HDMI DA2 • Setup Guide

Overview

The Extron HDMI DA2 distribution amplifier distributes one HDMI input signal to two

outputs simultaneously. This setup guide provides instructions for a basic installation by

an experienced installer. For complete instructions, see the HDMI DA2 User Guide, which is

available on the Extron web site (www.extron.com).

Front Panel

aPower status LED — Lights green when power is applied to the unit.

bUSB Config port — Used for SIS configuration, monitoring, and firmware updates.

cSignal LEDs — Light green when a TMDS signal is detected on the HDMI input and is

being transmitted on the appropriate output.

dHDCP LEDs — Light green when a HDCP has been authenticated on the HDMI input

and the appropriate output (if required).

eEDID LED — Lights green when the EDID is successfully stored from the selected output

device (output 1 by default). Lights amber if factory-installed EDID is used or if the EDID

was not successfully stored.

Rear Panel

POWER

12V

0.4A MAX RS-232

Tx Rx G

INPUT

REMOTE

OUTPUTS

ab dc

aPower input — Connect the provided 12 VDC, 1 A power supply to this power input.

bHDMI input — Connect a source device into this female HDMI type A connector.

cHDMI outputs — Connect display devices into these female HDMI type A connectors.

dRS-232 — Used for SIS configuration, monitoring, and firmware updates.

Installation

1. Mount the HDMI DA2 in a suitable location (see the “Mounting” section of the HDMI

DA2 User Guide for mounting options). Follow the instructions provided with the

mounting kit.

HDMI DA2

CONFIG

INPUT

EDID

OUTPUTS

SIGNAL

HDCP

HDMI DA2 • Setup Guide (Continued)

Extron USA Headquarters

+800.633.9876 (Inside USA/Canada Only)

Extron USA - West Extron USA - East

+1.714.491.1500 +1.919.850.1000

+1.714.491.1517 FAX +1.919.850.1001 FAX

Extron Europe

+800.3987.6673 (Inside Europe Only)

+31.33.453.4040

+31.33.453.4050 FAX

Extron India

1800.3070.3777 (Inside India Only)

+91-80 3055.3777

+91 80 3055 3737 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+4000.EXTRON

+4000.398766

Inside China Only

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Asia

+800.7339.8766

Inside Asia Only

+65.6383.4400

+65.6383.4664 FAX

Extron Middle East

+971.4.2991800

+971.4.2991880 FAX

Extron Korea

+82.2.3444.1571

+82.2.3444.1575 FAX

2. (Optional) Connect the USB or RS-232 connector (see the ﬁgure at right) to

a PC for conﬁguration and maintenance. Use SIS commands to conﬁgure

EDID Minder®, mute the video signal, mute the audio signal, adjust the

video color bit depth, or monitor the signal and HDCP status, as required.

See the “SIS Commands” section of the HDMI DA2 User Guide.

3. Connect and power on the display devices to the rear panel HDMI outputs.

Connect the primary display to output 1. EDID from output 1 will be stored

automatically.

NOTE: Use the LockIt™HDMI cable lacing brackets provided

to secure the HDMI connectors (see the LockIt HDMI Cable

Lacing Bracket Installation Guide).

4. Connect the provided 12 VDC, 1.0 A power supply to the 2-pole captive

screw connector (see ﬁgure at bottom right).

CAUTION: Before connecting the power supply, see the

cautions in the “Power Connector” section of the

HDMI DA2 User Guide.

5. Connect and power on the source device.

POWER

12V

0.4A MAX RS-232

TxRx G

1 2

INPUT

REMOTE

OUTPUTS

131

100

LINK

ACT

COM IR INPUT RELAY

TX RX

IPL250

OFF

DISPLAY

MUTE

SCREEN

DOWN

VCR

DVD

DOC

CAM

LAPTOP

RS-232

Extron

HDMI DA2

Distribution

Amplier

TCP/IP

TouchLink™

Control

System

HDMI Cables

HD Display

Blu-ray Disc Player

68-1844-50

Rev. A05 12

SECTION A–A

Ridges

Smooth

3/16"

(5 mm) Max.

POWER

12V

0.4A MAX

DB9 Pin Locations

Female

RS-232

Tx Rx G

REMOTE

TransmitReceive

ReceiveTransmit

GroundGround

Pin 2 = Rx

Pin 3 = Tx

Pin 5 = G

Computer

HDMI DA2
