Overview

The Aero Micro Relay Controller (UAMR) controls lighting loads when a

received input from a linked sensor or switch is changed.

The UAMR controls loads based on the following:

• switch actions from an Aero SmartClick Switch Station

• ambient light levels as monitored by an Aero Light Sensor

• occupancy state as monitored by an Aero Occupancy Sensor

• input from another Aero device

ETC Installation Guide

Micro Relay Controller

Micro Relay Controller Install Guide Page 2 of 4

Placement and Radio Range

The UAMR is intended for use with Aero sensors and stations. Consideration

should be made for locating the controllers based on the construction materials

and furniture that may disrupt transmissions. Fire doors, elevator shafts,

stairwells, storage areas and any large metal objects can create radio shadows

and disrupt wireless transmissions.

It is recommended that stations and sensors be placed with in 50 feet (15m) of

the UAMR controller for optimal performance.

Typical Radio Range

Material Range - typical

Line of sight 100 feet (30m) corridors

Line of sight 330 feet (100m) open halls

Plasterboard 100 feet (30m) through 5

walls

Brick 65 feet (20m) through 3 walls

Concrete 65 feet (20m) through 3 walls

FerroConcrete 33 feet (10m)

Ceiling 1 ceiling

Signal Loss

Material Attenuation

Wood/Plaster/Glass 0-10%

Brick/MDF 5-35%

Metal 90-100%

ETC Installation Guide

Power Series

Page 3 of 4 Micro Relay Controller Install Guide

Installation

The UAMR is mounted directly to an electrical junction box or panel at the load

or before the load in the circuit.

Step 1: Locate the circuit breaker panel and turn off the power to the circuit.

Step 2: Remove face plates and other hardware from the junction box, gaining

access to the high voltage wiring.

Step 3: The UAMR mounts inside the junction box or panel.

Step 4: The UAMR controller is provided with a wire harness that serves

120 - 277 VAC power requirements. Refer to the wiring diagram above

to connect power to the controller.

a: Connect the black wire to the line input feed wire.

b: Connect the white wire to the incoming Neutral wire.

c: Connect the red (relay output) to the lighting load.

Step 5: Replace the junction box face plate and hardware.

Note:

If the circuit will have an additional hard wired switch, wire the

UAMR in series before the switch.

WARNING:

Risk of electric shock! The UAMR utilizes high voltage and

should only be installed by a qualified installer or electrician.

Follow all local codes for installation. Before terminating the

AC power wiring verify the main breaker is in the off position

and follow the proper lockout/tag out procedures per NFPA

Standard 70E.

WARNING:

For indoor use only! Must install in an electrical junction box

or wire way.

CAUTION:

The UAMR has an orange external antenna that extends off

one end of the unit. Do not cut, cap, or connect this wire.

Note:

Follow all local code requirements for terminating wiring.

Notice the harness wires on the controller unit are pre-stripped

for your installation convenience.

RANGE

(

ANTENNA

)

HITE

(

NEUTRAL

)

REEN

(

GROUND

)

LACK

(120 - 277VAC)

WIRELESS

OTHER

DEVICES

UNISON AERO MICRO

RELAY CONTROLLER

(UAMR)

OAD

(

RELAY

OUTPUT

)

ETC Installation Guide

Micro Relay Controller

Micro Relay Controller Install Guide Page 4 of 4

Power Up and Test

For detailed programming and configuration information, please reference the

Unison Aero 902 MHz User Programming Guide. ETC documentation is

available for free download at www.etcconnect.com.

Step 1: Restore power to the circuit.

Step 2: Test the circuit by linking a Unison Aero Wireless Switch.

a: Within radio range of the controller, press the toggle switch up (On) three

times consecutively.

b: Press the toggle switch down (Off) three times consecutively.

c: Press the toggle switch up again, three times consecutively.

Step 3: Test the controller response.

a: Press the toggle switch “Off” once. The controlled lighting should respond

by turning off.

b: Press the toggle switch “On” once. The controlled lighting should respond

by turning on.

Note:

The linking method described in “Step 2” will learn the Unison

Aero Wireless Switch to any controllers that are within radio

range that do not already have stations linked to them.

Contains FCC ID: SZV-TCM320U

The enclosed device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(i.) this device may not cause harmful interference and

(ii.) this device must accept any interference received, including

interference that may cause undesired operation.

Contains IC: 5713A-TCM320U
