DESCRIPTION

The Fireye®BurnerLogix™ System is a microprocessor based burner management control system

designed to provide the proper burner sequencing, ignition and flame monitoring protection on auto-

matically ignited oil, gas, and combination fuel burners. In conjunction with limit and operating con-

trols, it programs the burner/blower motor, ignition and fuel valves to provide for proper and safe

burner operation. Through SMART LED’S, the control provides current operating status and lockout

information in the event of a safety shutdown. Optional VFD and LCD displays are available that

may be either plugged in or mounted remotely to give full language descriptors of current status and

diagnostic lockout information. Refer to BurnerLogix PROGRAMMER SELECTION later in this

document for the various combinations of programmer and display modules.

A complete BurnerLogix system includes the YB110 (YB230) chassis equipped with the type of

flame amplifier required for the application, appropriate flame detector, plug-in programmer mod-

ule, wiring base and optional alpha-numeric display. Interchangeable programmer modules allow for

complete versatility in selection of function, timing and flame failure response times.

The optional alpha-numeric display has 2 lines by 16 characters per line. It is available in either vac-

uum fluorescent or liquid crystal formats. The advantage of VFD is high brightness and extended

temperature range down to –40°F. Both displays contain a fully functional keypad. You can easily

scroll through the various menus to view the current operating status, review programmer configura-

tion, and lockout history. When mounted remotely, the displays provide NEMA 4x(IP66) protection.

An advantage of the BurnerLogix control family is the ability to set many of the operating parame-

ters associated with proper and reliable burner operation allowing inventory of various programmer

types to be kept to a minimum.

The YB110 (YB230) is a chassis/flame amplifier module complete with mounting screws and blank

display module. The display module (BLV512 (vfd) or BLL510 (lcd)), if required, must be ordered

separately. Interchangeable YP programmer modules allow for complete versatility in selection of

control function, timing, and flame scanning means. Functions such as pre-purge time, recycling or

non-recycling interlocks, high fire proving interlock, and trial for ignition timing of the pilot and

main flame are determined by the programmer module. The BurnerLogix system can be used with

ultra-violet, auto-check infrared, flame rod, self-check ultra-violet flame scanners or direct coupled

integrated scanners by choosing the proper chassis/flame amplifier module.

YB110/YB230 FIREYE®

BurnerLogiX™

MICROPROCESSOR-BASED

INTEGRATED BURNER

MANAGEMENT CONTROL

BL-1001

August 7, 2018

APPROVED



Wiring bases for the BurnerLogix control are available pre-wired with 4 foot (1.2m) lead wires color

coded and marked for easy installation or with an integral terminal block capable of a accepting up to

2 X 14 AWG wires. The wiring base terminal block is available with knockouts for conduit or open

ended for cabinet mounting. The pigtail wiring base is 4" X 5" (101.6mm x 127mm) and the terminal

block wiring base is 4" X 7" (101.6mm x 177.8mm).

Additional functions of the BurnerLogix system include:

•A non-volatile memory allows the control to remember its history and present position even

when power is interrupted.

•A consistent flame signal read-out via display module or 4-20 mA output.

•Read-out of main fuel operational hours and complete cycles via display module.

•Modbus communications via RS485 multi-drop link.

•Proof of fuel valve closure during the off cycle.

•Burn-in time of program parameters occurs after 8 hours of main valve on time.

•A run/check switch allows the operator to stop the program sequence in any of four

different positions (Purge, PTFI, MTFI or Auto).

•Remote Display mounting with NEMA 4 protection.

•Remote Reset.

•Programmable communication baud rate allows for DCS compatibility.

•Keypad selectable language readout.

•Revert to pilot can increase burner turn down.

•Additional terminals provided for applications requiring additional inputs and outputs.

CAUTION: While programmers are mechanically interchangeable in that they mate with a

common chassis/amplifier module, you must select the correct model for your application.

Inappropriate application of a control can result in an unsafe condition hazardous to life

and property. Selection of a control for a particular application must be made by a compe-

tent professional, such as a boiler/burner service technician licensed by a state or other gov-

ernment agency.

NOTICE: This equipment generates and can radiate radio frequency energy, and if not

installed and used in accordance with the instruction manual may cause interference to

radio communications. It has been tested and found to comply with the limits for a Class A

computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to

provide reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area may cause interference in

which case the user, at his own expense, will be required to take whatever measures which

may be required to correct the interference.

TABLE OF CONTENTS

BURNERLOGIX SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

PART NUMBERS ANDAPPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

ORDERING INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

INSTALLATION PROCEDURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

WIRING BASE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

PTFI*MTFI TIMINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

LED INDICATOR LIGHTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

REPLACEABLE FUSE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

DESCRIPTION OF FUNCTIONS OF OPERATING CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

SETTING PROGRAMMER PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

KEYPAD DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

PROGRAM SET UP SUB-MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

TO VIEWAND MODIFY A PROGRAMMABLE PARAMETER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

FLAME SCANNERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

INSTALLATION - UV SCANNERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

OPERATION — 45UV5 & 55UV5 SELF-CHECKING UV SCANNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

WIRING - UV SCANNERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

INSTALLATION—INFRARED SCANNER TYPE 48PT2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

OPERATION - IR LEARN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

INSTALLATION - 69ND1 FLAME ROD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

INSTALLATION - 85 SERIES PHOENIX SCANNER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

INSTALLATION - 95 SERIES INSIGHT SCANNERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

SYSTEM INFO SUB-MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

SYSTEM OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

YP100 OPERATING SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

START-UP (NORMAL CYCLE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

YP200 OPERATING SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

YP300 OPERATING SEQUENCE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

YP138 PROGRAMMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

LOCKOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

SAFETY SHUTDOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

DIAGNOSTIC MESSAGES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

RESETTING THE CONTROL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

LOCKOUT CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

LOCKOUT HISTORY SUB-MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

COMMUNICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

MESSAGE FORMAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

MODBUS MESSAGE TABLE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

INPUTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

OUTPUTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

EXPLANATION OF LOGSTAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

BURNERLOGIX MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

INTERLOCK ANNUNCIATOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

OPERATIONAL FEATURES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

4-20 mA TEST JACKS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

CHECK-RUN SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

OPERATIONAL TEST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

TEST CHECKOUT PROCEDURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

SUGGESTED GROUNDING RULES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63



Table of Figures

FIGURE 1. BURNERLOGIX ORDERING INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

FIGURE 2. WIRING BASE DETAILS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

FIGURE 3. YP110 PROGRAMMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

FIGURE 4. KEYPAD DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

FIGURE 5. BURNERLOGIX MENU STRUCTURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

FIGURE 6. MAIN MENU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

FIGURE 7. FLAME SCANNERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

FIGURE 8. AIMING YOUR SCANNER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 24

FIGURE 9. TYPICAL SCANNER INSTALLATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

FIGURE 10. UV SELF CHECK SCANNER OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

FIGURE 11. SCANNER INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

FIGURE 12. PHOENIX WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

FIGURE 13. BURNERLOGIX TYB110DC/YB230DC WITH 85UVF4-1QDWR SCANNER. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

FIGURE 14. INSIGHT WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

FIGURE 15. CONNECT BURNERLOGIX & INSIGHT I . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

FIGURE 16. SYSTEM INFO SUB-MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

FIGURE 17. YP100 OPERATING SEQUENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

FIGURE 18. YP200 OPERATING SEQUENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

FIGURE 19. YP300 OPERATING SEQUENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

FIGURE 20. BURNERLOGIX WIRING DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

FIGURE 21. YP300 WIRING DIAGRAM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

FIGURE 22. YP138 WIRING DIAGRAM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

FIGURE 23. LOCKOUT HISTORY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

FIGURE 24. BOTTOM VIEW COMMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

FIGURE 25. DEFAULT WIRING FOR YZ300 INTERLOCK ANNUNCIATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

FIGURE 26. BOTTOM VIEW 4-20 mA JACKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

FIGURE 27. TEST JACKS (4-20 mA) VS. FLAME STRENGTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

FIGURE 28. CHECK RUN SWITHCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

FIGURE 29. PILOT FLAME TEST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Table of Tables

Table 1: OPERATING TEMPERATURE LIMITS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Table 2: LOAD RATINGS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Table 3: AGENCYAPPROVALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Table 4: APPLICABLE BULLETINS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table 5: ORDERING INFORMATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table 6: PROGRAMMER MODULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Table 7: BURNERLOGIX DISPLAYS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 8: BURNERLOGIX WIRING BASES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 9: BURNERLOGIX ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 10: SCANNER SELECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Table 11: PRE-WIRED WIRING BASE, P/N 60-2810-1 (shown for 120 VAC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Table 12: BURNERLOGIX PROGRAMMER SELECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Table 13: PTFI & MTFI TIMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Table 14: LED INDICATORS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Table 15: MODIFIABLE PARAMETERS LOCATED IN PROGRAM SETUP MENU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Table 16: PHOENIX SCANNER CABLE COLOR CODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Table 17: DIAGNOSTIC MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Table 18: LED CODES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Table 19: MESSAGE FORMAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Table 20: MODBUS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Table 21: MODBUS MESSAGE TABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Table 22: INPUTS AND OUTPUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Table 23: YZ300. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Table 24: LOGSTAT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Table 25: BURNERLOGIX MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Table 26: DIAGNOSTIC MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Table 27: ANNUNCIATOR MESSAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

..BURNERLOGIX SPECIFICATIONS

Supply Voltage:

YB110 120 VAC (+10%, -15%) 50/60 Hz

YB230 230 VAC (+10%, -15%) 50/60 Hz

Power Consumption:

25 VA

Temperature Rating:

-40°C (-40°F) to +60°C (140°F)

Protection Category:

YB110 (YB230) control NEMA 1 (IP01)

Display, remote mounted NEMA 4X (IP66)

Unit Dimensions:

Wiring base 60-2810-1 - 4.0" (101 mm) W x 5.0" (127mm) H

Wiring base 60-2812-1, 60-2814-1 - 4.0" (101 mm) W x 7.0" (178 mm) H

Shipping Weight:

YB110 (YB230) Approx. 3.2 lbs. (1.45kg)

Table 1: OPERATING TEMPERATURE LIMITS

CONTROL MAXIMUM MINIMUM

YB110, YB230 140°F 60°C -40°F -40°C

YP Programmers 140°F 60°C -40°F -40°C

BLV512, VFD Display 140°F 60°C -40°F -40°C

BLL510, LCD Display 140°F 60°C -4°F -20°C

Scanner UV1A, UV2, UV8A, UV90, 45UV3 200°F 93°C -40°F -40°C

45UV5-1005, 45UV5-1105

45UV5-1007, 45UV5-1009

55UV5-1007, 55UV5-1009

200°F 93°C -40°F -40°C

48PT2 140°F 60°C -40°F -40°C

Flame Rod (Tip 2460°F) 1500°F 816°C -40°F -40°C

Humidity: 90% R.H. (Non-condensing)

Phoenix 85 Series 150°F 65°C -40°F -40°C

InSight 95 Series 150°F 65°C -40°F -40°C



Table 2: LOAD RATINGS

Combination of fuel and igniter terminals

Composition of each combination

Maximum connected load must not exceed 2000 VA

ELECTRICAL RATINGS

VA ratings (not specified as pilot duty) permit the connection of transformers and similar devices

whose inrush current is approximately the same as their running current.

VA Pilot Duty ratings permit the connection of relays, solenoid valves, lamps, etc. whose total oper-

ating load does not exceed the published rating and whose total inrush current does not exceed 10

times the rating.

Running and locked rotor ratings are intended for motors. VA and VA Pilot Duty loads may be added

to a motor load provided the total load does not exceed the published rating.

Terminal Typical Load A. Maximum Rating

@120V-50/60 Hz

B. Maximum Rating

@230V-50/60 Hz

C. Alternate Rating

M Burner/Blower Motor 9.8 F.L.A. *

58 L.R.A.

4.0 F.L.A. *

20 L.R.A.

240 VA Pilot Duty

(Motor Starter Coil)

10-11-12-X Modulator 125 VA Pilot Duty

A Alarm 50 VA Pilot Duty

Terminal ratings may be selected from either column A or C for 120 VAC or from either column B or C for 30 VAC:

(select the rating from the column which best applies to the connected load on that terminal).

* F.L.A. = full load amps; L.R.A = locked rotor amps

Combination No. Pilot Fuel

Trm 6

Main

Trm 7

Ignition

Trm 5

Delayed Valve

Trm W

1C E No Load No Load

2B E No Load No Load

3No Load E No Load B

4E E A No Load

5No Load E A E

6D E A No Load

7DDAD

8No Load D A No Load

AB C D E

4.5A Ignition

@120 VAC

50 VA Pilot Duty

plus 4.5A ignition@

120 VAC

180 VA Ignition plus

motor valves with: 660

VA inrush, 360 VA

open, 250 VA hold.

2A Pilot Duty

@120 VAC

65 VA Pilot Duty plus

Motor valves with: 700

VA open 250 VA hold.

2.2A Ignition

@230 VAC

50 VA Pilot Duty

plus 2.2A ignition

@230 VAC

1A Pilot Duty

@230 VAC

CAUTION: Published load ratings assume that no contact will be required to handle inrush

current more often than once in 15 seconds. Using control switches, solenoid, relays, etc.

which chatter lead to premature failure. Run through a test operation (with fuel shut off)

following the tripping of a circuit breaker, a blown fuse, or any known instance of chattering

of any external current consuming devices.

APPROVALS

Underwriters Laboratories Inc.:

MCCZ File MP1537

Controls, Primary Safety - Listed

MCCZ2 File MP1537

Controls, Primary Safety - Component

MCCZ7 File MP1537

Controls, Primary Safety Certified for Canada

MCCZ8 File MP1537

Controls, Primary Safety Certified for Canada - Component

Factory Mutual: Approved

Acceptable by: Industrial Risk Insurers (I.R.I.)

CE: Gas Appliances

Gas Appliance Directive: 90/396/EEC

Low Voltage Directive: 73/23/EEC

EMC Directive: 89/336/EEC

GASTEC: 0063BT1754

(EN298, 2003; EN230, 2005)

NOTICE: This equipment generates and can radiate radio frequency energy, and if not

installed and used in accordance with the instruction manual may cause interference to

radio communications. It has been tested and found to comply with the limits for a Class A

computing device pursuant to Subpart J of part 15 of FCC Rules, which are designed to

provide reasonable protection against such interference when operated in a commercial

environment. Operation of this equipment in a residential area may cause interference in

which case the user, at his own expense, is required to take whatever measures which may be

required to correct the interference.



PART NUMBERS AND APPROVALS

Table 3: AGENCYAPPROVALS

BurnerLogix

Chassis/Flame Amp. Module

YB110UV XXX

YB110UVSC XXX

YB110IR XXXX

YB110IR2 XXXX

YB110FR XXX

YB110DC XXX

YB230UV X

YB230UVSC X

YB230IR XX

YB230IR2 XX

YB230FR X

YB230DC X

BurnerLogix Programmer Module

YP100 XXX

YP102 XXX

YP138 XXX

YP118 XXX

YP183 XXX

YP200 XXX

YP202 XXX

YP300 XXX

YP302 XXX

YP113 XXXX

YP115 XXXX

BurnerLogix Displays

BLV512 XXXX

BLL510 XXXX

BurnerLogix Wiring Bases

60-2810-1 XX X

60-2812-1 XXX

60-2814-1 XXX

X = CERTIFICATION IN HAND

APPROVED

Table 4: APPLICABLE BULLETINS

Table 5: ORDERING INFORMATION

Table 6: PROGRAMMER MODULES

Note: All programmers: when used with the YB110DC or YB230DC, the FFRT is 0.2 seconds

Programmers, Non-recycle Operation

YP-1001Programmers, Recycle Operation

Programmers, Non-modulating

Displays BD-5001

Wiring base installation, 60-2810-1 133-676

Wiring base installation, 60-2812-1 133-677

Wiring base installation, 60-2814-1 133-677

BurnerLogix Chassis/Flame Amplifier Module

YB110UV 120 VAC input with UV non self-check amplifier

YB110UVSC 120 VAC input with UV self-check amplifier

YB110IR 120 VAC input with IR auto-check amplifier

YB110IR2 120 VAC input with IR auto-check amplifier (special application only -consult factory)

YB110FR 120 VAC input with flame rectification amplifier

YB110DC 120 VAC input with direct coupled amplifier

YB230UV 230 VAC input with UV non self-check amplifier

YB230UVSC 230 VAC input with UV self-check amplifier

YB230IR 230 VAC input with IR auto-check amplifier

YB230IR2 230 VAC input with IR auto check (special application only-consult factory)

YB230FR 230VAC input with flame rectification amplifier

YB230DC 230VAC input with direct coupled amplifier

BurnerLogix Programmer Modules

YP100 Keypad selectable parameters, non-recycle operation, modulation, open damper proving, 4 second FFRT

YP102 Keypad selectable parameters, non-recycle operation, modulation, open damper proving, 2 second FFRT

YP113 Keypad selectable parameters, non-recycle operation, modulation, open damper proving, 1 second FFRT

YP115 Keypad selectable parameters, non-recycle operation, modulation, open damper proving, 1 second FFRT

YP118 Keypad selectable parameters, non-recycle operation, modulation, open damper proving, indefinite pilot hold,

revert to pilot from auto, 1 second FFRT

YP138 Keypad selectable parameters, non-recycle operation, modulation, open damper proving, voltage on terminal 16

is indefinite pilot hold during lightoff, applied voltage on term 16 is revert to pilot from auto, 4 second FFRT

YP183 Same as YP138, except, removal of voltage on terminal 16 will suspend pilot hold during lightoff sequence. Ter-

minal W used for purge complete.

YP200 Keypad selectable parameters, recycle operation, modulation, 4 second FFRT

YP202 Keypad selectable parameters, recycle operation, modulation, 2 second FFRT

YP300 Keypad selectable parameters, recycle operation, low fire start, early spark termination, 4 second FFRT

YP302 Keypad selectable parameters, recycle operation, low fire start, early spark termination, 2 second FFRT



Table 7: BURNERLOGIX DISPLAYS

Table 8: BURNERLOGIX WIRING BASES

Table 9: BURNERLOGIX ACCESSORIES

BurnerLogix Displays

BLV512 Display, 2 line X 16 characters, VFD, with cable, NEMA 4

BLL510 Display, 2 line X 16 characters, LCD, with cable, NEMA 4

BurnerLogix wiring bases

60-2810-1 Pigtail wires, 4 foot long, 4"W x 5"H

60-2812-1 Closed base with terminal block and knockouts, 4"W x 7"H

60-2814-1 Open base with terminal block. 4"W x 7"H

BurnerLogix Accessories

129-178-4 Kit, remote mounting, BurnerLogix display, 4 ft. cable, provides NEMA 4 protection

129-178-8 Kit, remote mounting, BurnerLogix display, 8 ft. cable, provides NEMA 4 protection

BLD500 Blank display module, included with YB module

IT1000 Alarm annunciation system using wireless technology

PPC6000 Parallel Positioning System

61-5745-3 Shutter drive assembly for redundant self-check scanners

Table 10: SCANNER SELECTION

FIREYE P/N DESCRIPTION USE WITH CHASSIS BULLETIN

48PT2-1003

48PT2-9003

48PT2-1007

48PT2-9007

4-263-1

Infrared 1/2" straight mount 96"(2438mm) TC-ER cable

Infrared 1/2" 90° angle mount 96" (2438mm) TC-ER cable

Infrared 1/2" straight mount 48" (1219mm) TC-ER cable

Infrared 1/2" 90° angle mount 48" (1219mm) TC-ER cable

Replacement photo detector

YB110IR

YB230IR

YB110IR2

YB230IR2

SC-103

UV1A3

UV1A6

UV8A

UV2

UV2A6

45UV3-1050

UV90-3

UV90-6

UV90-9

UV 1/2" straight 36" (915mm) TC-ER cable

UV 1/2" straight 72" (1830mm) TC-ER cable

UV 1/2" 90° head 72" (1830mm) no armor flex

UV 3/8" straight 36"(915mm) TC-ER cable

UV 3/8" straight 72" (1830mm) TC-ER cable

UV 3/4" cast aluminum housing 96" (2438mm) unshielded leads

UV 90° lateral view with 36" (915mm) flex conduit

UV 90° lateral view with 72" (1830mm) flex conduit

UV 90° lateral view with 108" (2745mm) flex conduit

YB110UV

YB230UV

SC-102

45UV5-1007

45UV5-1009

4-314-1

Self-check UV 1" BSP threads, 102-264VAC

Self-check UV 1" NPT threads, 102-264VAC

Replacement UV tube

YB110UVSC

YB230UVSC SC-101

69ND1-1000K4

69ND1-1000K6

69ND1-1000K8

Flame rod, 12”, 1/2” mount

Flame rod, 18”, 1/2” mount

Flame rod, 24”, 1/2” mount

YB110FR

YB230FR

SC-103

45UV5-1005

45UV5-1105

Self-check UV 1" NPT threads, 61-5745-3 required

Self-check UV 1" BSP threads, 61-5745-3 required

YB110UVSC

YB230UVSC

133-645

55UV5-1007

55UV5-1009

Self-check UV 1" BSP, 102-264VAC, Suitable for hazardous locations.

Self-check UV 1" NPT, 102-264VAC, Suitable for hazardous locations.

YB110UVSC

YB230UVSC

SC-106

PHOENIX

Autres manuels pour BurnerLogiX YB110

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Fireye Matériel informatique

Fireye

Fireye NXM2G-2 Manuel utilisateur

Fireye

Fireye BurnerLogiX ZB110 Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

Intel

Intel NUC 12 Pro Manuel utilisateur

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur
