Franklin Wireless R526 Manuel utilisateur
Table of Contents
Care and Maintenance
Part 1. Getting to know the R526
1.1 Package Contents
1.2 Hardware Features of R526
Part 2. Setting up the R526
2.1 Charging the battery
2.2 Battery Tips
2.3 Using a LAN cable
Part 3. Using the R526
3.1 Connecting the R526
3.2 Opening the Browser Interface
3.3 Device Activation(Windows)
3.4 Device Activation(Mac users only)
Part 4. Technical Specications, Regulatory
and Safety Information, Warranty,
Trademarks & Copyright
4.1 LED Overview
4.2 Technical Specication
4.3 Safe Information
4.4 Warranty
4.5 Trademarks
4.6 Copyright
2
3
3
4
5
6
7
7
8
9
10
10
11
12
15
15
Thank you for choosing Franklin R526.
•
This manual briey explains the preparation, the process for
installing and safety precautions for using R526 router.
•
We recommend you read this manual before using the R526.
Note
•
Use your wireless device and accessories with care and in clean environment.
•
Keep the wireless device away from an open ame, dust, and dirt.
•
Protect your device and accessories from water and vapor and keep them dry.
•
Do not drop, throw or bend your device.
•
Clean your device with a piece of damp and soft antistatic cloth.
•
Do not use any chemical agents (such as alcohol and benzene),
chemical detergent, or powder to clean it.
•
Do not leave your device and accessories in a place with a considerably low
or high temperature.
•
Use only accessories of the wireless device approved by the manufacturer.
•
Contact the authorized service center for any abnormity of the device or
accessories.
•
Do not dismantle the device or accessories. Otherwise, the device and
accessories are not covered by the warranty.
2
Care and Maintenance
Part.1
Getting to know the R526
3
1.1 Package Contents
•
Franklin R526 Mobile Hotspot Router
•
QSG (Quick Start Guide)
•
AC-DC Travel Adaptor
•
Carrying Pouch
•
Li-ion 1,350mAh battery
•
RJ45 port cover
1.2 Hardware Features of R526
Factory Reset Button
Factory Reset Button
Power/Reset Button
Micro USB port
RJ45 LAN port
Air holes
4
2.1 Charging the battery
1. The battery compartment is located on the
bottom of the device.
Slide open the battery compartment door
by rmly pressing in the direction of the arrows.
2. Insert the battery by lining up the gold
contact points on the battery with the gold
contact points in the battery compartment.
Then press down gently until the battery
is seated.
3. Replace the battery cover and slide it closed
while pressing gently until it locks into place.
4. Connect the micro USB end of the AC-DC
adaptor to the micro USB port of the device.
Note
• You must have a fully charged battery the rst
time you use the R526.
•After the rst use, you may use the device while
it is connected to the AC-DC adaptor.
•When using battery power, the device lasts up to
3 hours (when connected to a single device only).
•The battery will discharge more rapidly as
additional devices access the R526.
5
2.2 Battery Tips
Warning
Use only Franklin Wireless approved batteries and chargers with your device.
The failure to use a Franklin Wireless-approved battery and charger may increase the risk that your
device will overheat, catch re, or explode, resulting in serious bodily injury, death, or property
damage.
Battery life depends on the network, signal strength, temperature, features, and accessories
you use.
•
If you connect your device to your computer using a USB data cable, the battery will charge.
However, the device will not function as a wireless access point while connected to your
computer.
•
It normally takes at least 2 hours to fully charge the battery with an AC-DC adaptor.
•
New batteries or batteries stored for a long time may take more time to charge.
•
When charging your battery, keep it near room temperature.
•
Never expose batteries to temperatures below 32°F (0°C) or above 113°F (45°C).
Never leave the device in an unattended vehicle due to uncontrollable temperatures that
may be outside the desired temperature for this device.
•
It is normal for batteries to gradually wear down and require longer charging times.
If you notice a change in your battery life, it is probably time to purchase a new battery.
6
2.3 Using a LAN cable (RJ45)
If you want to connect to RJ45 LAN cable
to the R526, plug the cable to the RJ45
slot located between Micro USB port and
power button.
