Freecom FC TapeWare AIT-260i Manuel utilisateur

This document contains proprietary

information which is protected by

document may be photocopied,

reproduced or translated to another

language without prior written consent

of Sony.

The information contained in this

document is subject to change without

notice.

SONY MAKES NO WARRANTY

OF ANY KIND WITH REGARD TO

THIS DOCUMENT.

Sony shall not be liable for errors

contained herein, indirect, special,

incidental or consequential damages in

connection with the furnishing,

performance or use of this document.

Your AIT TAPE DRIVE is assigned a

Model No. ATDNA2A for regulatory

compliance certifications.

The number is indicated on the model

number label on your drive along with

the rated voltage and current.

VORSICHT

Diese Ausrüstung erfüllt die

Europäischen EMC-Bestimmungen für

die Verwendung in folgender /

folgenden Umgebung(en):

•Wohngegenden

•Gewerbegebiete

•Leichtindustriegebiete

(Diese Ausrüstung erfüllt die

Bestimmungen der Norm EN55022,

Klasse B.)

IMPORTANT SAFEGUARDS

For your protection, please read these

safety instructions completely before

operating the appliance, and keep this

manual for future reference.

Carefully observe all warnings,

precautions and instructions on the

appliance, or the one described in the

operating instructions and adhere to

them.

USE

Power Sources – This unit should be

operated only from the type of power

source indicated on the marking label.

If you are not sure of the type of

electrical power, consult your dealer or

local power company.

For the unit with a three-wire

grounding type ac plug:

If you are unable to insert the plug into

the outlet, contact your electrician to

have a suitable plug installed. Do not

defeat the safety purpose of the

grounding plug.

AC Power cord: (for AC mains

operating unit only)

The AC power cord should have

appropriate safety approvals or

marking for the country in which the

equipment will be used. Consult your

dealer or local power company.

Cleaning – Unplug the unit from the

wall outlet before cleaning or

polishing it. Do not use liquid

cleaners or aerosol cleaners.

Use a cloth lightly dampened with

water for cleaning the exterior of the

unit.

Object and Liquid Entry – Never

push objects of any kind into the unit

through openings as they may touch

dangerous voltage points or short out

parts that could result in a fire or

electric shock. Never spill liquid of

any kind on the unit.

INSTALLATION

Water and Moisture – Do not use

power-line operated units near water -

for example, near a bathtub,

washbowl, kitchen sink, or laundry

tub, in a wet basement, or near a

swimming pool, etc.

Power-Cord Protection – Route the

power cord so that it is not likely to be

walked on or pinched by items placed

upon or against them, paying

particular attention to the plugs,

receptacles, and the point where the

cord exits from the appliance.

Accessories – Do not place the unit on

an unstable cart, stand, tripod, bracket,

or table. The unit may fall, causing

serious injury to a child or an adult,

and serious damage to the unit. Use

only a cart stand tripod, bracket, or

table recommended by the

manufacturer.

Ventilation – The slots and openings

in the cabinet are provided for

necessary ventilation. To ensure

reliable operation of the unit, and to

protect it from overheating, these slots

and openings must never be blocked or

covered.

•Never cover the slots and openings

with a cloth or other materials.

•Never block the slots and openings

by placing the unit on a bed, sofa,

rug or other similar surface.

•Never place the unit in a confined

space, such as a bookcase, or built-

in cabinet, unless proper ventilation

is provided.

SERVICE

Damage Requiring Service – Unplug

the unit from the wall outlet and refer

servicing to qualified service

personnel under the following

conditions:

•When the power cord or plug is

damaged or frayed.

•If liquid has been spilled or objects

have fallen into the unit.

•If the unit has been exposed to rain

or water.

• If the unit has been subject to

excessive shock by being dropped,

or the cabinet has been damaged.

•If the unit does not operate normally

when following the operating

instructions. Adjust only those

controls that are specified in the

operating instructions. Improper

adjustment of other controls may

result in damage and will often

require extensive work by a

qualified technician to restore the

unit to normal operation.

•When the unit exhibits a distinct

change in performance - this

indicates a need for service.

Servicing – Do not attempt to service

the unit yourself as opening or

removing covers may expose you to

dangerous voltage or other hazards.

Refer to all servicing to qualified

service personnel.

Contents

SDX-460V/SDX-260V Tape Drive ......................................................................... 6

Introduction .............................................................................................................. 7

Product Features ............................................................................................... 7

Precautions ....................................................................................................... 8

Installation ................................................................................................................ 9

Jumper Setting.................................................................................................. 9

Option Switches (DIP Switch) ....................................................................... 10

Mounting Holes.............................................................................................. 12

Reconfiguring from 5.25" Model to 3.5" Model............................................ 14

Orientation...................................................................................................... 15

Attaching and Removing the Dust Cover ............................................................... 16

Attaching the Dust Cover ............................................................................... 16

Removing the Dust Cover .............................................................................. 18

Operation ................................................................................................................ 19

Location of 3 LEDs ........................................................................................ 19

Drive Operation.............................................................................................. 20

Interface Implementation........................................................................................ 22

Supported ATA Commands ........................................................................... 22

Supported ATAPI Packet Commands............................................................ 22

Specification ........................................................................................................... 23

Product Specifications.................................................................................... 23

Sony Contacts ......................................................................................................... 25

SDX-460V/SDX-260V Tape Drive

The Sony SDX-460V/SDX-260V drive is a high capacity data storage

device using Advanced Intelligent tape (AIT) technology. The SDX-460V/

SDX-260V drive achieves high data reliability through Read-After-Write,

an additional level of Error Correction Code, and other features.

The Sony SDX-460V/SDX-260V drive stores data on tape using a standard

format called AIT (Advanced Intelligent Tape) and ALDC formats.

Introduction

Product Features

*Assuming a 2.6 : 1 compression ratio.

(The compression ratio varies according to the type of data.)

•Supported Format : AIT-E Turbo, AIT-1 Turbo and AIT-1 (SDX-460V)

: AIT-E Turbo (SDX-260V)

•Burst Transfer Rate 100 MB/s Ultra DMA (mode 5)

•Large 12 MB Buffer Memory

•3.5” Standard Height, 5.25” Half Height

•ATA/ATAPI-6 Interface

•Frame Rewrite Function

•Three levels of Error Correction Code (ECC)

•High Speed search (120 times normal Read/Write speed)

•Random Read, Append Write

Data Capacity

Transfer Rate

(sustained)

SDX-460V SDX-260V

40 GB uncompressed 20 GB uncompressed

(with AIT-1 Turbo 186 m tape) (with AIT-E Turbo 98 m tape)

104 GB compressed*52 GB compressed*

(with AIT-1 Turbo 186 m tape) (with AIT-E Turbo 98 m tape)

6 MB/s uncompressed 6 MB/s uncompressed

Precautions

Installation

Avoid placing the drive in a location subject to:

–high humidity

–high temperature

– mechanical shock and vibration

–direct sunlight

Operation

• Do not move the drive while it is operating. It may cause malfunction.

•Avoid exposing the drive to sudden changes from a low to high in

temperature. This may cause water condensation to collect inside the

drive. If the ambient temperature should suddenly rise while the drive is

turned on , wait at least one hour before turning on the drive. If you

attempt to operate the drive immediately after a sudden increase in

temperature, a malfunction may occur.

• Turning off the power to the drive while it is writing to tape may cause

the tape to become unreadable. All previously negotiated parameters will

be lost, whenever power to the drive is cycled.

Transportation

•Keep the original packing materials to facilitate transportation of the

drive.

•Always remove the tape before moving the drive. After removing the

drive from the computer, repack the drive into its original packing.

Installation

Jumper Setting

Master

Slave

Cable Select

No Connection

Jumpers Drive Setting

Master

Slave

Cable Select

IDE Interface Connector

Power Connector

4 3 2 1

5V GND GND 12V

Option Switches (DIP Switch)

DIP Switch Positions

Default

OFF

12345678

DIP Switch

1Drive Mode (OFF)

2Drive Mode (OFF)

3Drive Mode (OFF)

4Drive Mode (OFF)

5Reserved (OFF)

6Periodic Cleaning Req (ON)

7DC Control (1) (ON)

8DC Control (2) (OFF)
