FMS Center 2000+ Series Instructions de montage
FMS Center 2000+ Series
Hardware Installation Manual
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
p. 2
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Table of Contents
Introduction
Features & Benets
Applications
Accessories
Product SPECIFICATION
Technical Specication
Description and Mounting
Conguration
Operation Instructions
I/O PIN and Harness
Installation Procedure
RFID Antenna
GPRS Antenna
GPS Antenna
Assemble the Harness
Starting Relay Harness
Optional - Power Control Outputs Connection
Installation Verication
Troubleshooting
Speed and RPM Calibration
RPM Calibration
Speed calibration
3
3
3
4
5
6
7
8
9
10
12
13
13
13
14
14
15
16
17
17
17
17
p. 3
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Introduction
Applications
This installation manual covers the installation of the FMS Center 2000+ Series unit.This manual is for the qualied installer
and should be used to ensure a safe and functional install of the FMS Tech. product.
Our new On-Board computers FMS Center 2000+ Series are our latest state-of-the-art black boxes innovation. It is featuring
small size, easy installation and multiple functions.This series can perform tasks on vehicles, such as monitoring temperature,
engine status, fuel consumption, controlling Vehicle door, light on/o, use of seatbelt, etc.
FMS Tech. oers dedicated installation and training courses to train sta on techniques and best practices for installations.
This program will insure that the system is implemented in the most ecient manner while ensuring maximum self-
suciency for troubleshooting.
The FMS Center 2000+ is designed to work with almost all types of vehicles, trucks, buses and heavy vehicles. The system is
designed to withstand high voltage spikes found in some vehicles.
Features & Benefits
Trip Details The system records the following information for every trip: start-and-end date and time, driving time,
standing time, parking time, Driver ID, maximum and average engine RPM
Driving Violations Over speeding, over revving, harsh acceleration, not wearing seat-belt, driving for continuous hours,
without resting and driving at night
Custom Events Door open, door close, lock status, lights, air condition, engine temperature, truck container door status and
10 dierent sensor status
Accident Investigation System records vehicle speed and engine RPM every 1 second
Warning Alert Integrated buzzer
Driver Identication Contactless RFID proximity card or tag (RFID 13.56 MHz)
Device Memory 4 MB, 30 days or 1,500 trips depending on conguration, driving Violations and driving distance
Data Communication GPRS Quad band GSM 850, EGSM 900, DCS 1800, PCS 1900
p. 4
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Accessories
The FMS Center 2000+ Series Product comes with all necessary accessories and product complements. The package will
include the following:
Quantity: 1 Quantity: 1
Quantity: 1 Quantity: 1
Quantity: 1 Quantity: 1
Quantity: 1 Quantity: 1
FMS Center 2000+ Device RFID Antenna
16-Pin Main Connector (Harness Cable) Driver Access Card
15-Pin Secondary Connector (Harness Cable) GSM Antenna
Starting Relay Cable GPS Antenna
NOTE: GPRS Antenna Apply only to FMS Center 2000+ and FMS Track 2000+
p. 5
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Content Specications
Operation Voltage 9-50 volt
Rated Voltage 12-24 volt
Current Consumption 300 mA
Storage Temperature -40 °C to +85 °C
Working Temperature -20 °C to +75 °C
Humidity 95%
Clock Component Real Time Clock (RTC)
Clock Battery Lithium 3 volt
Memory 4 MB
Interrupters Relay 20 A max
Indicator Integrated Buzzer and 4 LED for unit and module
Vehicle Interface RS232, RFID, ZigBee 2.4 GHz Wireless
Dimension 127 x 90 x 38 mm
Weight 325 g
Unit Backup Battery NiMH 6 volts with internal PWM charger(optional)
GPRS Packet Up to 85.4 Mbps
Antenna Standard
Product Specification
p. 6
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Content Specications
Remote Immobilizer Yes
Ignition Relay Int.
Harsh Braking Yes
Harsh Acceleration Yes
Vibration (Graded Road) No
Movement sensor Yes
Harsh shock Yes
Idle time Yes
Online Tracking Yes
Oine Tracking Yes
No. of Events Unlimited
Tolerance conguration Yes
Buzzer Alarm Yes
Internal Battery Optional
Internal Battery Autonomy 1-5 hours
Events Conguration unlimited
No. of reports 60+
Power Consumption @12VDC 320ma
Power Spike Protection 55v
Enclosure IP54
Main Harness Cable Yes
Additional Harness Cable Optional
Cigarette Lighter Power Cable N/A
Satellite GPS Receiver GPS
Data Network Modem 2G/3G
GSM Technology Q-Band
Voice Support Optional
GPS Antenna Ext.
GSM Antenna Ext.
GPS Hot Start <6 sec
GPS Cold Start (Open Sky) < 30 sec
No. of Satellite Channels 22 SAT/12 CH
TCP/IP Yes
No. of inputs 13
Digital/Analogue 9
Frequency Inputs 3
Ignition Input 1
RS 232 1
No. of outputs 2
ZigBee 2.4 GHz Wireless Optional
Wireless 2.4 GHz Function Optional
Speed via GPS Yes
Speed via Gearbox Yes
Engine RPM Yes
Driver Identication Yes
Driver Identication Technology RFID
Panic Button Yes
Technical Specification
p. 7
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Description and Mounting
The FMS Center 2000+ Series unit should be mounted so it will not be exposed to damage from people or objects.The cables
that connect to the unit should also be routed to protect them from possible damage. The unit must be mounted where
it will not be exposed to excessive heat generated by the vehicle operation and away from moving parts. Some examples
of mounting locations include under center console, behind glove compartment, beside the main controller or under the
dashboard“Recommended”
Figure 1: FMS Center 2000+ Series unit
RFID Antenna ConnectorLED IndicatorsSIM Card Slot
GPS Antenna ConnectorGSM Antenna Connector Zigbee Antenna Connector
13
24
P1 ConnectorStarting Relay Connector P2 Connector
P1
A1 A2
Fuse 1
2
1
2
3
4
3
4
5
6
5
6
7
8
7
8
9
10
9
10
11
12
11
12
13
14
13
14
15
16
Fuse
P2
p. 8
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Configuration
Find the PIN harness and insert it into the corresponding holes of the device, and connect the wires with the suitable vehicle
lines as showing below:
Figure 2: FMS Center 2000+ Series Conguration
Antenna
GPRS/GSM
Access
Card
out 1
Auxillary
Outputs
out 2
To vehicle
speed signal
RPM1
RPM2Optional
Door, Light, etc... )
FMS Center 2000+ Conguration
“Secondary Engine”
(High speed
Freq channel)
(High speed
Freq channel)
(High speed
Freq channel)
RFID
On-Board Computer
FMS 2000
Tx
Rx
RS 232
To Vehicle
Battery Power
To Vehicle
Ignition Power
To Vehicle
Ground
Analog / Digital
Channels
Wire Harness Set
Data Receiver
Fuse
Fuse
( Break, Signal
Auxillary
Power
p. 9
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
Operation Instructions
Installations must be performed by a qualied automotive and FMS Tech certied technician.
Vehicle engine, battery and Vehicle lines must be in good working condition
All vehicle functions such as light, door, seat-belt, air condition etc. must be in good working condition (Optional)
Prepare suitable Tools ( screwdriver, pliers, wire stripper, solder, multi-meter, wrench set, Electrical tape or shrink
tubing and cable tie).
2-(7.5 amp) fuses 50-volt.
Do not install it in an environment which is over GSM performance index, and please pay attention to x the antennas
in an appropriate position with good signals.
Pay attention to make installation location preventing water and dust.
Find the 16 PIN harness and insert it into the corresponding holes of the device, and connect the wires with the suitable
vehicle lines .
Connect the GPS and GSM antenna to the right connector, and nd appropriate place and x the antennas to make sure
it receives signals very well.
p. 10
Copyright © 2017 | All Rights Reserved | Fleet Management Systems & Technologies
FMS Center 2000 + Series | Hardware Installation Manual
I/O Pin and Harness
Figure 3: FMS Center 2000+ Series I/O System
(Colors in Diagram Represent wire color)
Power (Vehicle Battery)
Power (Vehicle Ground)
GND
CAN_H
Speed
Ignition
A/D IN 4
A/D IN 7
A/D IN 9
Non-Regulated
+3V3 Auxillary Power
(100mA)
Output 1
Not Used
Not Used
Not Used
RS232 - Data In
RS232 - Data Out
RPM 2
A/D IN 1
A/D IN 3
RPM 1
A/D IN 5
CAN_L
Output 2
Regulated
A/D IN 8
Not Used
Not Used
Not Used
GND
A/D IN 6
Starting Engine
A/D IN 2
P1
A1 A2
Fuse 1
2
1
2
3
4
3
4
5
6
5
6
7
8
7
8
9
10
9
10
11
12
11
12
13
14
13
14
15
16
Fuse
P2
