Superior technology with Symphony Plus™

Value, reliability and the next level of sanitation

Exclusive features for

sanitation and serviceability

Symphony Plus ice andwater

dispensers oer superior features

and beneﬁts

Including our high-performance

ice making technology

• Industry-exclusive stainless steel jacketed

evaporator that

− eliminates wrapped refrigerant tubing,

solderand air gaps

− maximizesheat transfer and

icemakingcapacity

• Corrosion resistant design that stands up to the

most aggressive water

• Cutter style stainless steel auger with helix proﬁle

that cleanly cuts ice ﬁlm o the inner wall of the

evaporator with minimal radial loading

• Form ﬁtting evaporator insulation that reduces

condensation and maximizes eciency

• More than 30 dierent

freestanding, countertop and wall

mount models to meet the needs

of every application

• Storage capacities of 12, 25, 50

and 90 lb (5, 11, 23 and 41 kg)¹

• SensorSAFE

™

infrared ice

dispense or one-hand lever

dispense reduces chance of

cross-contamination

• Patient-preferred Chewblet

ice

• Stainless steel cabinet with

accenttrim

¹ 12, 25 and 50 models available in 230 V/50 HZ or 220 V/60 Hz.

| 2

More antimicrobial product

protection

Key ice and water components have EPA, FDA and

NSF-approved Agion

, silver-based antimicrobial

protection

, to help protect the dispensers from

biological growth

• The silver in Agion is dispersed through the

treated parts and inhibits microbial growth

by disrupting the cell functions of bacteria,

viruses, yeasts, molds and fungi

• Critical ice and water contact components that

have Agion include bin liners, bin agitation

wheels, water reservoirs, drain lines, drain

pans, drain grilles and ice and water chutes

Disclaimer: Antimicrobial protection is limited to the treated

components and does not treat water or ice.

Plus…The next level of sanitary features

Innovative drain cup system

• Consolidates all drain lines

• Improves drain line pitch

• Provides an air break to prevent drain water from

coming into contact with key ice and water dispenser

components in the event of a drain clog

• Removes easily for cleaning and sanitizing Drain cup consolidates independent component drain lines

to prevent drain water from coming into contact with ice

storage bin (B), evaporator (E) or water reservoir (R)

Automatic self-ﬂushing

• Automatically self-ﬂushes twice after every

hour of compressor run time

• Removes mineral-laden water and impurities

for better tasting ice, less maintenance and

increased reliability

| 3

Plus…Greater ease of service

Common ice machine modules

• Symphony Plus ice and water dispensers and replacement modules have the same ice machine

components to reduce spare parts inventory and standardize troubleshooting

• One module ﬁts all 25, 50 and 110 Series countertop, wall mount and freestanding Symphony Plus and

Symphony

™

dispensers shipped after March 2001

• Replacing the ice machine module saves approximately 40% over the cost of replacing the entire ice and

water dispenser of the same capacity and quality

• Machine dispenses ice in hopper even when ice machine module is removed

Plus…Sustainability beneﬁts

Quiet operation for peaceful environments

Quiet Night

™

sleep mode reduces the number of compressor

starts, especially overnight, to reduce noise

• Once the bin is full, ice must be dispensed for more than ﬁve

seconds before the ice machine restarts

• Optimal staging of fan and gearmotor masks compressor

noise on startup to reduce perceived machine noise

Energy eciency

All Symphony Plus dispenser ice machines consume 40% less

water and 20% less electricity than comparable sized cube-type

ice machines

• Dispensers meet the Consortium for Energy Eciency (CEE)

Tier 2 requirements for highly ecient ice machines

Intuitive control board

User-friendly, easy to access control board with intuitive LED diagnostics

display simpliﬁes cleaning and maintenance with instant status updates

that are easy to see.

| 4

Plus…Cleaning and sanitizing

in less than 1 hour

Plus…Easy access to

technical support

Use the QR code label located under the front cover of Symphony Plus

dispensers to quickly access all technical information.

Semi-automatic cleaning and sanitizing of the ice machine

reduces preventive maintenance time by 50 to 75%.

There are three easy steps to clean and sanitize the ice machine.

1. Press clean switch to purge all water from the evaporator

and reservoir.

2. Fill cleaning cup with ice machine cleaner until the cleaner

full light comes on.

The ice machine does the rest.

When rinsing is complete, the maintenance light will turn o.

3. Sanitize the ice transport tube by removing the

compression nozzle and inserting two Follett

SaniSponges

™

While the ice machine is automatically cleaning and sanitizing,

clean and sanitize the dispenser with the remaining solution.

For detailed instructions see the service manual.

Plus…Pressurized water

line sanitizing

Follett oers pressurized water sanitizing kits for the internal

pressurized water lines. The process will facilitate a complete

sanitization of the entire ice and water dispenser when performed in

conjunction with the standard ice machine and dispenser cleaning/

sanitizing process.

Agion is a registered trademark of Sciessent LLC.

FOLLETT HEALTHCARE, SANISPONGE, SYMPHONY PLUS and QUIET NIGHT are trademarks of Follett LLC.

CHEWBLET, FOLLETT and RIDE are registered trademarks of Follett LLC, registered in the US.

Follett reserves the right to change specifications at any time without obligation.

| 5

6700-201907 | © Follett LLC

801 Church Lane | Easton, PA 18040, USA

+1 610.252.7301 | 800.523.9361 | folletthealthcare.com

Unmatched service and support program

• Outstanding warranty

−3-year parts and labor

−5-year parts on compressor

• 7-day toll free, factory direct technical support throughout the U.S. and Canada¹

• Free local technical service seminars available throughout the U.S. and Canada¹

• Online training modules available

• Comprehensive manuals

• 10-year service part support after production ceases for discontinued models

Our commitment to quality

Our commitment to quality performance is carefully managed in every aspect of our product including design,

sourcing, manufacturing, testing, shipping, and customer service and support.

Follett ice and water dispensers are known for quality construction, durability and longevity.

Symphony Plus –over 30 dierent models

12 series¹

12 lb (5 kg) ice storage capacity

ice and water dispenser (shown) or ice-only

SensorSAFE infrared (shown) or lever dispensing

integral air-cooled 425 lb (186 kg)/day ice machine

countertop

(12CI425A-S shown

with SensorSAFE dispense)

freestanding

(12CI425A-S shown with base

stand and SensorSAFE dispense)

Exclusive features for

sanitation and serviceability

25, 50 and 110 series¹

25, 50 or 90 lb (11, 23 or 41 kg) ice storage capacity

(25 lb (11 kg) ice storage shown)

ice and water dispenser (shown) or ice-only

SensorSAFE infrared (shown) or lever dispensing

modular air-cooled or water-cooled 425 lb (186 kg)/day ice machine

countertop

(25CI425A-S shown

with SensorSAFE dispense)

freestanding

(25FB425A shown

with SensorSAFE dispense)

¹ All other markets contact authorized Follett distributor.

¹ Air-cooled, countertop 12, 25, and 50 models are available in 230 V/50 HZ or 220 V/60 Hz. Use prefix “E” for 230/50 or ”C“ for 220/60.

Example: E12CI425A or C12CI425A.
