Foxconn 865A01 series Manuel utilisateur

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modified at any time, Foxconn does not

obligate itself to inform the user of these changes. Additionally, Foxconn does

not accept responsibility for any direct or indirect accident relating with the use

of this manual.

Trademark:

Note: refers to important information that can help you use motherboard better.

Attention: indicates that it may damage hardware or cause data loss, and tells

you how to avoid such problems.

Warning: means that a potential risk of property damage or physical injury exists.

More information:

If you want more information about our products, please visit Foxconn’s

website:

Foxconn: www.foxconnchannel.com

Version:

User manual V1.3 in English for 865A01 series

P/N:91-181-613-14-40

Symbol description:

All trademarks are the property of their respective owners.

Intel®and Pentium®are registered trademarks of Intel Corporation.

PS/2 and OS/2 are the registered trademarks of IBM, Inc.

Windows®95/98/2000/NT/XP/Me is the registered trademark of Microsoft.

Award®is the registered trademark of Award, Inc.

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:121

Item Checklist:

Thanks for your purchasing Foxconn’s 865A01 series motherboard. Please check

the package; if there are missing or damaged items, contact your distributor as

soon as possible.

865A01 series motherboard (x1)

Foxconn Utility CD (x1)

User manual (x1)

IDE ribbon cable (x1)

Floppy ribbon cable (x1)

I/O shield (x1)

S-ATA signal cable (x1) (optional)

S-ATA power cable (x1) (optional)

SPDIF cable (x1) (optional)

USB 2.0 cable (x1) (optional)

Floppy Driver disk (x1) (optional)

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:122

Declaration of conformity

HON HAI PRECISION INDUSTRY COMPANY LTD

66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,

TAIPEI HSIEN, TAIWAN, R.O.C.

declares that the product

Mainboard

865A01 G/PE series

is in conformity with

(reference to the specification under which conformity is declared in

accordance with 89/336 EEC-EMC Directive)

EN 55022/A1: 2000 Limits and methods of measurements of radio disturbance

characteristics of information technology equipment

EN 61000-3-2/A14:2000 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits for harmonic current emissions

(equipment input current <= 16A per phase)

EN 61000-3-3/A1:2001 Electromagnetic compatibility (EMC)

Part 3: Limits

Section 2: Limits of voltage fluctuations and flicker in low-

voltage supply systems for equipment with rated current

<= 16A

EN 55024/A1:2001 Information technology equipment-Immunity characteristics

limits and methods of measurement

Signature : Place / Date : TAIPEI/2003

Printed Name : James Liang Position/ Title : Assistant President

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:123

Declaration of conformity

Trade Name: FOXCONN

Model Name: 865A01 G/PE

Responsible Party: PCE Industry Inc.

Address: 458 E. Lambert Rd.

Fullerton, CA 92835

Telephone: 714-738-8868

Facsimile: 714-738-8838

Equipment Classification: FCC Class B Subassembly

Type of Product: Mainboard

Manufacturer:HON HAI PRECISION INDUSTRY

COMPANY LTD

Address: 66 , CHUNG SHAN RD., TU-CHENG

INDUSTRIAL DISTRICT, TAIPEI HSIEN,

TAIWAN, R.O.C.

Supplementary Information:

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions : (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including interfer-

ence that may cause undesired operation.

Tested to comply with FCC standards.

Signature : Date : 2003

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:124

Product Introduction

Main Features ............................................................................................. 2

865A01 Layout ........................................................................................... 5

Installation Instructions

CPU ........................................................................................................... 11

Memory ..................................................................................................... 17

Power Supply ........................................................................................... 21

Rear Panel Connectors ............................................................................. 22

Other Connectors ..................................................................................... 24

Expansion Slots ........................................................................................ 34

Jumpers ................................................................................................... 37

BIOS Description

Enter BIOS Setup ...................................................................................... 42

Main menu ................................................................................................ 42

Standard CMOS Features Setup ............................................................... 44

BIOS Features .......................................................................................... 47

Advanced BIOS Features ......................................................................... 48

Advanced Chipset Features ..................................................................... 51

Integrated Peripherals ............................................................................... 53

Power Management Setup ........................................................................ 58

PnP/PCI Configuration Setup ..................................................................... 62

PC Health Status ....................................................................................... 63

Frequency/Voltage Control ....................................................................... 65

Load Fail-Safe Defaults ............................................................................ 66

Load Optimized Defaults ........................................................................... 66

Set Supervisor/User Password ................................................................ 66

Save & Exit Setup ..................................................................................... 67

Exit Without Saving ................................................................................... 67

Table of Contents

Chapter 1

Chapter 2

Chapter 3

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:125

Driver CD Introduction

Utility CD content ...................................................................................... 69

Start to install Driver ................................................................................. 70

Install Chipset Software............................................................................ 70

Install IAA-RAID (optional) ......................................................................... 71

Install DirectX ............................................................................................ 72

Install VGA Driver (optional) ....................................................................... 73

Install USB2.0 Driver ................................................................................. 74

Install LAN Driver (For Realtek 10/100M LAN) (optional) ........................... 75

Install Intel®PRO Network Driver (For Intel®1G LAN) (optional) ................. 76

Install and Use 4- or 6- Channel Audio Function ........................................ 78

Install Norton Internet Security 2004 ....................................................... 84

Directions for Bundled Software

SuperStep ................................................................................................. 86

SuperUpdate ............................................................................................ 89

Special BIOS Feature

SuperSpeed .............................................................................................. 95

SuperBoot ................................................................................................. 97

SuperBIOS-Protect ................................................................................... 98

SuperRecovery ......................................................................................... 99

Appendix

Installing WinXP & Win2K With RAID 108

Table of Contents

Chapter

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:126

1. Attach the CPU and heatsink using silica gel to ensure full contact.

2. It is suggested to select high-quality, certified fans in order to avoid

damage to the motherboard and CPU due high temperature.

3. Never turn on the machine if the CPU fan is not properly installed.

4. Ensure that the DC power supply is turned off before inserting or re

moving expansion cards or other peripherals, especially when you

insert or remove a memory module. Failure to switch off the DC

power supply may result in serious damage to your system or memory

module.

Warning:

We cannot guarantee that your system will operate normally while

over-clocked. Normal operation depends on the over-clock capacity

of your device.

Warning:

Note:

Since BIOS programs are upgraded from time to time, the BIOS

description in this manual is just for reference. We do not guarantee

that the content of this manual will remain consistent with the ac-

tual BIOS version at any given time in the future.

Note:

The pictures of objects used in this manual are just for your reference.

Please refer to the physical motherboard.

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:127

This page is intentionally left blank

865A01-English preface-V1.3-121603.p65 2004-5-27, 18:128

Chapter

Thank you for buying Foxconn’s 865A01 series

motherboard. This series of motherboard is one of our

new products, and offers superior performance, reliability

and quality, at a reasonable price. This motherboard

adopts the advanced Intel ® 865 G/PE+ICH5/5R chipset,

providing users a computer platform with a high integra-

tion-compatibility-performance price ratio.

This chapter includes the following information:

Motherboard Features

 865A01 Layout

865A01-FOXCONN-V1.3-EN-121603.p65 2004-5-27, 18:021

Chapter 1 Product Introduction

2865A01 G/PE User Manual

Main Features

Size:

ATX form factor of 12” x 9.6”

Microprocessor:

Supports Intel® Pentium®4 Socket 478 (Willamette/Northwood/Prescott) processors

Supports Intel® Celeron®Socket 478 (Willamette/Northwood) processors

Supports FSB at 400MHz/533MHz/800MHz

Supports Hyper-Threading technology

Chipset:

Intel®Springdale Chipset: Intel®865G/PE (NorthBridge) +ICH5/5R (SouthBridge)

System Memory:

Provides four 184-pin DDR DIMM Sockets

Supports for PC3200/2700/2100

Supports for 128/256/512Mb technology up to 4GB

Supports Dual-channel DDR

Attention:

1. Use the same memory modules for Dual-Channel.

2. The memory operating frequency is 320MHz while FSB800 CPU

works with DDR333.

USB 2.0 Port:

Supports hot-Plug

Eight USB 2.0 ports (four rear panel ports, two onboard USB headers

providing four extra ports)

Supports wake-up from S1 and S3 mode

Supports USB 2.0 Protocol up to480 Mbps transmission rate

865A01-FOXCONN-V1.3-EN-121603.p65 2004-5-27, 18:022

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Foxconn Carte mère

Foxconn

Foxconn G31AX-K Manuel utilisateur

Foxconn

Foxconn NF3UK8MA Manuel utilisateur

Foxconn

Foxconn P9657AB User's Manuel utilisateur

Foxconn

Foxconn 865M01 series Manuel utilisateur

Foxconn

Foxconn 661FX7MJ Series Manuel utilisateur

Foxconn

Foxconn T70S Series Manuel utilisateur

Foxconn

Foxconn A6GMV Series Manuel utilisateur

Foxconn

Foxconn H61AP Series Manuel utilisateur

Foxconn

Foxconn D42S Manuel utilisateur

Foxconn

Foxconn X38A Manuel utilisateur

Foxconn

Foxconn 945G7AD Manuel utilisateur

Foxconn

Foxconn H67S Series Manuel utilisateur

Foxconn

Foxconn A88GMX Series Manuel utilisateur

Foxconn

Foxconn A85GM Series Manuel utilisateur

Foxconn

Foxconn 650M02 Series Manuel utilisateur

Foxconn

Foxconn 760GXK8MC Manuel utilisateur

Foxconn

Foxconn A6VMX Series Instructions d'utilisation d'origine

Foxconn

Foxconn H61MXL Series Manuel utilisateur

Foxconn

Foxconn A74GA Series Manuel utilisateur

Foxconn

Foxconn G31 MX series Instructions d'utilisation d'origine

Foxconn

Foxconn G33M Manuel utilisateur

Foxconn

Foxconn Z75A-S Manuel utilisateur

Foxconn

Foxconn G41MXP Series Manuel utilisateur

Foxconn

Foxconn K8S760MG series Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
