CONTENTS

Dear Customer,

If you follow the recommendations contained in this Instruction

Manual, your appliance will give you constant high performan-

ce and will remain efficient for many years to come.

RECOMMENDATIONS AND SUGGESTIONS 13

CHARACTERISTICS 14

INSTALLATION 16

USE 19

MAINTENANCE 20

13GB

RECOMMENDATIONS AND SUGGESTIONS

INSTALLATION

•The manufacturer will not be held liable for any damages resulting

from incorrect or improper installation.

•The minimum safety distance between the cooker top and the

extractor hood is 650 mm.

•Check that the mains voltage corresponds to that indicated on the

rating plate fixed to the inside of the hood.

•For Class I appliances, check that the domestic power supply

guarantees adequate earthing.

Connect the extractor to the exhaust flue through a pipe of

minimum diameter 120 mm. The route of the flue must be as short

as possible.

•Do not connect the extractor hood to exhaust ducts carrying

combustion fumes (boilers, fireplaces, etc.).

•Iftheextractorisusedinconjunctionwithnon-electricalappliances

(e.g. gas burning appliances), a sufficient degree of aeration must

be guaranteed in the room in order to prevent the backflow of

exhaust gas. The kitchen must have an opening communicating

directly with the open air in order to guarantee the entry of clean

air.

USE

•The extractor hood has been designed exclusively for domestic

use to eliminate kitchen smells.

•Never use the hood for purposes other than for which it has ben

designed.

•Never leave high naked flames under the hood when it is in

operation.

•Adjust the flame intensity to direct it onto the bottom of the pan

only, making sure that it does not engulf the sides.

•Deep fat fryers must be continuously monitored during use:

overheated oil can burst into flames.

•The hood should not be used by children or persons not instructed

in its correct use.

MAINTENANCE

•Switch off or unplug the appliance from the mains supply before

carrying out any maintenance work.

•Clean and/or replace the Filters after the specified time period.

•Clean the hood using a damp cloth and a neutral liquid detergent.

650 mm min.

14GB

CHARACTERISTICS

Dimensions

650 min.

135

500

676 70

898

ø 340

ø 150

min. 890

max. 1170

890

15GB

12f

2.1

2.2

12h

7.1

14.1

12g

12e

12c

7.1a

7.1b

Components

Ref. Q.ty Pro uct Components

11 Hood Body, complete with: Controls, Light,

Blower, Filters

21 Telescopic Chimney comprising:

2.1 1 Upper Section

2.2 1 Lower Section

7.1 1 Telescopic fr me complete with extr ctor,

consisting of:

7.1a 1 Upper fr me

7.1b 1 Lower fr me

81 Air Outlet Grill

91 Reducer Fl nge ø 150-120 mm

14 1 Hood Body Air Outlet Extension Piece

consisting of two H lf Shells

14.1 1 Air Outlet Connection Extension

15 1 Air Outlet Connection

24 1 Junction box

25 2 Pipe cl mps

Ref. Q.ty Installation Components

11 4 W ll Plugs ø 10

12c 4 Screws 2,9 x 6,5

12e 2 Screws 2,9 x 9,5

12f 4 Screws M6 x 10

12g 4 Screws M6 x 80

12h 4 Screws 5,2 x 70

21 1 Drilling templ te

22 4 6.4 mm int. di w shers

23 4 M6 nuts

Q.ty Documentation

1 Instruction M nu l

16GB

INSTALLATION

Drilling the Ceiling/shelf an fixing the frame

DRILLING THE CEILING/SHELF

•Use a plumb line to mark the centre of the hob on the ceiling/support shelf.

•Place the drilling template 21provided on the ceiling/support shelf, making sure that the template

is in the correct position by lining up the axes of the template with those of the hob.

•Mark the centres of the holes in the template.

•Drill the holes at the points marked:

•For concrete ceilings, drill for plugs appropriate to the screw size.

•For hollow brick ceilings with wall thickness of 20 mm: drill ø10 mm.

•For wooden beam ceilings, drill according to the wood screws used.

•For wooden shelf, drill ø7 mm.

•For the power supply cable feed, drill ø10 mm.

•For the air outlet (Ducted Version), drill according to the diameter of the external air exhaust

duct connection.

FIXING THE FRAME

Before fixing, separate the Upper Section 2.1 and

the Lower Section 2.2 from the Frame by

unscrewing the screws 12c, then separate the two

sections of the frame by unscrewing the 6 side

screws to obtain the Upper frame and Lower fra-

me.

17GB

Upper frame

•Align the power supply cable feed hole

•Fix the upper frame to the ceiling or shelf using:

•For concrete ceilings, use the appropriate plugs for the screw size (not provided).

•For hollow brick ceilings of wall thickness of approximately 20 mm: use 4 plugs 11 and 4

screws 12h, provided.

•For wooden beam ceilings, use 4 wood screws (not provided).

•For wooden shelf, use 4 screws 12g with washers 22 and nuts 23, provided.

Lower frame

•Fix the lower frame using the 8 previously removed screws, adjusting the length according to the

installation height (hood body lower fixing surface must be at least 720 mm from the hob).

•For the recirculation version, turn the frame in the direction chosen for the recirculated air outlet.

•The frame mountings must be secure to withstand the weight of the hood and any stresses caused

by the occasional side thrust applied to the device. On completion, check that the base is stable,

even if the frame is subjected to bending.

•In all cases where the ceiling is not strong enough at the suspension point, the installer must

provide strengthening using suitable plates and backing pieces anchored to the structurally sound

parts.

Connections

DUCTED VERSION AIR EXHAUST SYSTEM

When installing the ducted version, connect the hood to the chimney using either a flexible or rigid

pipe ø150 or 120 mm, the choice of which is left to the installer.

•To install a ø120 mm air exhaust connection,

insert the reducer flange 9on the hood body

outlet.

•Fix the pipe using the pipe clamps 25 provided.

•Remove any activated charcoal filters.

RECIRCULATION VERSION AIR OUTLET

•Insert reducer flange 9on the extractor outlet.

•Push fit the extension piece 14 onto the flange.

•Push fit connector 15 onto the extension piece.

•Insert extension piece/connector 14.1 laterally

on connector 15, ensuring that the outlet is in

line with the chimney intake.

ø 120ø 150

14.1 14

18GB

12f

12e

Cmd

12c

Lux

Flue assembly - Mounting the hoo bo y

•Position the upper chimney section and fix the

upper part to the frame using the 2 screws 12c

provided.

•Fit the lower chimney section onto the frame,

holding it in place until the hood body has been

fixed in place.

Recirculation version

•Make sure that the outlet of the extension piece

14.1 is horizontally and vertically aligned with

the chimney outlet.

•Ifthis is not thecase, remove the lowerchimney

section and adjust the position by cutting the

hoodbody extension 14 along one of the thinner

section channels denoting the pre-fixed lenghts,

then reassemble as described previously.

Before fixing the hood body to the frame:

•Remove the grease filters from the hood body;

•Remove any activated charcoal filters.

•From below, use the 4 screws 12f provided to

fix the hood body to the frame.

•For the recirculation version, locate the

directional grill 8in its housing. Ensure that it

is inserted correctly in connector 15.

ELECTRICAL CONNECTION

•Connect the hood to the mains through a two-

pole switch having a contact gap of at least 3 mm.

•Connect the control connector Cmd.

•Connect the lights connector Lux.

•Place the connectors in the junction box 24 and

close it using the 2 screws 12e (2,9 x 9,5)

provided.

•Fix the junction box to the hood body using the

2 screws 12c (2,9 x 6,5) provided.

•For the recirculation version, fit the activated

carbon odour filter.

•Replace the grease filters.

19GB

USE

Control panel

LLight Switches the lighting system on and off.

S1 Led Motor running led. Flashes when the grease filters are saturated.

S2 Led Intensivespeedled.Flasheswhentheactivatedcarbonodourfilters are exhausted.

MMotor Switches the extractor motor on and off at low speed. Used to provide a contin-

uos and silent air change in the presence of light cooking vapours.

When the Hood is in ELC (Electronic Comfort) mode, the button will not only

turn the Ducting motor on, but will also disable this function.

V1 Speed Reduces the operating speed.

When the button is pressed with the Motor off, ELC (Electronic Comfort) mode

will be enabled again, giving a continuous, low noise flow of air. Press the

button and hold it until Led S1 flashes slowly.

V2 Speed Increases the operating speed.

V3 Intensive Maximum speed, used for eliminating the highest cooking vapour emission.

speed Switches off automatically after 10 minutes operation. Can also be switched off

manually by pressing the button.

20GB

MAINTENANCE

Grease filters

CLEANING METAL SELF-SUPPORTING GREASE FILTERS

Alarm signal reset

•Switch off the lights and extractor motor.

•Press button V3 for at least 3 seconds, until the

leds start to flash.

Cleaning the filters

•The filters are washable and must be cleaned

when led S1 flashes or at least every 2 months

of operation, or more frequently for particularly

heavy usage.

•Removethe filters one at a time by pushing

them towards the back of the group and

pulling down at the same time.

•Wash the filters, taking care not to bend them.

Allow them to dry before refitting.

•When refitting the filters, make sure that the

handle is visible on the outside.
