Essentials CBCONX18 Manuel de service

Built-In Oven

Installation / Instruction Manual

CBCONX18 / CBCONW18

Currys Essentials Built in Oven CBCONX18 Manual.indd 1 05/11/2018 16:45

Currys Essentials Built in Oven CBCONX18 Manual.indd 2 05/11/2018 16:45

Contents

Safety Warnings............................................................................................................................ 4

Unpacking..................................................................................................................................... 6

Installation .................................................................................................................................... 7

Use a Competent Person or Qualied Electrician ...................................................................... 7

Installing the Built-in Oven.......................................................................................................... 8

Making an Electrical Connection................................................................................................. 9

Terminal Box Connections ........................................................................................................... 9

Product Overview....................................................................................................................... 10

Front View ................................................................................................................................................................10

Control Panel........................................................................................................................................................... 10

First Time Use of the Oven ......................................................................................................... 11

Function Selector Control .......................................................................................................... 11

Thermostat Control .................................................................................................................... 11

Replacing the Anti-tilting Oven Shelf....................................................................................... 11

Using the Oven ........................................................................................................................... 12

Using the Functions.................................................................................................................... 13

Baking Tips.................................................................................................................................. 13

Energy Saving ............................................................................................................................. 13

Cleaning Tips............................................................................................................................... 14

Cleaning the Outside of the Oven............................................................................................. 14

Cleaning the Oven Door Glass................................................................................................... 14

Removing the Door for Easier Cleaning.................................................................................... 15

Taking out the Glass from the Oven Door for Cleaning........................................................... 15

Replacing the Oven Light........................................................................................................... 15

Product Fiche and Specications .............................................................................................. 16

Energy Labels.............................................................................................................................. 17

- New Energy Label

February 2019.............................................................................................................................................. 17

Currys Essentials Built in Oven CBCONX18 Manual.indd 3 05/11/2018 16:45

Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

• It is recommended that this appliance is installed by a qualied electrical

engineer. The manufacturer is not responsible for any damage caused by

incorrect installation.

• Check whether there is any damage to the appliance after you have

unpacked it. If any damage is found, do not use the appliance and

contact the store where you purchased it.

• This appliance is for Indoor Domestic Use only.

• For disconnection from the mains supply you must have a switch with

a contact separation of at least 3.0 mm in all poles and suitably rated that

provides full disconnection, this must be incorporated in the xed wiring

in accordance with the local wiring rules.

• If your mains cable gets damaged, it should be replaced by an authorized

service agent or qualied electrician in order to avoid a hazard.

• Only operate your appliance in a dry atmosphere.

• Ensure that the appliance is switched o at the mains supply switch

and allowed to completely cool down before cleaning, replacing the

oven lamp or performing any maintenance to avoid the possibility of an

electric shock.

• This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and

understand the hazards involved.

• Cleaning and user maintenance shall not be made by children without

supervision.

• Children should be supervised to ensure that they do not play with

the appliance.

• During use the appliance becomes hot. Care should be taken to avoid

touching the heating elements inside the oven.

• The appliance and its accessible parts become hot during use. Young

children should be kept away.

Currys Essentials Built in Oven CBCONX18 Manual.indd 4 05/11/2018 16:45

• Danger of re: Do not store items in the oven other than the accessories

supplied.

• When the oven is hot never touch the oven glass or any other parts that

get hot. Allow the oven to cool before touching these parts.

• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the

oven door glass since they can scratch the surface, which may result in

the glass shattering.

• Before starting to use your appliance, keep curtains, tulle, paper

or ammable materials away from your appliance. Do not keep

combustible or ammable things in or on the appliance.

• This appliance is for cooking purposes only. It must not be used for other

purposes, for example room heating.

• Do not use steam cleaners for cleaning the appliance.

• Do not rest any items on or stand on the open door.

• Take care when handling parts with glass, knocks, chips, heavy handling

and dropping could cause the glass to shatter.

• The glass oven door uses toughened glass and is designed to break into

many‘nugget’ size pieces if it breaks. These pieces will still have sharp

edges, please handle broken glass with care.

Currys Essentials Built in Oven CBCONX18 Manual.indd 5 05/11/2018 16:45

Unpacking

Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so

according to local regulations.

The following items are included:

Baking Pan Shelf x 1Grill Pan, Grill Rack and Handle Set x 1

The Main Unit

Wire Shelf x 1

240

Max

50°

100°

150°

200°

Thank you for purchasing your new Currys Essentials Built-In Oven.

You must read this manual in order to fully understand how to install and

operate it correctly.

Read all the safety warnings carefully before use and keep this manual for

future reference.

If items are missing or damaged please contact

Partmaster (UK only). Tel: 0344 800 3456 for assistance.

Currys Essentials Built in Oven CBCONX18 Manual.indd 6 05/11/2018 16:45

Installation

Use a Competent Person or Qualied Electrician

• This oven must be installed in compliance with local safety standards.

• Wiring connections must be in accordance with Local Wiring Rules and any particular conditions of the

local authority.

• Refer to data plate for rating information. The data plate is positioned behind the bottom of the oven door.

The electrical wiring diagram is positioned on the rear panel of the appliance.

• A means of disconnection with a contact separation of at least 3 mm must be supplied in the xed wiring.

• This appliance must be properly earthed.

• Do not lift the appliance by the door handles.

• Prepare the cupboard opening to match your appliance measurements. (See diagrams)

• Slide appliance into the cupboard, ensuring that the supply cable does not kink.

• To prevent tipping, secure your oven into the cupboard by fastening with the 2 screws supplied.

• The cabinet must be suitable for use in built in ovens and capable of withstanding 75°C Installation into low

temperature tolerant cabinetry (e.g. Vinyl coated) may result in deterioration of the low temperature coating

by discolouring or bubbling.

• We cannot accept responsibility for damage caused by installation into low temperature tolerant cabinets.

• After installation, test and ensure that the appliance operates correctly.

• The electrical connection of this oven should be carried out by a competent person, if in doubt consult

a qualied electrician, according to the instructions in this installation section and in compliance with

the current regulations.

• The oven is intended for indoor domestic use only.

• The manufacturer reserves the right to introduce changes which do not aect the operation of

the appliance.

To avoid any potential hazard, you must follow our instructions when you install your appliance.

Failure to install the appliance correctly could invalidate any warranty or liability claims.

Currys Essentials Built in Oven CBCONX18 Manual.indd 7 05/11/2018 16:45

Installing the Built-in Oven

1. The space where the oven will be placed needs to be at least 560 mm wide, 555 mm deep and 600 mm high.

A minimum gap of 2.5 cm between the work surface and the control panel, and a distance of 5 cm between

the work surface and top of the oven is needed, in order to be able to get to the back of the oven if necessary

and for easy access when sliding the oven out.

2. Ensure the electrical connections have been made.

3. Insert the oven into the cabinet by pushing it back into the space within the cabinet (Ensuring the electrical

cable is not trapped or touching hot parts). Open the door carefully, and insert the xing screws through the

spacers into the xing surface of the cabinet, ensure the front frame of the oven is touching the xing surface

of the cabinet and tighten the xing screws to hold the oven in place securely.

Cabinet cut - out sizes

60cm

58cm

56cm

60cm

Countertop

Built-in oven

Min.2.5cm

Control

panel

Distance between

countertop and

control panel

Built-in hob

Distance between

countertop and

top panel of built-in

oven

Min. 5cm

557mm

550mm

575mm

576mm

595mm

Mounting screws

Mounting

screw

Front

frame

Cabinet

edge

Spacer

Cabinet cut - out sizes

600mm

555mm

Min 560mm

Max 565mm

Countertop

Built-in oven

Min.2.5cm

Control

panel

Distance between

countertop and

control panel

Built-in hob

Distance between

countertop and

top panel of built-in

oven

Min. 5cm

Currys Essentials Built in Oven CBCONX18 Manual.indd 8 05/11/2018 16:45

Making an Electrical Connection

An approved suitable cable must be connected from the Consumer Unit (main fuse box)and be protected by its

own 30 amp fuse or Micro Circuit Breaker (MCB).

The electrician must provide a fused double-pole isolation switch, which disconnects both the line (live) and

neutral conductors, with a contact separation of at least 3 mm incorporated into the xed wiring. The fused

switch should be tted to the kitchen wall, and must be placed in an easy accessible position in accordance with

IEE regulations. Connect the fused switch to a junction box which should be tted on the wall. The ovens power

supply cable can then be connected. Connect one end to the junction box and connect the other end to the

ovens power connection box which is located at the back of the oven. Remove the cover of the power connection

box and install the cable, in accordance with the connection diagram. The power supply cable must be positioned

away from direct heat sources. It should not be subjected to a temperature rise of more than 50°C above room

temperature.

Terminal Box Connections

For this oven, the cable type must be a minimum of H05VV-F

(PVC insulated and sheathed) 3 cores x 4 mm2and the

connection should be made as detailed below.

Green / Yellow (Earth) to the PE ( ) terminal

Brown (Live) wire to the terminal marked L

Blue (Neutral) wire to the terminal marked N

Ensure the cable exits through the cable grip, clamping on

the outer sheath of the cable, and x in place by tightening

the xing screw.

Ensure all connections are adequately tightened. Do not over

tighten as you may risk damaging the threads.

This appliance must be earthed.

For this connection, ‘Twin and Earth 6242Y’

type cable can be used.

L N

Currys Essentials Built in Oven CBCONX18 Manual.indd 9 05/11/2018 16:45

Product Overview

Front View

Control Panel

240

Function Selector

Control

Thermostat Control

Oven Indicator

Lamp

Thermostat

Lamp

240

Max

50°

100°

150°

200°

Control Panel

Shelf Guide Slots

Baking Pan

Shelf

Wire Shelf

Currys Essentials Built in Oven CBCONX18 Manual.indd 10 05/11/2018 16:45

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Essentials Four

Essentials

Essentials XHT30 Manuel utilisateur

Essentials

Essentials CFSGSV17 Manuel utilisateur

Essentials

Essentials 7367674 Manuel utilisateur

Essentials

Essentials ESS600SS Mise à jour du firmware

Essentials

Essentials ESS630SS Mise à jour du firmware

Essentials

Essentials GH30-S1 Manuel utilisateur

Essentials

Essentials GH25-S1 Manuel utilisateur

Manuels Four populaires d'autres marques

Bosch

Bosch HVA531NS0 Manuel utilisateur

Electrolux

Electrolux EOF6P46X Manuel utilisateur

NEFF

NEFF B44S32 5GB Series Manuel utilisateur

Combi

Combi BLODGETT BC142GDS Manuel utilisateur

AEG

AEG COMPETENCE 311704300 Manuel utilisateur

Falcon

Falcon DOMINATOR PLUS G3106 Series Guide de l'utilisateur

Rational

Rational SCC WE 61G Manuel utilisateur

Smeg

Smeg DOSPA38X Manuel d'installation et d'exploitation

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manuel utilisateur

Miele

Miele HR 1954-2 Manuel utilisateur

KHIND

KHIND OT50 Manuel utilisateur

Henny Penny

Henny Penny Smoker Box Manuel utilisateur

Lang

Lang ECOD-AP Manuel utilisateur

AEG

AEG BEK455310M Manuel utilisateur

Frigidaire

Frigidaire FNGE90JGR Manuel utilisateur

Hotpoint

Hotpoint FE9 S831 JSH IX Manuel utilisateur

GE Advantium SCB2000 Manuel utilisateur

AEG

AEG DE401301DM Manuel utilisateur
