Support PIP - PIP technology unaltered state in the original image, the other input of the same or
different overlay images. LED Video Processor PIP function, not only can be adjusted overlay size,
location, borders, etc. You can also use this feature to achieve Picture outside Picture (POP),
dual-screen display.
One key black - black screen during a performance is an essential operation, during a performance, you
need to close the image output, you can use the black buttons for fast black.
Support Freeze - During playback, you may need to freeze the current picture together to achieve
"pause" screen. Freeze the screen, the operator can also change the current input selection or change
lines, etc., to avoid background operation affect performance results.
PART and FULL fast switching - LED Video Processor a simple and functional operation of the
interception part of the screen and full-screen operation, any one input channel can be independently set
different interception effect, and each channel is still able to seamlessly switch. Users can arbitrarily set
the current channel interception of part of the screen size and position, and the other channels remain
unchanged intercept method. When switching between channels most of its screen or full screen function
follow.
Preset -LED Video Processor user presets with 4 groups, each user can store all user default setup
parameters, use the LOAD preset shortcut keys you can quickly recall. Can achieve rapid field parameter
backup and recall function
Equal and unequal splicing - splicing is LED Video Processor important part, which can be achieved
equal splicing and unequal splicing, splicing on greatly satisfy users' needs. On multiple processors to
achieve frame synchronization, 0 delay, no tail and other technologies to enable smooth performance
perfect. Unequal spliced portion of the output is the same with the picture settings, the user can read the
following chapters for instructions.
30bit scaling technology - LED Video Processor using a dual-core image processing engine, a single
core can process 30 image scaling technology to achieve pixel output from 64 to 2560, while achieving
10 times the image to enlarge the output, ie, the maximum screen more than 25,600.
Brightness adjustment technology - LED Video Processor unique brightness adjustment function,
reduce the brightness solved after layering lost, so that more true color reproduction.
Saved directly technology - Saved directly technology to solve the user's settings and manually save
tedious process, that users of co-ordination or adjust parameters without the implementation of artificial
save operation, LED Video Processor user parameters automatically stored in EEPROM, even if the
power When turned on, the parameters before power remains in the device.
ACC &ACM image filtering - LED Video Processor using ACC and ACMimage filtering engine, handling
each color, nonlinear filtering effect of the lowest loss rate of the image, restore the color fidelity.
Support the upper RS232 interface control - can use computer to connect processor to use PC
software to set the output resolution, brightness, audio switch, switch signal source, etc.......
