a Clear Bit n in Memory Mn ←0 ––––––

DIR (b0)

DIR (b1)

DIR (b2)

DIR (b3)

DIR (b4)

DIR (b5)

DIR (b6)

DIR (b7)

BCS rel Branch if Carry Bit Set

(Same as BLO) Branch if (C) = 1 ––––––REL 25 rr 3

BEQ rel Branch if Equal Branch if (Z) = 1 ––––––REL 27 rr 3

BGE rel Branch if Greater Than or

Equal To

(Signed Operands) Branch if (N ⊕ V) = 0 ––––––REL 90 rr 3

BGT rel Branch if Greater Than

(Signed Operands) Branch if (Z) | (N ⊕ V) = 0 ––––––REL 92 rr 3

BHCC rel Branch if Half Carry Bit

Clear Branch if (H) = 0 ––––––REL 28 rr 3

BHCS rel Branch if Half Carry Bit

Set Branch if (H) = 1 ––––––REL 29 rr 3

BHI rel Branch if Higher Branch if (C) | (Z) = 0 ––––––REL 22 rr 3

BHS rel Branch if Higher or Same

(Same as BCC) Branch if (C) = 0 ––––––REL 24 rr 3

BIH rel Branch if IRQ Pin High Branch if IRQ pin = 1 ––––––REL 2F rr 3

BIL rel Branch if IRQ Pin Low Branch if IRQ pin = 0 ––––––REL 2E rr 3

BIT #opr8i

BIT opr8a

BIT opr16a

BIT oprx16,X

BIT oprx8,X

BIT ,X

BIT oprx16,SP

BIT oprx8,SP

Bit Test (A) & (M)

(CCR Updated but Operands

Not Changed) 0––



–

IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED5

9EE5

hh ll

ee ff

BLE rel Branch if Less Than

or Equal To

(Signed Operands) Branch if (Z) | (N ⊕ V) = 1 ––––––REL 93 rr 3

BLO rel Branch if Lower

(Same as BCS) Branch if (C) = 1 ––––––REL 25 rr 3

BLS rel Branch if Lower or Same Branch if (C) | (Z) = 1 ––––––REL 23 rr 3

BLT rel Branch if Less Than

(Signed Operands) Branch if (N ⊕ V ) = 1––––––REL 91 rr 3

BMC rel Branch if Interrupt Mask

Clear Branch if (I) = 0 ––––––REL 2C rr 3

BMI rel Branch if Minus Branch if (N) = 1 ––––––REL 2B rr 3

Table 2. Instruction Set Summary (Sheet 2 of 8)

Source

Form Operation Description Effect

on CCR

Address

Mode

Opcode

Operand

Cycles

VH I NZC

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

8M68HC08 Family Reference Guide MOTOROLA

BMS rel Branch if Interrupt Mask

Set Branch if (I) = 1 ––––––REL 2D rr 3

BNE rel Branch if Not Equal Branch if (Z) = 0 ––––––REL 26 rr 3

BPL rel Branch if Plus Branch if (N) = 0 ––––––REL 2A rr 3

BRA rel Branch Always No Test ––––––REL 20 rr 3

BRCLR n,opr8a,rel Branch if Bit nin Memory

Clear Branch if (Mn) = 0 –––––



DIR (b0)

DIR (b1)

DIR (b2)

DIR (b3)

DIR (b4)

DIR (b5)

DIR (b6)

DIR (b7)

dd rr

BRN rel Branch Never Uses 3 Bus Cycles ––––––REL 21 rr 3

BRSET n,opr8a,rel Branch if Bit nin Memory

Set Branch if (Mn) = 1 –––––



DIR (b0)

DIR (b1)

DIR (b2)

DIR (b3)

DIR (b4)

DIR (b5)

DIR (b6)

DIR (b7)

dd rr

BSET n,opr8a Set Bit n in Memory Mn ←1 ––––––

DIR (b0)

DIR (b1)

DIR (b2)

DIR (b3)

DIR (b4)

DIR (b5)

DIR (b6)

DIR (b7)

BSR rel Branch to Subroutine

PC ← (PC) + $0002

push (PCL); SP ←(SP) –$0001

push (PCH); SP ←(SP) –$0001

PC ←(PC) + rel

––––––REL AD rr 4

CBEQ opr8a,rel

CBEQA #opr8i,rel

CBEQX #opr8i,rel

CBEQ oprx8,X+,rel

CBEQ ,X+,rel

CBEQ oprx8,SP,rel

Compare and Branch if

Equal

Branch if (A) = (M)

Branch if (X) = (M)

Branch if (A) = (M)

––––––

DIR

IMM

IX1+

IX+

SP1

9E61

dd rr

ii rr

ff rr

CLC Clear Carry Bit C ←0 –––––0INH 98 1

CLI Clear Interrupt Mask Bit I ←0 ––0–––INH 9A 2

Table 2. Instruction Set Summary (Sheet 3 of 8)

Source

Form Operation Description Effect

on CCR

Address

Mode

Opcode

Operand

Cycles

VH I NZC

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

MOTOROLA M68HC08 Family Reference Guide 9

CLR opr8a

CLRA

CLRX

CLRH

CLR oprx8,X

CLR ,X

CLR oprx8,SP

Clear

M ←$00

A ←$00

X ←$00

H ←$00

M ←$00

0––01–

DIR

INH

IX1

SP1

9E6F

CMP #opr8i

CMP opr8a

CMP opr16a

CMP oprx16,X

CMP oprx8,X

CMP ,X

CMP oprx16,SP

CMP oprx8,SP

Compare Accumulator

with Memory

(A) –(M)

(CCR Updated But Operands Not

Changed)



––



IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED1

9EE1

hh ll

ee ff

COM opr8a

COMA

COMX

COM oprx8,X

COM ,X

COM oprx8,SP

Complement

(One’s Complement)

M ←(M)= $FF –(M)

A ←(A) = $FF –(A)

X ←(X) = $FF –(X)

M ←(M) = $FF –(M)

0––



DIR

INH

IX1

SP1

9E63

CPHX #opr

CPHX opr Compare Index Register

(H:X) with Memory

(H:X) –(M:M + $0001)

(CCR Updated But Operands Not

Changed)



––



IMM

DIR 65

75 jj ii+1

dd 3

CPX #opr8i

CPX opr8a

CPX opr16a

CPX oprx16,X

CPX oprx8,X

CPX ,X

CPX oprx16,SP

CPX oprx8,SP

Compare X (Index

Memory

(X) –(M)

(CCR Updated But Operands Not

Changed)



––



IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED3

9EE3

hh ll

ee ff

DAA Decimal Adjust

AccumulatorAfterADDor

ADC of BCD Values (A)10 U––



INH 72 2

DBNZ opr8a,rel

DBNZA rel

DBNZX rel

DBNZ oprx8,X,rel

DBNZ ,X,rel

DBNZ oprx8,SP,rel

Decrement and Branch if

Not Zero

Decrement A, X, or M

Branch if (result) ≠ 0

DBNZX Affects X Not H ––––––

DIR

INH

IX1

SP1

9E6B

dd rr

ff rr

DEC opr8a

DECA

DECX

DEC oprx8,X

DEC ,X

DEC oprx8,SP

Decrement

M ←(M) –$01

A ←(A) –$01

X ←(X) –$01

M ←(M) –$01



––



–

DIR

INH

IX1

SP1

9E6A

DIV Divide A ←(H:A)÷(X)

H ←Remainder ––––



INH 52 7

Table 2. Instruction Set Summary (Sheet 4 of 8)

Source

Form Operation Description Effect

on CCR

Address

Mode

Opcode

Operand

Cycles

VH I NZC

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

M68HC08RG/AD

10 M68HC08 Family Reference Guide MOTOROLA

EOR #opr8i

EOR opr8a

EOR opr16a

EOR oprx16,X

EOR oprx8,X

EOR ,X

EOR oprx16,SP

EOR oprx8,SP

Exclusive OR

Memory with

Accumulator A ←(A ⊕M) 0 ––



–

IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED8

9EE8

hh ll

ee ff

INC opr8a

INCA

INCX

INC oprx8,X

INC ,X

INC oprx8,SP

Increment

M ←(M) + $01

A ←(A) + $01

X ←(X) + $01

M ←(M) + $01



––



–

DIR

INH

IX1

SP1

9E6C

JMP opr8a

JMP opr16a

JMP oprx16,X

JMP oprx8,X

JMP ,X

Jump PC ←Jump Address ––––––

DIR

EXT

IX2

IX1

hh ll

ee ff

JSR opr8a

JSR opr16a

JSR oprx16,X

JSR oprx8,X

JSR ,X

Jump to Subroutine

PC ←(PC) + n(n= 1, 2, or 3)

Push (PCL); SP ←(SP) –$0001

Push (PCH); SP ←(SP) –$0001

PC ←Unconditional Address

––––––

DIR

EXT

IX2

IX1

hh ll

ee ff

LDA #opr8i

LDA opr8a

LDA opr16a

LDA oprx16,X

LDA oprx8,X

LDA ,X

LDA oprx16,SP

LDA oprx8,SP

Load Accumulator from

Memory A ←(M) 0 ––



–

IMM

DIR

EXT

IX2

IX1

SP2

SP1

9ED6

9EE6

hh ll

ee ff

LDHX #opr

LDHX opr LoadIndexRegister(H:X)

from Memory H:X ← (M:M + $0001)0––



–IMM

DIR 45

55 ii jj

dd 3

LDX #opr8i

LDX opr8a

LDX opr16a

LDX oprx16,X

LDX oprx8,X

LDX ,X

LDX oprx16,SP

LDX oprx8,SP

Load X (Index Register

Low) from Memory X ←(M) 0 ––



–

IMM

DIR

EXT

IX2

IX1

SP2

SP1

9EDE

9EEE

hh ll

ee ff

LSL opr8a

LSLA

LSLX

LSL oprx8,X

LSL ,X

LSL oprx8,SP

Logical Shift Left

(Same as ASL)



––



DIR

INH

IX1

SP1

9E68

Table 2. Instruction Set Summary (Sheet 5 of 8)

Source

Form Operation Description Effect

on CCR

Address

Mode

Opcode

Operand

Cycles

VH I NZC

Cb0

b7 0

Freescale Semiconductor, I

Freescale Semiconductor, Inc.

For More Information On This Product,

Go to: www.freescale.com

nc...

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Freescale Semiconductor Microcontrôleur

Freescale Semiconductor

Freescale Semiconductor FRDM-KL05Z Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor DEMO9S08LG32 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor HCS12 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MPC5604B Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor TWR-KV58F220M Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor ColdFire MCF5213 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor M5213EVB Instructions d'utilisation

Freescale Semiconductor

Freescale Semiconductor TWR-K21F120M Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor *KE02 Series Manuel d'instructions

Freescale Semiconductor

Freescale Semiconductor QorIQ T2080 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor Logic Zoom ColdFire LITE Series Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MCF52100 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor FRDM-KL02Z Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MPC5565 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MC9S12VR Series Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor FRDM-KL82Z Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MC68881 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor DEMO9S08SE8 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MCF52230 ColdFire Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor MMA7455L Manuel d'instructions

Freescale Semiconductor

Freescale Semiconductor PXR4030 Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor KL02 Series Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor Flexis Series Manuel utilisateur

Freescale Semiconductor

Freescale Semiconductor T4240 Manuel utilisateur

Manuels Microcontrôleur populaires d'autres marques

AMS

AMS AS7261 Demo Kit Manuel utilisateur

Novatek

Novatek NT6861 Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266 SDK Guide de configuration

Nuvoton

Nuvoton ISD61S00 ChipCorder Mode d’emploi

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manuel utilisateur

Texas Instruments

Texas Instruments Chipcon CC2420DK Manuel utilisateur

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manuel utilisateur

NEC

NEC 78GK0S/K 1+ Series Instructions d'installation et d'utilisation

Mikroe

Mikroe SEMITECH N-PLC Click Instructions d'installation et d'utilisation

Intel

Intel Agilex Manuel utilisateur

Cypress

Cypress CY4607 HX2VL Manuel utilisateur

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manuel utilisateur

Texas Instruments

Texas Instruments TMS320F2837 D Series Manuel utilisateur

CYPRES

CYPRES CY14NVSRAMKIT-001 Manuel utilisateur

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manuel utilisateur

Espressif Systems

Espressif Systems ESP8266EX Mode d'emploi

Abov

Abov AC33M8128L Manuel utilisateur

Laird

Laird BL654PA Manuel utilisateur
