Fluke 62 MAX Manuel utilisateur

62 MAX/62 MAX +

Infrared Thermometer

Users Manual

Introduction

The Fluke 62 MAX and 62 MAX + Infrared Thermometers (the Product) can determine the

surface temperature by measuring the amount of infrared energy radiated by the target’s

surface. Note that the Japanese models indicate Celsius only.

WWarning

Read all safety information before you use the Product.

62 MAX/62 MAX +

Users Manual

Safety Information

A Warning identifies conditions and procedures that are dangerous to the user. A Caution

identifies conditions and procedures that can cause damage to the Product or the equipment

under test.

Table 1 tells you about symbols used on the Product and in this manual.

*WWarning

To prevent eye damage and personal injury:

•Read all safety Information before you use the Product.

•Do not use the Product if it operates incorrectly.

•Use the Product only as specified, or the protection supplied by the

Product can be compromised.

•Before you use the Product, inspect the case. Do not use the Product if it

appears damaged. Look for cracks or missing plastic.

Infrared Thermometer

Safety Information

•See emissivity information for actual temperatures. Reflective objects

result in lower than actual temperature measurements. These objects

pose a burn hazard.

•Do not look directly into the laser with optical tools (for example,

binoculars, telescopes, microscopes). Optical tools can focus the laser

and be dangerous to the eye.

•Do not look into the laser. Do not point laser directly at persons or

animals or indirectly off reflective surfaces.

•Replace the batteries when the low battery indicator shows to prevent

incorrect measurements.

•Do not use the Product around explosive gas, vapor, or in damp or wet

environments.

•Use the Product only as specified or hazardous laser radiation exposure

can occur.

62 MAX/62 MAX +

Users Manual

Table 1. Symbols

Symbol Meaning Symbol Meaning

WRisk of danger. Important

information. See Manual. ~

Do not dispose of this product as

unsorted municipal waste.

*Warning. Laser. PConforms to European Union

directives.

Battery Conforms to relevant Australian

standards.

Infrared Thermometer

Maintenance

WCaution

To avoid damage to the Product, do not leave the thermometer on or near

objects of high temperature.

How to Change the Battery

To install or change the AA IEC LR06 battery, open the battery compartment and replace the

battery as shown in Figure 16.

How to Clean the Product

Use soap and water on a damp sponge or soft cloth to clean the Product case. Carefully wipe

the surface with a moist cotton swab. The swab may be moistened with water. See Figure 17.

62 MAX/62 MAX +

Users Manual

Specifications

62 MAX 62 MAX +

Temperature Range -30 °C to 500 °C

(-22 °F to 932 °F) -30 °C to 650 °C

(-22 °F to 1202 °F)

Accuracy

≥0 °C: ±1.5 °C or ±1.5 % of

reading, whichever is

greater

(≥32 °F: ±3 °F or ±1.5 % of

reading, whichever is

greater)

≥-10 °C to <0 °C: ±2 °C

(≥14 °F to <32 °F: ±4 °F)

< -10 °C: ±3 °C

(<14 °F: ±6 °F)

≥0 °C: ±1 °C or ±1 % of

reading, whichever is

greater (≥32 °F: ±2 °F or

±1 % of reading, whichever

is greater)

≥-10 °C to <0 °C: ±2 °C

(≥14 °F to <32 °F: ±4 °F)

< -10 °C: ±3 °C

(<14 °F: ±6 °F)

Response Time (95 %) <500 ms (95 % of reading) <300 ms (95 % of reading)

Spectral Response 8 to 14 microns

Emissivity 0.10 to 1.00

Infrared Thermometer

Specifications

Optical Resolution 10:1

(calculated at 90 % energy) 12:1

(calculated at 90 % energy)

Display Resolution 0.1 °C (0.2 °F)

Repeatability (% of reading) ±0.8 % of reading or ±1.0 °C

(2 °F), whichever is greater ±0.5 % of reading or ±0.5 °C

(1 °F), whichever is greater

Power 1 AA IEC LR06 Battery

Battery Life 10 hours with laser and

backlight on 8 hours with laser and

backlight on

Weight 255 g (8.99 oz)

Size (175 x 85 x 75) mm (6.88 x 3.34 x 2.95) inches

Operating Temperature 0 °C to 50 °C (32 °F to 122 °F)

Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F), (without battery)

Operating Humidity 10 % to 90 % RH non-condensing @ 30 °C (86 °F)

Operating Altitude 2000 meters above mean sea level

Storage Altitude 12,000 meters above mean sea level

62 MAX/62 MAX +

Users Manual

IP Rating IP 54 per IEC 60529

Drop Test 3 meters

Vibration and Shock IEC 68-2-6 2.5 g, 10 to 200 Hz, IEC 68-2-27, 50 g, 11 ms

EMC EN 61326-1:2006 EN 61326-2:2006

Standards and Agency Approval

Compliance.............................................EN/IEC 61010-1: 2001

Laser Safety............................................FDA and EN 60825-1 Class II

Infrared Thermometer

The Product

1 2
