FCC BBQ FCC-A-10035 Mode d’emploi

OUTDOORUSEONLY

FORUSEWITHGASBBQ

Sare  u  cookin!

Rotisserie Kit

60-90 CMWITHACMOTOR

INSTRUCTION MANUAL & MAINTENANCE FCC-A-10035

Parts

1. Handle ................1pc 2. Balance Block ... 1 pc. 3. Roller ....................1pc 4. M5 Screw ............ 2pc 5. M5 Washer ........ 2pc.

6. M5 Nut ............... 2pc 7. Spit Rod Bracket .. 1pc 8. Spit Rod Support .. 1pc 9. Extension Rod .... 2pc 10. Rod Socket ..... 2pc

11 Meat Fork ......... 2 pc 12. Spit Rod ........... 1pc 13. Motor Bracket ........ 2pc 14. M6 Nut ............... 2pc 15. M6 Washer ........ 2pc

16. M6 Screw ......... 2pc 17. AC Motor ........... 1pc

USE , CLEANINGANDMAINTENANCE

0 THEROTISSERIEISFOROUTDOORUSEWITHAGASBBQ. USEAGROUNDEDOUTLET.

0 NOTE! MAXWEIGHTUSEDONTHEROTISSERIEIS 12 KG.

0 DONOTLETCHILDRENPYOROPERATETHEROTISSERIE.

0 UNPLUGTHEELECTRICCORDWHENNOTINUSE.

0 STORETHEACMOTORINADRYPCEWHENNOTINUSE.

0 USEASOFTDAMPCLOTHFORCLEANINGTHEMOTORHOUSING. DONOTUSE

CHEMICALSORABRASIVECLEANERS.

0 HANDWASHSPITANDFORKSUSINGMILDDISHDETERGENTANDTHEN

DRYUSINGASOFTCLOTH.

(2 alternatives)

1. Fix the motor bracket (13) to the sidewall of the

grill body with M6 nut, washer and screw. Use the

motorbracket that ﬁts your barbecue.

2. Enter the AC motor (17) on the bracket by sliding

the track on the motor onto the bracket from above.

3. Thread the meat forks (11) on the spit (12) and

tighten in desired position. The spit (12) is then

inserted into the square hole on the AC motor(17).

4. Enter the handle (1) on the extension (9), then

the balance block (2) and put on the roller (3) . The

rods are assembled using the rod sockets (10).

5. The food should be centered when put on the

on the rod for roasting. Tighten the screw on the

meat forks when they are pushed into the food

and positioned in the middle of the rod.

6. For smaller food or bigger barbecues, the

spit rod (12) can be used with the spit rod

support (7 & 8). Do NOT assemble the handle (1)

when the end of the rod end up inside the barbecue.

NOTE! Remove the grills warming rack when mounting the rotisserie kit.

Also remove the grilling grid if necesarry to allow enough space for rotation.

Assembly

Waste electrical production

should not be disposed of with

household waste.

Please recycle were facilities exist.

Check with your local authority

or retailer for recycling advice.

Consumer Contact

Always attach your receipt when making a warranty claim.

Produced in China for FCCProducts Co., Ltd.

This product is covered by a warranty in accordance with consumer legislation. It has

undergone strict quality controls and testing at the factory.

If there are any parts missing or the product has been damaged, please contact your

dealer or the consumer contact below for help.

Faults due to misuse, lack of maintenance or modiﬁcation of the product will

invalidate the warranty. Damaged parts not due to a fault with the product will be

invoiced according to our price list + carriage and administration fee.

If new parts are needed or in the event of a warranty claim, please contact your

dealer or consumer contact:

FCCPRODUCTSAS

KJELLERVEST   KJELLER NORWAY

+47 924 78 600

support@fccproducts.no

www.fccproducts.no
