Freecom DLT-V4 EZ-Kit Series Manuel utilisateur

DLT-V4 EZ-KiT

iNTERNaL & ExTERNaL DLT-V4 soLuTioN / sCsi, saTa & usB / up To 320 GB

Freecom DLT-V4 including

• DLT-V4 (Device, 5.25”full height) internal or external

• SCSI or SATA cable, black & white bezel (only with

internal models), mounting screws, manual, SATA to USB

converter (with SATA models only)

• 3 years rapid exchange warranty after user/product

registration

Freecom DLT-V4 EZ-Kit Series

•Based on leading Quantum DLT-Technology

•Stores up to 320 GB* of data on one data cartridge

•Up to 72.0* GB/h data transfer rate

•Multiple connection possibilities with SCSI- and SATA-Interface

•Including DLTSageTM: monitors drive and media health

•MTBF of 250,000 hours (@ 100% duty cycle)

•Compares the data while writing (Read While Write), theoretical no verify

necessary

•WORM (Write Once Read Many) support with DLTIceTM, on normal DLT-VS1

media

•Backwards read compatible to DLT-1, DLT-VS80 and DLT-VS160

•Seven generation roadmap with up to 2-3 TB of capacity

•Supports virtually most OS and platforms e.g. Windows (NT, 2000, XP, 2003),

MAC OS, NetWare (5.x, 6.x), Linux (Kernel 2.2.5 or higher), Unix, Sun Solaris

(8, 9, 10.x), Silicon Graphics (IRIX 6.5.16), IBM AIX (5.2.0)

•Freecom DLT V4-Devices including 3 years Rapid-Exchange-Service

*all maximum capacities and data transfer rates were based on typical 2:1 hardware data compression WWW.FREECOM.COM

Ref. MM/DB/22-01-2007

*all maximum capacities and data transfer rates were based on typical 2:1 hardware data compression

1= read, 2 = write

PRODUCT SPECIFICATIONS FREECOM DLTV4 EZKIT:

AVAILABLE DEVICES DLTV4

CAPACITY

NATIVE

COMPRESSED

160 GB

320 GB*

DATA TRANSFER RATE

NATIVE

COMPRESSED

10.0 MB/s, 36.0 GB/h

20.0* MB/s, 72.0* GB/h

AVERAGE SPEED

CARTRIDGE LOAD TIME

ACCESS TIME

READ/ WRITE TAPE SPEED

SEARCH TAPE SPEED

120 sec. From BOT (formatted tape)

80 sec.

118 ips (inch per sec)

130 ips (inch per sec)

INTERFACE SCSI Ultra 160/ LVD or SATA 1.0 or USB 2.0 (with SATA to USB adapter)

BUFFER SIZE 32 MB

FORM FACTOR 5.25”, half height

RELIABILITY

MTBF

UNCORRECTABLE ERROR RATE

250,000 hours @ 100% duty cycle

1 in 10-17 Bits

COMPATIBILITY DLT-1 1, DLT-VS80 1, DLT-VS160 1, DLT-V4 1,2

POWER CONSUMPTION +5V & +12V, typical (SCSI) < 14 W, max. 16 W

ENVIRONMENTAL REQUIREMENTS

TEMPERATURE

STOCKING

OPERATION

HUMIDITY

STOCKING

OPERATION

-40° C to 66° C (-40° to 151° F)

10° C to 40° C (50° to 104° F)

10% to 95%, non condensing

20% to 80%, non condensing

ALTITUDE -152.4 meter to 9,144 meter (-500 ft to 30,000 ft)

PHYSICAL DIMENSION H X W X D

INTERNAL

ENTERNAL

4.22 x 14.76 x 22.53 cm (1.66 x 5.81 x 8.87 inches)

66.30 x 21.21 x 27.25 cm (2.61 x 8.35 x 10.73 inches)

WEIGHT

INTERNAL

ENTERNAL

1.36 kg (3.0 lb)

3.63 kg (8.0 lb)

MEDIA CAPACITY DLT-VS1 Media, 160 GB without, 320 GB with compression

CERTIFICATIONS FCC part 15 Class B (ANSI C63.4: 1992, CISPR22: 1997) & EMC Directive

(89/336/EEC) & EN55022: 1998, Class B &CISPR 22: 1997, Class B &

VCCI Class B & CNS 13438 & AS/NZS 3548 & ICES – 0003; Low Voltage

Directive (73/23/EEC) & UL 1959: 1995 & CSA C22.2 #950 & EN 60950/

A11: 1997 & IEC 60950/ A4: 1996; 2002/ 95/ EC & 2002/ 96/ EC (RoHS

and WEEE)

FC DLT-V4i EZ-Kit SCSI FC DLT-V4i EZ-Kit SATA FC DLT-V4es EZ-Kit SCSI FC DLT-V4es EZ-Kit

SATA/ USB

Art. No. EU/UK 26354 26355 26356 28927

EAN Code EU/UK 4021801263544 4021801263544 4021801263568 4021801289278

Capacity 160/ 320* GB 160/ 320* GB 160/ 320* GB 160/ 320* GB
