F910 Facial Recognition Terminal
User Manual
Original operating instructions Version 1.1 / 12-2014 EN
Confidential Page 2
General Notice
Although every care has been taken to ensure that this manual is reliable and accurate,
Hanvon Corporation (here after referred to as Hanvon) provides it ‘as is’ and without
express, implied, or limited warranty of any kind. In no event shall Hanvon be liable for
any loss or damage caused by the use of this manual.
This manual describes F910 facial recognition terminal in detail and contains full operating
instructions.
Hanvon reserves the rights to change the specifications and information in this document
without notice. The information contained herein is proprietary to Hanvon. Release to third
parties of this publication or of information contained herein is prohibited without the prior
written consent of Hanvon.
Copyright © Hanvon, 2014
Confidential Page 3
Content
1. About this document ....................................................... 4
2. Product Features.............................................................. 5
2.1 Appearance View...............................................................5
2.2 Installation Guide ...............................................................6
2.3 Connection Port .................................................................7
2.4 Power up terminal..............................................................8
3. Operating Guide ............................................................... 9
3.1 Admin. Management..........................................................9
3.2 User Management............................................................12
3.3 Data Management............................................................15
3.4 USB Management............................................................17
3.5 System Settings...............................................................20
3.6 System Info......................................................................30
3.7 Auto Test..........................................................................31
4. Appendix ......................................................................... 33
Appendix1. Product Specification .................................. 33
Appendix2. Caution .......................................................... 34
Confidential Page 4
0. About this document
Validity
These instructions are valid for the F910 Facial Recognition Terminal.
Target group
The target group for this document comprises the terminal operator and technical
personnel.
Content and purpose
These user manual describe the F910 facial recognition terminal installation and
operation information to users.
Supplementary documents
N/A
Abbreviations
Hanvon Hanwang Technology Co., Ltd Brand
Face ID Hanwang Technology Co., Ltd Brand
F910 F910 Facial Recognition Terminal
Danger categories and warning symbols
DANGER
Danger Operation!
NOTE
Application tips, useful information
Confidential Page 5
1. Product Features
2.1 Appearance View
1. RFID Reader
2. Display
3. Button: Previous or next field
4. Button: Main function menu
5. Button: Backspace and delete
6. Button: Digital Keypad
7. Button: Cancel button
8. Button: Confirm button
9. Camera
10. Loudspeaker
11. Reset Button
12. USB Socket
13. Power Adaptor Port
14. Network Cable Port
15. Connection Port
Confidential Page 6
2.2 Installation Guide
User can drill the holes according to the
mounting diagram. Use the 4 wall mount,
screws to mount the bracket to the wall.
User also could mount the terminal by
choosing your “shortest” users and have
them stand in front of the device.
Hold the terminal on the wall that
employee can comfortably center their
face in the LCD display window.
Use the 2 bracket screws on the bottom of the
bracket. Align the terminal with the pairs on
the mounting-plate and secure the two
together with the 2 Philips head screws. Be
careful not to pinch the AC cord. When
finished, plug the Power Adapter into the AC
wall outlet.
Confidential Page 7
2.3 Connection Port
PIN Definition Feature
J1.1 VC12V 12V Power Supply
J1.2 GND Ground
J1.3 LOCK_NO
J1.4 LOCK_COM
J1.5 LOCK_NC
Door Lock
J1.6 DOORSENSOR Door Magnetic Detection
J1.7 GND Ground
J1.8 DOORSWITCH Door Switch
J1.9 COM 2
J1.10 NO 2
Alarm/Bell Output
PIN Definition Feature
J2.1 WGD0_IN
J2.2 WGD1_IN
Weigand Input(Need
Customized)
J2.3 GND
J2.4 GND Ground
J2.5 SPK+
J2.6 SPK- Audio Output
PIN Definition Feature
J3.1 WGD0_OUT
J3.2 WGD1_OUT
Weigand Output
J3.3 GND
J3.4 GND Ground
J3.5 BEEP Buzzer
Confidential Page 8
2.4 Power up terminal
Select a proper language when the terminal boot first time. The terminal will provide
several language options for customers:
English
Spainish
Portuguese
Turkish
┉┉
Confidential Page 9
2. Operating Guide
3.1 Admin. Management
Admin.ManagementMainMenu
If no admin. in system, then press <MENU> to enter the main
menu.
If there has enrolled admin. in system, then press <MENU> to
enter admin. verifying process. While the verification is correct,
then the system enter to the main menu.
Press <↑/↓>to move selection to <Set Admin>, and press <OK>
to enter into admin. menu.
Press 1-7 digital buttons on the keypad to enter the corresponding functions
directly.
Set Admin.
There are total 8 admin. accounts. A <Null Admin.> sign will
display for unset admin. accounts. Choose a <Null> account to
register an admin.
Input Admin. ID: Input an ID for admin. If the ID is in the
database, then the terminal displays admin.’s name.
Admin ID uses natural sequence numbers.
Admin.ID can’t be duplicated and start with “0”.
Input Admin. Name: Press <MENU> to switch character
inputting mode between <Upper Case>, <Lower Case> and
<Digital>.
Confidential Page 10
Admin. Types
Super Admin. can operate all functions
and normal administrators.
The first administrator must be super
admin and can’t be deleted in system.
Normal Admin. can operate
User/Data/USB Management function,
check system info. and auto test function.
Verification modes:
ID and Pin: Use ID and password sequentially as a verification
method.
ID and Face: Use ID and face sequentially as a verification
method.
Card and Face: Use card and face sequentially as a
verification method.
Card: Use card as a verification method.
Add as an User: Press [OK] to make the admin. as an user. If
don’t, please check [ESC].
If add as an user, please select the user privilege mode:
Access & Attendance: The terminal is used for access control
and time attendance with relay output.
Attendance: The terminal is only used for time attendance
without relay output.
