Extech Instruments ExStik EC500 Manuel utilisateur

User Manual

ExStik®EC500

pH / Conductivity / TDS / Salinity / Temperature Meter

www. .com information@itm.com1.800.561.8187

2 EC500-en-US_v2.9 7/20

Introduction

Congratulations on your purchase of the ExStik® EC500 pH/Conductivity/Total Dissolved Solids

(TDS) / Salinity meter. With the EC5 -constant technology it is possible to measure

a wide range of Conductivity, TDS, and Salinity with the same electrode. Careful use and

maintenance will provide years of reliable service.

The ExStik® uses four (4) CR2032 Lithium Ion Batteries

indicator appears on the LCD. Press the ON/OFF key to turn the ExStik® on or off. The auto power

off feature shuts the ExStik® off automatically after 10 minutes of inactivity to preserve battery life.

Getting Started

Remove the cap from the bottom of the ExStik to expose the pH electrode, reference junction

and conductivity electrodes.

Before the first use or after storage, soak the electrode in tap water or pH 4 buffer solution for

about 10 minutes.

White KCL crystals may be present in the cap or on the electrode. This is to be expected

depending on the length of time in storage. These crystals will dissolve while soaking the

electrode or they can be rinsed away with tap water.

For best results calibrate with pH 7 buffer solution first, then calibrate with the buffer solution

closest to the expected pH value of the solution or material to be tested.

To preserve the pH electrode life, keep the sponge in the protective cap soaked with tap water

or pH 4 buffer solution.

For best results, calibrate for conductivity with a standard in the expected range of the sample.

For maximum accuracy calibrate from low conductivity value standards to high value standards.

www. .com information@itm.com1.800.561.8187

3 EC500-en-US_v2.9 7/20

Meter Description

Front Panel Description

1. Battery compartment cover

2. LCD Display

3. MODE/HOLD button

4. CAL/RECALL button

5. ON/OFF button

6. Electrode Collar

7. pH/Conductivity Electrode

(Note: The Electrode cap is not shown)

LCD Display

1. Bargraph display

2. Measurement units

3. Main display

4. Range calibration and

low battery indicators

5. Temperature display

6. Renew indicator

7. Reading hold indicator

www. .com information@itm.com1.800.561.8187

4 EC500-en-US_v2.9 7/20

Measurement Procedure

Sample Preparation:

1. For Conductivity, TDS or Salinity place the test sample in a sample

cup with enough depth (2.5cm minimum) to cover the electrode. Stir

the solution to remove any air bubbles.

2. For pH, place the tip of the electrode in the sample or make contact

with a wet surface.

Measurement:

1. Press the ON button. (

display during the turn-on diagnostics)

2. Depress and hold the MODE/HOLD key to scroll to the desired

measurement mode.

3. Insert the electrode into the sample making sure that the electrodes are

completely submersed.

4. Slowly stir the solution with the electrode to remove air bubbles if in the

Conductivity, TDS or Salinity mode.

5. If in the Conductivity, TDS or Salinity modes, the meter will auto-range

to the proper range and then display the reading.

www. .com information@itm.com1.800.561.8187

5 EC500-en-US_v2.9 7/20

Changing Measurement Function

The meter can be set to measure pH, Conductivity, TDS or Salinity.

To change the mode:

1. Press and Hold the MODE/HOLD button for 2 seconds and the display will begin to scroll

through the units.

µS (Conductivity); pH; ppm S (Salinity); ppm (TDS); mg/l (TDS);

Note:

displayed in the lower left corner of the display, briefly press the MODE/HOLD button to turn it off.

2. When the desired units are displayed, release the MODE/HOLD button.

TDS Compensation Ratio

The TDS value is determined by multiplying a conductivity reading by a known ratio factor. The

meter allows for selecting a conversion ratio in the range of 0.4 to 1.0. The ratio varies with the

application, but is typically set between 0.5 and 0.7.

Note: The stored ratio will briefly appear in the lower temperature display when the meter is first

turned on, or when changing measurement function to TDS.

Note: In the Salinity mode the ratio is 0.4 to 0.6 auto

To change the ratio, while in the TDS measurement mode (ppm or mg/l):

1. Press and release the CAL/RECALL button twice in succession. The stored

ratio will appear in the display.

2. Press the MODE/HOLD button to increase the ratio value in steps of 0.1.

3. When the desired ratio is displayed, press and release the CAL/RECALL

button to store the value and return to the normal mode.

4. If no buttons are pressed for 5 seconds, the meter returns to measure mode.

Storing Readings

1. Press the MODE/HOLD button to store a reading. The storage location

number will be displayed on the lower display, while the main display shows

the stored reading. The meter will enter the HOLD mode and the

indicator will appear.

2. Press the MODE/HOLD button again to exit the HOLD mode and return to

normal operation.

3. If more than 25 readings are stored, previously stored readings (starting with

number 1) will be overwritten.

www. .com information@itm.com1.800.561.8187

6 EC500-en-US_v2.9 7/20

Recalling Stored Readings

1. Press the CAL/RECALL button and then press the MODE/HOLD button. A location number (1

through 25) will briefly appear and then the value stored in that location will appear. The

displayed units will flash, indicating that the storage recall mode is active.

2. The last stored reading will be displayed first. Pressing and releasing the MODE/HOLD button

will scroll through the stored readings one at a time. The location number is displayed first,

followed by the reading stored in that location.

3. To exit the storage mode, press the CAL/RECALL button and the meter will return to normal

operation nd .

Clear Stored Memory

clr

memory is cleared.

Changing Temperature Units

To change the displayed temperature units (oC or oF):

1. With the unit OFF, press and hold down the CAL/RECALL button.

2. With the CAL/RECALL button depressed momentarily press the ON/OFF button.

CAL/RECALL button. The unit will power on with

temperature displayed in the new units.

Data Hold Mode

Press the MODE/HOLD button to hold (freeze) a reading in the display. The meter will enter the

Note: This also stores the reading.

Press the MODE/HOLD button again to return to normal operation.

Auto Power OFF

The auto power off feature automatically shuts the meter off 10 minutes after the most recent button

press.

Auto Power OFF Disable

To disable the Auto Power Off feature:

1. Turn the unit on

2. Press CAL/RECALL once (Quickly)

3. Immediately and simultaneously press the MODE/HOLD and ON/OFF buttons for

approximately 2 seconds, until oFF is briefly displayed

To disengage this feature, turn the unit off with the ON/OFF button. The next time the unit is

powered up, Auto Power OFF mode will be engaged again.

Low Battery Indication

on will appear in the display. Refer to the

Maintenance section for battery replacement information.

www. .com information@itm.com1.800.561.8187

7 EC500-en-US_v2.9 7/20

Calibration - pH (1, 2, or 3 points)

1. Place the electrode into a buffer solution (4, 7, or 10). Press and hold the CAL/RECALL key

. When doing a 2 or 3 point calibration, calibrate

with pH 7 buffer first, then follow with pH 4 then the pH 10 buffer.

2. The ExStik® automatically recognizes the solution and calibrates itself to that value (the circled

number on the LCD will match the solution). Note that if the solution is more than 1 pH unit off

from the L (4), M (7), or H (10) pH buffer, or if the electrode slope is low, the ExStik®will

assume an error and abort the calibration ( will be displayed, and the unit will return to

measure mode.)

3. During calibration, the pH reading flashes on the main display.

4. When calibration is complete, the ExStik® automatically displays nd and returns

to normal operation mode.

5. The appropriate circled indicator (L, M, or H) appears on the LCD when a particular calibration

or series of calibrations has been completed within one power on cycle. When the ExStik® is

turned off, the circled indicator configuration and the calibration data will be retained.

6. For a two or three-point calibration, repeat steps 1-4.

7. See Reset Calibration Data to clear all calibration data from the meter.

CAL Reminder Display

When in pH measurement mode, without

performing a calibration. The CAL display is simply a reminder to calibrate pH, and will turn off when

the pH electrode is recalibrated. The reminder does not affect function in any way.

RENEW Display

is not performing to expected specifications. If

cleaning and recalibration does not cause the RENEW icon to disappear, replace the probe (see

optional accessories on the last page of this manual). The RENEW display appears as a result of

the pH electrode slope falling below 70% of a nominal slope.

Measurement and Display Considerations

If the unit appears to be locked (display frozen). It is possible that the Data Hold mode has

been inadvertently accessed by pressing the MODE/HOLD button.

in the bottom left of the LCD.) Simply press the MODE/HOLD button again or turn the meter off

and then on.

For maximum accuracy, allow sufficient time for the temperature of the probe to reach the

temperature of the sample before calibrating. This will be indicated by a stable temperature

reading on the display.

Reset Calibration Data

Follow this procedure to clear all calibration data from the meter. Resetting the calibration data may

be necessary when new calibration solutions are used or accuracy of measurements is in question.

1. Turn off the meter.

2. Press and Hold the Cal/Recall and Mode/Hold buttons.

3. Momentarily press the On/Off button, as soon as the display comes on, release all 3

buttons.

4. The display will show dFLt rSt ration data will be erased.

If does not appear, retry the procedure.

5. Proceed to the calibration routine for pH and Conductivity.

www. .com information@itm.com1.800.561.8187

8 EC500-en-US_v2.9 7/20

Calibration - Conductivity

Meter accuracy verification should be performed on a periodic basis. Once per month is the

recommended cycle for normal use. If calibration is required, a conductivity standardizing solution

must be obtained. The meter can be calibrated in any or all of the three ranges. Standardizing

solutions of 84µS/cm, 1413µS/cm or 12.88mS/cm (12,880µS/cm) are used for the automatic

calibration recognition procedure. No other calibration values are permitted.

Calibration is always done in conductivity mode. Since salinity and TDS values are calculated from

conductivity values, this procedure also calibrates the salinity and TDS ranges.

1. Fill a sample cup with the standardizing solution.

2. Turn the meter ON and insert the electrode into the solution. Tap or move the electrode in the

sample to dislodge any air bubbles.

3. Press and hold the CAL/RECALL button (approximately 2 seconds) until s in

the lower (temp) display. The main display will start flashing.

4. The meter will automatically recognize and calibrate to the standardizing solution. The display

will brie nd and then return to the measurement mode after a calibration.

5. range ange that is calibrated

during that power on cycle.

Low range, 84µS/cm

Medium range, 1413µS/cm

High range, 12.88mS/cm (12,880µS/cm)

Note: Each time the calibration mode is entered all calibration symbols on the display are cleared,

but only the calibration data for the currently calibrated range is replaced. The other two ranges

keep the existing calibration data, just the symbols are removed. Calibration of all three ranges must

be performed during one power on period for all three range calibration symbols to appear.

See Reset Calibration Data to clear all calibration data from the meter.

Note: The meter allows for a 1, 2 or 3 point calibration. If calibration is done for more than one point

the lowest value standard should be done first to obtain the best accuracy.

Considerations and Techniques

Do not touch the inner surfaces of the conductivity electrodes. Touching the surface of the

platinized electodes may damage and reduce the life of the probe.

Store the electrode in the wetting cap with the sponge moistened with pH 4.01 buffer solution.

Always rinse the electrode in de-ionized water between measurements to avoid cross

contamination of the sample. Double rinsing is recommended when high accuracy is required.

Periodically, accumulated salt deposits from the reference electrode may build up in the

storage cap, and should be rinsed away. These deposits could affect measured values of low

conductivity samples.

When measuring low conductivity samples, extra care is recommended in rinsing the probe to

avoid contamination of the sample with electrolyte from the pH reference electrode. This will

only be a factor when measuring in the low range, and can be further minimized by increasing

the volume of the sample. (Example: Try a 200 to 500 mL sample.)

If the 20mL sample cup is to be used, then the electrode should not be allowed to sit in the

sample for any longer than necessary, to avoid pH electrolyte leakage into the sample, raising

the conductivity value.

www. .com information@itm.com1.800.561.8187

9 EC500-en-US_v2.9 7/20

Operational Matrix

Function /

Resulting Action

Power

Status

Mode

Setting

Required Key Press Sequence

On/Off On or Off Any Momentary press of the ON/OFF key

Calibration On pH or

Conductivity

Press & hold CAL/RECALL key for 2

seconds, until it enters CAL function

Store Reading On Any measure

mode

Momentary press of the

MODE/HOLD key

Hold Release On While In Hold

Mode

Momentary press of the

MODE/HOLD key

Enter Memory

Retrieval

On Any measure

mode

Momentary press of the

CAL/RECALL key followed by a

momentary press of the

MODE/HOLD key (Within 4 seconds)

Scroll Stored

Readings

On Memory

Recall

Momentary press of the

MODE/HOLD key

(Displays last in first out )

Exit Memory

Retrieval

On Memory

Recall

Momentary press of the

CAL/RECALL key

Clear Stored

Memory

On Any Measure

Mode

Press and hold the ON/OFF key for 4

seconds

Change

Measurement Mode

On Any Press and hold the MODE/HOLD key

for at least 2 seconds (the modes will

scroll by until the key is released)

Enter Cond/TDS

Ratio

On TDS (ppm or

mg/l)

Press and release the CAL/RECALL

key twice in quick succession

Change Cond/TDS

Ratio

On TDS ratio Momentary press of the

MODE/HOLD key (each key press

increases the ratio by 0.1, the value

cycles from 0.4 - 1.0)

Exit Cond/TDS

Ratio

On TDS ratio Momentary press of the

CAL/RECALL key

Change

Temperature Units

Off n/a (off

mode)

Press and hold the CAL/RECALL key

then momentarily press the On/Off

key. Release the CAL/RECALL key

after the "SELF CAL" lights

Override Auto

Power Off

On Any measure

mode

Momentarily press the CAL/RECALL

key then simultaneously press and

hold the ON/OFF & MODE/HOLD key

for approximately 2 seconds, until

Default Reset OFF n/a Simultaneously press ON/OFF,

CAL/RECALL and MODE/HOLD

momentarily will be displayed.

www. .com information@itm.com1.800.561.8187

10 EC500-en-US_v2.9 7/20

Specifications

Display 2000 count LCD with Bargraph

pH Range 0.00 to 14.00

pH Accuracy ±0.01 pH typical

pH ATC Range 32°F to 194oF (0°C to 90oC)

pH Reference Junction Permanent gel, non-refillable

Conductivity ranges 0 to 199.9µS

200 to 1999µS

2.00 to 19.99mS

TDS ranges 0 to 99.9ppm or mg/L

(Variable ratio) 100 to 999ppm or mg/L

1.00 to 9.99ppt or g/L

Salinity range 0 to 99.9ppm

100 to 999ppm

1.00 to 9.99ppt

TDS Ratio 0.4 to 1.0 adjustable

Salinity Ratio 0.4 to 0.6 auto

Conductivity ATC 2.0% per oC

Conductivity ATC Range 32.0°F to 140oF (0.0°C to 60.0oC)

Temperature Range 23.0°F to 194oF (-5.0°C to 90.0oC)

Temperature Resolution 0.1 up to 99.9, 1 >100

Temperature Accuracy ±1.8°F; 1°C (from 23 to 122°F;-5 to 50°C)

±5.4°F; 3°C (from122 to 194°F; 50 to 90°C)

Accuracy Conductivity: ±2% full scale

TDS: ±2% full scale

Salinity: ±2% full scale

Measurement Memory 25 tagged (numbered) readings

Low battery indication

Power Four (4) CR2032 Lithium Ion Batteries

Auto power off After 10 minutes (override available)

Operating conditions 23°F to 122oF (-5°C to 50oC)

Dimensions (40 x 200 x 40 mm)

Weight 3.3 oz (93 g)

www. .com information@itm.com1.800.561.8187

Autres manuels pour ExStik EC500

Table des matières

Autres manuels Extech Instruments Instrument de mesure

Extech Instruments

Extech Instruments 407750 Manuel utilisateur

Extech Instruments

Extech Instruments EX830 Manuel utilisateur

Extech Instruments

Extech Instruments SDL310 Manuel utilisateur

Extech Instruments

Extech Instruments 475040-SD Manuel utilisateur

Extech Instruments

Extech Instruments ExStik EC510 Manuel utilisateur

Extech Instruments

Extech Instruments LT505 Manuel utilisateur

Extech Instruments

Extech Instruments HD600 Manuel utilisateur

Extech Instruments

Extech Instruments MO230 Manuel utilisateur

Extech Instruments

Extech Instruments TachIR RPM10 Manuel utilisateur

Extech Instruments

Extech Instruments 401025 Manuel utilisateur

Extech Instruments

Extech Instruments RH600 Manuel utilisateur

Extech Instruments

Extech Instruments EX820 Manuel utilisateur

Extech Instruments

Extech Instruments MO220 Manuel utilisateur

Extech Instruments

Extech Instruments SL510 Manuel utilisateur

Extech Instruments

Extech Instruments 407768 Manuel utilisateur

Extech Instruments

Extech Instruments EC210 Manuel utilisateur

Extech Instruments

Extech Instruments UV510-NIST Manuel utilisateur

Extech Instruments

Extech Instruments 407355 Manuel utilisateur

Extech Instruments

Extech Instruments HT200 Manuel utilisateur

Extech Instruments

Extech Instruments 461893 Manuel utilisateur

Extech Instruments

Extech Instruments 407820 Manuel utilisateur

Extech Instruments

Extech Instruments HD300-NISTL Manuel utilisateur

Extech Instruments

Extech Instruments 461920 Manuel utilisateur

Extech Instruments

Extech Instruments HD750-NIST Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
