Erbauer ECD12-Li-2 Manuel utilisateur
ECD12-Li-2
ORIGINAL INSTRUCTIONS
EAN: 5059340010762
18
16
14
20
V100421 / BX220IM
Original Instructions - MNL_ECD12-Li-2_GB_V1_210623
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 1 4/22/21 6:19 PM
2
Safety instructions 8
Product description 21
Assembly 24
Use 27
Care & maintenance 33
Guarantee 36
Declaration of conformity 37
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 2 4/22/21 6:19 PM
3
1
x1
WARNING! Please read all safety warnings carefully and be
sure that they are fully understood before handling the tool.
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 3 4/22/21 6:20 PM
4
Product description
18
16
14
20
1
1b
1a 234
5
6
7
7a
8
9
10
10a
11
12
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 4 4/22/21 6:20 PM
5
A
10a
10
7
7a
2.
1. B
10
7a
C D
10
10c
10b
76-100%
51-75%
26-50%
5-25%
<5%
E F
9
8
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 5 4/22/21 6:20 PM
6
G
18
16
14
20
1b
1a
1
H
18
16
14
20
1
I J
18
16
14
20
18
16
14
20
12
6
K L
66
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 6 4/22/21 6:20 PM
7
M
6
N
4
1.2.
O P
32
Q
18
16
14
20
11
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 7 4/22/21 6:20 PM
8
Safety instructions
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow all
instructions listed below may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
WORK AREA SAFETY
a) Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
b) Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases
or dust. Power tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
a) Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs
with earthed (grounded) power tools. Unmodied plugs
and matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces,
such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is
earthed or grounded.
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 8 4/22/21 6:20 PM
9
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric
shock.
d) Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electric shock.
PERSONAL SAFETY
a) Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the inuence
of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal
injury.
b) Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power source
and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or
energising power tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to
a rotating part of the power tool may result in personal
injury.
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 9 4/22/21 6:20 PM
10
e) Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool
safety principles. A careless action can cause severe
injury within a fraction of a second.
POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from the
power tool before making any adjustments, changing
accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
d) Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool
or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
MNL_Erbauer_ECD12-Li-2_GB_12V Combi Drill_V10_210422.indd 10 4/22/21 6:20 PM
