Fantasea LED 360 Light Manuel utilisateur

1. Introduction

The LED 360 Light is a new LED light from Fantasea, which

features 36 super bright LED bulbs and a focus light dim out

sensor, which shuts the light off for a second whenever a flash

is fired, in order to prevent a hot spot in the image caused by

the beam of the light. It is perfect to be used as a night dive,

modeling or focus light.

Included in the kit are the LED 360 Light, mounting ring,

stainless steel nut and a hand lanyard.

2. Installing and Removing Batteries

A. To open the LED Light, hold the hand grip firmly in one

hand and turn the clear plastic LED cover counterclockwise

until it separates. Pull the clear plastic cover off. Please

make sure that the light is pointed in an upward position

so contents do not fall out when opened. Take special care

36 Super Bright

ED Bulbs

Flashlight

Hand

Lan

ard

Sensor

not to stare into the light beam which is very powerful and

could damage your eyes.

B. Gently remove the LED head (the white component with 36

LED bulbs) by pulling it out.

C. Install or remove the 4 AA Alkaline or Ni Cad batteries

carefully. Make sure that you follow the instructions

diagram printed on the inside of the light. Note that there

are two sets of two batteries, each set pointing in a

different direction.

D. Carefully replace the LED head, making sure that the red

line on the head corresponds with the red marking on the

inside of the battery compartment. This is the only way it

will fit properly.

E. Carefully place the plastic cover over the threads, and

tighten evenly in a clockwise fashion. Do not use force and

do not allow it to screw down unevenly. Take special care

not to stare into the light beam which is very powerful and

could damage your eyes.

F. It is recommended to occasionally apply a slight amount of

silicone grease to the black O-ring seal found on the

flashlight after unscrewing the flashlight head

counterclockwise.

G. The LED Light is now ready for use.

3. Assembling the LED 360 Light

A. When using the LED Light as a flashlight for night dives,

install the hand lanyard by tying it around the button loop

on the back side of the light. Use the hand lanyard in order

to secure the LED Light to your wrist.

B. When using the LED Light as a focus light integrated in an

underwater camera system, mount it on a Flex or Ball &

Joint arm by using the mounting ring and stainless steel

nut included with the light. Attach the arm to the tray on

which the housing is mounted on.

3. Turning the LED 360 Light On/Off

A. The LED 360 Light features 3 different positions, which are

indicated near the light’s switch:

•Off

•On

•Flasher

B. In order to switch the light on, slide the switch to the “ON”

position. The light is turned on and whenever a flash is

fired, the LED Light’s sensor shuts the light off for a

second, in order to prevent a hot spot in the image, caused

by the beam of the light. After a second, when the image

had been already captured, the light turns on again.

C. In order to switch the emergency flasher on, slide the

switch to the “FLASHER” position. The emergency flasher is

visible up to 5 km/3 miles at night, depending on weather

conditions.

D. In order to switch the light back off, slide the switch to the

“OFF” position.

E. After the dive, detach the LED 360 Light from the

underwater camera system. Soak and rinse exterior

components in fresh water.

4. Specifications

oMade of polycarbonate

oLight output: 3.0 Watt

oFeatures 36 LED chips

oUses 4 x AA batteries

oBurns up to 30 hours per set of batteries

oIncludes an emergency flasher system

oAutomatically shuts off for a second when flash fires

oIncludes mounting ring and stainless steel wing nut for

easy attachment to strobe arm

oIncludes hand lanyard

oDimensions: length 15cm/6 inch, diameter 6cm/2.5 inch

oWeight with batteries: 200g

oDepth rated to 50 meters/180 feet

For further information please contact us at [email protected] or

visit our website at www.fantasea.com

•You must carefully soak and rinse exterior components in fresh

water after each use.

•Store in a protected, dry and shaded area.

•Remove batteries when storing for an extended period of time.
