The EVGA X570 DARK brings the exclusive DARK experience to Team Red for the rst time. This

motherboard evolved through a comprehensive design overhaul to squeeze out the full

performance of the legendary AMD Zen 3 processors. With a highly-ecient 17-phase digital

VRM design, 10-layer PCB, and two built-in VRM fans, it's no wonder that some tried to fool you

with DARK imitations. Powered with unmatched multi-core performance and energy eciency,

the EVGA X570 DARK unshackles your PC with PCIe Gen4 support for the latest graphics cards

and M.2 storage, lightning-fast 4800MHz+(OC) memory support, two Intel 2.5 Gb/s NICs, Wi-Fi

6/BT 5.2, plus an abundance of SATA 6Gb/s ports and USB options. The search for the pinnacle

of desktop PC performance is over: this is the way.

Supported CPUs -

AMD Ryzen™ 5000, 3000 Desktop Processors

Socket Type - AMD AM4 Socket

Chipset - AMD X570

PCIe Slots - 2x PCIe 4.0 x16 (x16, x8/8), 1x PCIe 4.0 x4

Memory DIMMs - 2 DIMMs Dual-Channel

Memory Type - DDR4 4800MHz+ (OC)

Memory Capacity - 64GB

SATA 6 Gb/s Ports/Controller - 8 from AMD X570

RAID Support - RAID 0, 1, 10

M.2 Key-M Sockets - 2x 110mm PCIe 4.0 (Up to 64Gb/s)

M.2 Key-E Sockets - 1x 32mm

Internal USB Ports/Headers -

1x USB 2.0 Port (for BIOS update), 2x USB 2.0 Headers,

1x USB 3.2 Gen1 Header, 1x USB 3.2 Gen2 Type-C Header

17 Phase Digital VRM

Preinstalled Rear I/O Cover

EVGA Wi-Fi Antenna

PCI Express 4.0 Ready

NVIDA® SLI® Ready Enthusiast Layout

Supports NVIDIA® Resizable BAR

Metal Reinforced PCIe slots

DIMENSIONS

Width: 10.9in - 277mm

Length: 12in - 305mm

Form Factor: E-ATX Form Factor

ACCESSORIES

EVGA Quick Installation Guide

M.2 Key-M Thermal Pads

SATA 6Gb/s Data Cables

EVGA Wi-Fi Antenna

Probelt Cable

Baseplate

Baseplate Screws and Standos

Case Badge

M.2 Screw Kit

USB Flash Drive

+ Contains Drivers and Manual

Part No: 121-VR-A579-KR

Rear I/O USB Ports-

2x USB 3.2 Gen1 Type-A, 4x USB 3.2 Gen2 Type-A, 1x USB 3.2

Gen2 Type-C

Network Speed - 10/100/1000/2.5Gbps

Network Controller - 2x Intel® I225-V 2.5 Gigabit NICs

Wi-Fi/BT –

Intel® AX200 Wi-Fi 6/BT 5.2 module,

preinstalled in the M.2 Key-E 32mm Slot

Audio - 7.1 Channel Realtek 1220, EVGA NU Audio

Fan Headers - 2x CPU PWM, 4x PWM/DC, 2x PUMP Headers

RGB Headers - 2x RGB Headers, 2x ARGB Headers

BIOS Type -

Latest UEFI BIOS with mouse/keyboard control,

OC Robot, In-BIOS Stress Test

Software - EVGA ELEET X1 Tuning Utility

DESIGN DE

AILS

TAILST

17 PHASE PWM

NVIDIA® SLI® READY

WITH REINFORCED PCIE SLOTS

SUPPORTS NVIDIA®

RESIZABLE BAR

HEATSINK WITH TWIN FANS

EVGA WIFI ANTENNA DEDICATED PUMP

HEADERS FOR AIO SUPPORT ELEET X1™TUNING UTILITY

PCIE GEN4 M.2 NVME SUPPORT

Part No: 121-VR-A579-KR FEATURES

PRODUCT WARRANTY

This product is covered under EVGA’s 3 year limited warranty which covers parts and labor. Further warranty extension

is available upon registration within 90 days of purchase. For more details please visit: www.evga.com/warranty

X570 DARK

RIGHT ANGLE POWER CONNECTORS

SUPPORTS NVIDIA®

TUNING UTILITY

Part No: 121-VR-A579

-KR

FEATURES

RIGHT ANGLE POWER CONNECTORS
