Formax 7200 Series Manuel utilisateur

Formax 7200 Series

Folder and Inserter

Instruction Manual

7200 Series

Mid-Volume Modular Inserting System

OPERATOR MANUAL

FIRST EDITION

12/2011

Table Of Contents

1 Introduction ........................................................................................ 3

1.1 Pictograms ........................................................................... 3

1.2 Notes on the use of this handbook ............................................. 4

2 Safety notes ........................................................................................ 4

2.1 General safety notes ................................................................ 5

2.2 End of life............................................................................... 6

3 Description of machine........................................................................ 8

3.1 Description of operation............................................................ 8

3.2 Identication of parts ............................................................... 9

4 Control Panel..................................................................................... 11

4.1 The Job Screen.......................................................................11

4.2 The Run Screen......................................................................12

4.2.1 The Run Screen displayed .............................................12

4.2.2 To adjust the Envelope Inserter settings..........................13

4.2.3 To adjust the Document Unit settings..............................15

4.3 The Menu Screen....................................................................16

5 Running an existing job..................................................................... 17

6 Switching the user............................................................................. 19

6.1 How to switch the user............................................................19

6.2 User access rights...................................................................19

7 Creating a job.................................................................................... 21

7.1 Creating the Job Settings.........................................................21

7.1.1 Dening the mailset .....................................................22

7.1.2 Dening the fold ..........................................................31

7.1.3 Dening the output settings ..........................................33

7.1.4 Saving the job.............................................................35

7.2 Creating an envelope ..............................................................36

7.3 Creating a document...............................................................38

7.4 Creating an enclosure .............................................................40

8 Loading the paper hoppers ................................................................ 41

8.1 Loading the envelope hopper....................................................41

8.2 Loading the versatile feeder hopper ..........................................42

8.3 Loading the ex folder hoppers.................................................45

8.4 Paper Control Lever ................................................................48

8.5 Daily Mail (Handfeed)..............................................................49

8.5.1 Stapling Restrictions.....................................................49

8.5.2 Using Daily Mail ...........................................................49

8.5.3 Setting the Separator Gap (see also section 8.2 ‘Adjusting the

Separator’)..........................................................................50

9 Operator Maintenance ....................................................................... 51

9.1 Cleaning the sensors...............................................................51

9.2 Clearing paper jams................................................................57

9.3 Changing the feed tyres ..........................................................59

9.4 Adjust the CIS reader..............................................................60

10 Technical Specication .................................................................... 61

10.1 Inserter head .......................................................................61

10.2 Flex tower............................................................................66

10.3 Versatile feeder ....................................................................68

10.4 Mechanical & Electrical ..........................................................69

11 Glossary of terms ............................................................................ 70

1 Introduction

With this inserter you have an advanced, medium-volume folding and inserting machine.

Its modular construction allows up to 8 feed units to be tted, with a maximum of 11 feed

trays. Its sophisticated software control optimises the order and ow of documents for

collating at the insert head before insertion into the envelope. All fold and adjustments take

place automatically according to the requirements programmed in by the operator.

In order to ensure the long usage of this machine and its components, and above all the

safe use of the machine, you must read and adhere to the operating instructions and safety

notes. Always be aware of all warnings and notes that are mounted or noted on the machine

itself.

All persons entrusted with the handling of this machine must also be familiar with the

operating manual.

Save this handbook carefully, so that the information it contains may be available at all

times.

1.1 Pictograms

General Warnings

Warning of danger from electricity or electrical shock

Information / Note indicating important information regarding the handling of

the machine.

1.2 Notes on the use of this handbook

This document contains all general information and explanatory text necessary in order to

be able to carry out the operation of the machine.

When some action is expected from the operator, this will always be explicitly stated, and

where relevant, accompanied by an illustration or graphic.

Always read through each step, so that you will obtain all of the necessary information. Do

not anticipate what you believe will follow in the handbook: It will prevent you from making

mistakes!

Chronology and Reference

This handbook is structured chronologically, and therefore ordered sequentially for the

operationally ready machine. It assumes that the machine has been installed in the

correct environment by an Authorised Service Engineer and that the operator or his or her

supervisor has had a degree of operator training.

When you are unfamiliar with the machine, it is best to read through the handbook from

beginning to end. You will be guided step by step, and in this way you can easily and quickly

have the machine in operation.

If you are already familiar with the machine, it will make thing easy if you use this

handbook as a reference work.

2 Safety notes

For your own safety and the operating safety of the machine, read the following notes

carefully before starting your machine. Always be aware of all warnings and notes that

are mounted or noted on the machine itself. Save this handbook carefully, so that the

information it contains may be available at all times.

The machine is of advanced construction and reliable in operation. Nevertheless, the device

does present hazards when operated by untrained personnel. The same applies to use that

is inappropriate and not in keeping with its intended purpose.

In not adhering to this handbook, there is the danger of

• an electrical shock,

• injuries from the intake at the rotating rollers,

• damage to the machine.

IMPORTANT: To stop the machine in an emergency,

open any cover.

Caution!

Please, read these notes with care.

Save these instructions for later use.

All notes and warnings found on the machine are to be followed.

Important! The machine must be installed only by an Authorised

Service Engineer. A safe, level position is necessary, when installing the

machine, with sufcient space all round to operate it. The machine is to be

protected from moisture. If moving the machine, ensure that the castor

brakes are off, and push on the stand, not the machine.

Ensure there is at least 1 metre of free space between the operator side of

the machine and a wall or barrier. To provide access to the mains switch, the

opposite side of the machine must be at least 150mm from a wall or barrier.

Do not place surrounding furniture or other objects where your path may be

obstructed.

The machine may only be connected to a voltage of 230V/50Hz or 115V/60

Hz,depending upon model.

The mains plug may only be connected with a socket having an installed

protective contact! The protective effect will be compromised by the use of

an extension line without a protective grounding conductor. All interruptions

of the protective grounding conductor, within or outside of the machine,

are prohibited. The device is double pole fused! When fuse failure occurs,

electrical machine parts can still carry voltage. When making the connection

to the mains power, be aware of the connection values on the nameplate.

Inspect the voltage setting on the device’s power input module. Run the

supply lines in such a way, that no-one may trip over them. Do not place any

objects upon the supply line. When the machine is not in use over a long

period of time, it should be disconnected from the power supply. In this way,

damage would be prevented in the event of excess voltage. Protect the device

from moisture. When moisture enters the machine, there is the danger of

electrical shock. Never open the machine except the top cover. For reasons

of electrical safety, the machine may only be opened by authorized Service

Agents.

Never reach into the machine when it is running! This could only occur if a

safety interlock were to fail.

The danger of injuries exists, through pulling in and crushing on the rotating

rollers. In addition, keep long hair and parts of loose clothing far from the

machine in operation. If a safety interlock fails, your Service Agent must

be contacted immediately!

In order to prevent damage to the machine, only factory authorized accessory

parts should be used.

Prior to cleaning the exterior of the machine, it should be disconnected from

the power supply. When cleaning the machine, do not use liquid or spray

cleaners, but only a cloth dampened with water.

When cleaning sensors use only non-ammable airdusters, eg. part number

9103707C. Other types may use ammable propellants, which could result in

re or explosion.

Installing

the

machine

Electrical

danger

Operating

safety

Cleaning

the

machine

Cleaning

sensors

2.1 General safety notes

In the following cases, the mains plug must be unplugged and the device

left for the authorized Service Agents:

• When the mains cable or plug is worn or damaged.

• When water or other liquid has entered the device.

• When the device does not function properly, in spite of

following the instructions provided.

• When the device has fallen down or the housing is

damaged.

• When there are noticeable differences in the normal

operation of the machine.

When repair work is carried out, only original spare parts or spare parts

corresponding to the original parts may be used.

Do not disassemble the machine any further than is described in this

handbook. Other than the top cover, the opening of the machine by

unauthorized personnel is not permitted. Repairs may only be carried out

by an authorized Service Agent.

Modication is not permitted:

For safety reasons, your own reworking and modications are not

permitted.

Please contact your Service Agent, for all questions relating to service and

repair. In this way, you ensure the operational safety of your machine.

2.2 End of life

The objectives of the European Community’s environment policy are, in particular, to

preserve, protect and improve the quality of the environment, protect human health and

utilise natural resources prudently and rationally. That policy is based on the precautionary

principle and principles that preventive action should be taken, that environmental damage

should as a priority be rectied at source.

Separate collection of waste is the precondition to ensure reuse and recycling of waste that

is generated at the disposal of electrical or electronic equipment and is necessary to achieve

the chosen level of protection of human health and the environment in the European

Community.

More particularly, certain materials and components of waste electrical and electronic

equipment needs selective treatment as their injudicious handling or disposing of on or into

land, water or air would represent a major threat to the environment and human health.

Allow

machine to

be checked

by the

Service

Agent

Spare Parts

Repairs

In order to facilitate collection and treatment separated from normal domestic waste,

electrical and electronic equipment is marked with the following logo:

Not only are you by law not allowed to dispose of the waste equipment via other waste-

streams, but we encourage you to actively contribute to the success of such collection and

to the common good and better quality of life of present and future generations.

For more information on the correct disposal of this product please contact your local dealer.

Do not mix with normal domestic waste.

Please use the subjoined return or

collection system dedicated to electrical

and electronic waste.

Equipment produced after

August 13 2005

3 Description of machine

Feeder Folder• - Mounts on the track,

either in conjunction with a tower (see

below) or as the last station. Fitted with

one feed hopper, and folds forms up to

14” long using a 2-plate folding mecha-

nism. An OMR/Barcode version is also

available.

Tower• - Mounts at the end of the

machine. Folds documents either sepa-

rately or in groups, using an accumula-

tor if required. Fitted with either one or

two feed pods, each consisting of either

2 x 500 sheet trays or 1 x 1000 sheet

tray. Uses a 3-plate folding mechanism.

An OMR/Barcode version is also avail-

able.

The machine is equipped with PC controlled

operating software from where jobs can be

programmed and run. The number of jobs

that can be programmed is limited only by

the capacity of the PC. Input is via touch-

screen monitor or keyboard/mouse.

A daily post function can be used as an

otional feature on a tower. This allows

groups of documents, stapled or loose, to

be hand-fed; they will then be folded and

inserted into an envelope. If other hoppers

are loaded, further forms can be collated.

No manual setting of the fold plates or

envelope closer is required, these being

adjusted automatically according to the

settings in the selected program.

An optional output conveyor can be speci-

ed, to replace the standard receiving tray.

This is available in two lengths.

3.1 Description of operation

The function of the machine is to fold forms

to ‘C’, ‘Z’, ‘V’ or double forward fold, ei-

ther singly, in xed multiples or in varying

groups. Enclosures such as inserts, BR enve-

lopes etc. may be added. Folded forms and

enclosures are collated in the collation area

in the inserter head before insertion into the

envelope. Forms may be inserted without

sealing the envelope for subsequent check-

ing or hand insertion.

There is a batch processing facility, allowing

a preset number of cycles to be completed

before the machine automatically stops.

The machine is OMR/Barcode compatible

for use with a mark-reading feeder or tower

folder, allowing a group of forms to be col-

lated on the track prior to folding. A number

of barcode symbologies may be read.

The machine consists of a number of mod-

ules, depending upon the build ordered -

these modules are briey described below:

Inserter head

• - Collates all documents

in a pocket before insertion, feeds the

envelope, inserts the pack and seals the

ap.

Versatile-Feeder - Feeds shortform inserts

(cards, BR envelopes, booklets etc.) onto

the track for subsequent insertion. Avail-

able as a single feeder with one feed

hopper or a double feeder with two feed

hoppers. An OMR/Barcode version (with

one feed hopper) is also available.
