Foxtech FH336 Manuel utilisateur

FFFHHH333333666 333666XXX OOOppptttiiicccaaa lll ZZZ ooo ooo mmm CCC aaa mmm eee rrr aaa www iii ttt hhh

333 --- aaa xxx iii sss GGG iii mmm bbb aaa lll ((( EEE ttt hhh eee rrr nnn eee ttt VVV eee rrr sss iii ooo nnn )))

3-Axis Gimbal

-1-

Contents

1Introduction………………………… …2

2、………………………………………………2

3、Gimbal description…………………………………………………………3

4、Packing list………………………………………………………………………………4

5、Mounting plate dimension drawing………………………………………4

6、Installing………………………………………………………………………………………5

7、Mechanics@Electronic characteristics………………………………5

8、Working Characteristics…………………………………………………………5

9、Gimbal Hub…………………………………………………………………………6

10󱾢Control box wire connection……………………………………………7

、Gimbal …………………………………………

Tracking function(optional)

1Camera introduction……………………………………………………………………………8

2、Features…………………………………………………………………………………8

3、Specification…………………………………………………………………………………9

4、TTL Serial port control wiring instruction………………………10

、……

36X Zoom camera

Object Tracking Function

Gimbal Introduction

FH230 TIR with a 2-axis high precision gimbal. The 2-axis

gimbal can not only be controlled via PWM signal,but also serial

command. Also gimbal status like Yaw, Pitch, zoom can be obtained

by sending serial command to the gimbal via its serial port.

The gimbal has 2 smart speed modes: FAST speed and LOW

speed. Fast speed mode is used for small zooming range, which

makes the gimbal control sensitive and quick; LOW speed mode

is used for large zoom range, will enable you to target the object

more accurately.

-2-

With onboard object tracking module, FH336 TIR is able to track static or

moving target easily. Just put the object you want to track in the screen, move

the cursor to the object and lock it via controller, and then the camera will track

it automatically.

Gimbal description

!Please make sure that the motor is not stopped by any object during the rotation, if the

gimbal is blocked during rotation, please remove the

obstruction

immediately.

-3-

[1]Copper pillar

[2]Damper

[3]Upper damper board

[4]Lower

damper

board

[5]Yaw Axis Motor

[6]Roll Axis Motor

[7]Pitch Axis Motor

[8]HD zoom camera

[

]

[

]

[

]

[

]

[

]

[

]

[

]

Screw*1

M3*5mm half

round inner

sixangle screw *12

DIMENSIONS

Damper*12

Packing List

-4-

Copper pillar*4

Gimbal*1

防脱落夹*12

Lens Cover*1

unit：mm

106.00

188

54.00~102.00

（adjust unit: 4mm）

105.3

151.5

Static

Working Characterastic

Mechanics@Electronic characteristics

Installing

Pitch：-90°~+90° Roll: -85°~+85°

Yaw：-360°~+360°

Control Precision：Pitch/Roll：± 0.01° Yaw± 0.01°

-5-

voltage 3S~6S 450mA@12V Dynamic 550mA@12V

Environment -10℃~+60℃weight 945g Temperature -30℃~+80℃

Size L105.3 *W188 *H151.5mmmm mm

-6-

Gimbal Hub

unit：mm

SD CARD

HDMI

S.bus/Rx

Roll/Tx

Pitch

Ya w

Mode

Zoom

Focus

Pic/Rec

Multi

USB

1 2 3

Note：This is Ethernet Version，no HDMI output，SD CARD is at

the back of the camera.

Rj45Ethernet Version

Control box wire connection

pitch Channel，connect 3-position switch，（Speed mode）

in the normal mode to control gimbal pitch angle, 3-position

switch at high position--camera turns down, if at low

position--camea turns up, and middle position--stop.

Yaw Channel，connect 3-position switch，（speed mode）

in the normal mode to control gimbal direction，high

position--turn right, low position--turn left, middle--stop.

Mode Channel, connect knob Channel󾺭󾺩angle mode󾺪,in the

normal mode to adjust gimbal yaw and pitch control speed,

switch at low position--slowest,at high position-fastest, turn

from middle to high position quickly and return to middle

position--onekey back to center.

Zoom Control, connet 3-position switch: high position-zoom

in, middle--stop、low position--Zoom out.

Manually adjust the focus，connect 3-position switch，(not con-

nect defult auto fucus): High position--telephoto、middle--stop

low position- closefocusing.

Pic/Rec, connect 3-position switch, Low position-taking

photo,middle position--stop, high position-rec.

、

白天/夜晚切换，接三位开关：高位白天、低位夜晚、中位自动（相机

根据环境亮度判断白天还是夜晚，自动切换）

模拟视频输出。

PITCH

YA W

MODE

Zoom

FOCUS

PIC/rec

R6208

S B

Futaba

DA TA

8/ B

Digital Servo Only

For HS Mode

S.BUS

S.bus/Rx

Pitch

Ya w

Mode

Zoom

Focus

Pic/Rec

Multi

Roll/Tx

---777---

Zoom Camera

Features

The 36X zoom camera provides 1080P 30FPS full HD video

streaming, and the 36X zoom will help to capture every detail in

distance. FH336 comes with powerful night vision capability. The

camera sensor is very sensitive to IR light due to its super low

illumination.which will enable you to observe objects clearly in

the darkness.

，

-1/1.9 inch 2.38MP CMOS sensor

-36X optical zoom

-Ethernet output

-1080P/30 H.264 video recorded

-Geotagging

-Super low illumination:

[email protected](black/white),

[email protected](color),

0lux(IR)

-SNR󱈆55dB

-Support OSD

-VISUAL FX QUALITY󾺻E-flip, Black-white, mirror image,

Image-GAMMA󱾢Electronic through fog, D-WDR.

-8-

-9-

Specification

version FH336

36X 238 mp 1/1.9″CMOS

Name

image size

effective pixel

progressive scanning

8.58 mm (Type 1/ 1.9 )

2.38 Mp

Support

1920H x 1080V /25fps

1920H x 1080V /30fps

output

Type

CMOS Sensor

optical zoom

focal distance

5.8 ~210 mm± 5%36 X

support

H:WIDE 60.00° TELE 3.70 °± 5%

V:WIDE 34.58° TELE 1.99 °± 5%

field angle FOV

ApertureF No F1. 5~F 4.8 ±3%

Lens
