FabiaTech FX5206 Manuel utilisateur

FabiaTech Corporation

IPC Solution

Website: http://www.fabiatech.com

Email: support@fabiatech.com

Small Cube System

Fanless Series

FX5206 User’s Manual

DEC 2013

Version: 1.0

Part Number: FX5206

be reproduced in any part or as a whole, transcribed, stored in a retrieval system,

translated into any language, or transcribed in any form or by any means,

electronic, mechanical, and magnetic… or otherwise without the prior written

permission of FabiaTech Corporation.

Disclaimer

FabiaTech makes no representation of warranties with respect to the contents of

this publication. In an effort to continuously improve the product and add features,

FabiaTech reserves the right to revise the publication or change specifications

contained in it from time to time without prior notice of any kind from time to time.

FabiaTech shall not be reliable for technical or editorial errors or omissions, which

may occur in this document. FabiaTech shall not be reliable for any indirect,

special, incidental or consequential damages resulting from the furnishing,

performance, or use of this document.

Trademarks

Trademarks, brand names and products names mentioned in this publication are

used for identification purpose only and are the properties of their respective

owners.

Technical Support

If you have problems or difficulties in using the system or setting up the relevant

devices, and software that are not explained in this manual, please contact our

service engineer for service, or send email to sup[email protected].

Returning Your Board for Service & Technical Support

If your board requires servicing, contact the dealer from whom you purchased the

product for service information. You can help assure efficient servicing of your

product by following these guidelines:

A list of your name, address, telephone, facsimile number, or email address

where you may be reached during the day

Description of you peripheral attachments

Description of your software (operating system, version, application

software, etc.) and BIOS configuration

Description of the symptoms (Extract wording any message)

For updated BIOS, drivers, manuals, or product information, please visit us at

www.fabiatech.com.

Table of Contents

FX5206 User’s Manual ...........................................................................................................i

Chapter 1 Introducing the FX5206 System ............................................................................... 1

Overview..................................................................................................................................1

Series Comparison Table.......................................................................................................2

Layout.......................................................................................................................................3

Specifications..........................................................................................................................4

Packing List ..............................................................................................................................5

Chapter 2 Hardware Installation ............................................................................................... 7

Before Installation ...................................................................................................................7

　Removing Covers –Installing Hardware...........................................................8

　LED Indicators & I/O Peripheral Connectors ................................................11

　Connecting the DC Power and Power Switch ............................................14

　Jumper Setting ..................................................................................................15

Chapter 3 BIOS Setup............................................................................................................... 17

Overview................................................................................................................................17

　BIOS Functions ...................................................................................................18

　Keyboard Convention .....................................................................................19

Main Setup ............................................................................................................................20

Advanced Setup..................................................................................................................21

　CPU Configuration............................................................................................22

　IDE Configuration..............................................................................................23

　Remote Access Configuration .......................................................................26

　USB Configuration .............................................................................................28

Boot Setup .............................................................................................................................30

　Boot Setting Configuration..............................................................................31

　Boot Device .......................................................................................................33

　USB Drives ...........................................................................................................34

Security setup........................................................................................................................35

Chipset Setup........................................................................................................................37

　Northbridge Configuration..............................................................................38

　Southbridge Configuration..............................................................................41

iii

Chapter 4 Software Installation ............................................................................................... 47

VGA Drivers ...........................................................................................................................47

　WINXP Driver ......................................................................................................47

Audio Driver...........................................................................................................................48

　WIN XP Driver .....................................................................................................48

LAN Driver (RTL 8111F)..........................................................................................................48

　WIN XP Driver .....................................................................................................48

BIOS Flash Utility.....................................................................................................................48

Watchdog Timer ...................................................................................................................49

　Watchdog Timer Setting ..................................................................................49

　Setup Watchdog Timer Step - WDT0 and WDT1 ..........................................51

Chapter 5 Technical Reference .............................................................................................. 55

Trouble Shooting for Post Beep and Error Messages.......................................................55

Technical Reference............................................................................................................58

　Physical and Environmental............................................................................58

　Real-Time Clock and Non-Volatile RAM .......................................................58

　CMOS RAM Map...............................................................................................60

　I/O Port Address Map.......................................................................................61

　Interrupt Request Lines (IRQ)...........................................................................62

　Serial Ports ..........................................................................................................63

Appendix................................................................................................................................... 67

Dimension ..............................................................................................................................67

FabiaTech Corporation

Chapter1IntroducingtheFX5206System

Overview

The FX5206 is an embedded system with low-power CPU module inside. This user’s

manual provides information on the physical features, installation, and BIOS setup

of the FX5206.

Built to unleash the total potential of the Vortex™ 86DX2 Processor, Able to support

800MGz CPU, this system supports one 10/100/1000 Base –T LAN port, PCIe Mini

Card connector for GPRS/GPS modules, audio, three USB 2.0 ports, and onboard

1GB DDR2 RAM, and a VGA controller.

Each FX5206 has one port for I/O communications. One RS-232C port is available.

The FX5206 is perfect for ATM machines, KIOSK, point-of-sales/point-of- information,

gaming and infotainment, measurement technology, lotteries, and banking and

small Embedded Control. The unit is only 95.0mm (D) X115.0mm (W) X30.2mm (H).

FabiaTech Corporation

SeriesComparisonTable

Model FX5206

System Processor Vortex™ 86DX2 800MHz

Memory

Onboard RAM DDR2 300/333

1GB

VGA Yes

Watchdog Timer Yes

Multi I/O One RS232

Storage One CFast and SD Card

USB 2.0 Port Three

Audio Ear-Phone And MIC-In

RJ45 LAN port

(10/100/1000 Mbps) One Realtek RTL8111F

PCIe Mini Card One

Operating Temperature 0~+ 50℃(32~113℉)

Storage Temperature -20~+60℃(4~140℉)

Dimensions (Unit: mm) 95(D) x 115(W) X 30.2(H)

FabiaTech Corporation

Layout

LAN

EAR-PHONEPOWER LED

ANTENNAANTENNA MIC COM

DC12~24V

POWER SWITCH

USB

RESET

DC IN

CRT

FabiaTech Corporation

Specifications

Processor Board –

Vortex™ 86DX2 Low Power 800MHz CPU with 1GB DDR2-RAM.

I/O Outlets –

One 10/100/1000 base-TX Ethernet LAN port with RJ45.

One CRT and three USB ports (2.0) and one RS-232/422/485 serial port.

Two Audio connectors for Earphone-out and Microphone-In.

One PCIe Mini card socket modules, especially for WLAN/GPRS module.

One DC-In terminal block with power switch.

One push button reset switch and one power LED.

Storage Bay-

CFast Compact Flash socket for CFast Compact Flash modules.

One SD socket supports up to 32GB SDHC (Class 6).

Power requirement –

+12~+24V DC, 1.12A maximum (0.77A typical) with DC 19V input.

Dimensions -

95.0mm (D) x 115.0mm (W) x 30.2mm (H)

FabiaTech Corporation

PackingList

Upon receiving the package, verify the following things. Should any of the

mentioned happens, contact us for immediate service.

•Unpack and inspect the FX5206 package for possible damage that may

occur during the delivery process.

•Verify the accessories in the package according to the packing list and see

if there is anything missing or incorrect package is included.

•If the cable(s) you use to install the FX5206 is not supplied from us, please

make sure the specification of the cable(s) is compatible with the FX5206

system.

Note: after you install the FX5206, it is recommended that you keep the diskette or

CD that contains drivers and document files, and keep the document

copies, or unused cables in the carton for future use.

The following lists the accessories that may be included in your FX5206 package.

Some accessories are optional items that are only shipped upon order.

•One FX5206 embedded system.

•One 2-pin apartable terminal block.

•One compact disc includes software utility and manual.

Optional:

•One pack of half size mini PCIe module adapter kits.( P/N:0606010028G)

•FX5311K1 panel back mounting fixers and 2 screws (VESA 75*75).

(P/N:0606010019G)

•Ak1009 Kit- DIN Rail mounting kit(P/N:0606010032R)
