Equinox Systems GEMINI-1 Manuel utilisateur

For the Philips FLASH

Microcontroller Families

USER

GUIDE

(Preliminary)

FIRMWARE

UPGRADABLE

User Guide V0.90

Philips is a trademark of Philips Semiconductors

Microsoft, MS-DOS, WindowsTM and Windows 95TM Windows NT™ are registered

trademarks of the Microsoft Corporation

IBM, PC and PS/2 are registered trademarks of International Business Machines

Corporation

Every effort was made to ensure accuracy in this manual and to give appropriate credit to

persons, companies and trademarks referenced herein.

It is against the law to copy the software on any

medium except as specifically allowed in the

license or non-disclosure agreement.

The purchaser may make one copy of the

software for backup purposes. No part of this

manual may be reproduced or transmitted in any

form or by any means, electronic, mechanical,

including photocopying, recording, or

information retrieval systems, for any purpose

other than for the purchaser’s personal use,

without written permission.

Equinox guarantees that its products will be

free from defects of material and

workmanship under normal use and service,

and these products will perform to current

specifications in accordance with, and subject

to, the Company’s standard warranty.

Equinox reserves the right to change

specifications detailed in this document

without notice and does not represent a

commitment on the part of the manufacturer.

The software described in this document is

furnished under license agreement or

non-disclosure agreement

and may be used or

copied only in accordance with the terms of the

agreement.

Disclaimer

Please note about diagrams contained

within this document:

Whilst suggested circuits are offered in

good faith, Equinox will not be liable in

any way for any problems which might

arise out of their use.

The GEMINI-1 Programmer is a CE Approved Product. It is designed only for use in a

development environment only. This means that the user must ensure that there is no

possibility of damage from electrostatic discharge (ESD). Since the devices and equipment to

which this product is likely to be connected may well themselves be susceptible to ESD, this

should not pose any difficulty.

For example, if you are handling microcontrollers and EEPROMS etc. then you will already be

used to appropriate precautions, such as the use of anti-static mats, wrist straps and so on.

You should treat your GEMINI-1 with the same care as you would these type of device.

Always ensure that you are not yourself carrying a static charge before handling the product.

Wearing an earthed anti-static wrist strap is recommended.

Equinox have taken great care in designing this product to be compliant with the European

EMC directive. When using the equipment be sure to follow the instructions provided.

Although RF emissions are within prescribed limits, care should be taken if you are using the

product near to sensitive apparatus. If you experience any difficulty please refer to Equinox

technical support.

ESD Points to remember

●Work in a static-free environment.

●Wear an earthed wrist strap when handling either the programmer

and/or any programmable device.

User Guide V0.90

Electromagnetic Compatibility (EMC) Compliance

Please Note:

This equipment is designed for use in a ‘Development Environment’ only and is

NOT guaranteed to operate correctly in a ‘Production Environment’.

Use of this product in a ‘Production Environment’ will invalidate your warranty.

User Guide V0.90

iii

It is often the case that users experience problems when installing or using a product for the first time.

Due to the low-cost nature of this product, Equinox are unable to answer technical support questions

about this product or its use by telephone.

If you have a technical support problem, please consult the following list for help:

1This manual

2 Troubleshooting Guide (see page 25)

3On-line help

Press <F1> for help at any time.

The help system is context-sensitive. Simply press <F1> on any error message and the possible

causes of the error should be listed. This help system is updated on a regular basis. Please see

software update details for information on keeping up-to-date with software revisions.

Please note: The help system does not work within Windows 3.11

4 Internet Web Site

Equinox have setup a Philips microcontroller support page on our web site. This page is designed

to provide up-to date information on all issues concerning both Philips microcontrollers and support

tools.

The microcontroller support page can be found at: www.equinox-tech.com/philips

5 E-mail

Please e-mail any technical support questions about this product to: [email protected]

Equinox will try our best to answer your questions about this product as quickly as possible.

However, we can not promise an immediate reply. Please consult our web site for new software

updates as the problem that you are enquiring about may have already been fixed in a new version.

6 Fax

Please fax any technical support questions about this product to: +44 (0) 1204 535555

Equinox will try our best to answer your questions about this product as quickly as possible.

However, we can not promise an immediate reply. Please consult our web site for new software

updates as the problem that you are enquiring about may have already been fixed in a new version.

Technical Support

User Guide V0.90

Contacts

Equinox Technologies UK Limited

3 Atlas House, St Georges Square, Bolton, England BL1 2HB

Telephone Sales ....................... : +44 (0) 1204 529000

Fax ........................................... : +44 (0) 1204 535555

E-mail ...................................... : [email protected]

Web site .................................. : www.equinox-tech.com

For technical support on this product please e-mail us at:

[email protected]

In line with our policy of continuous improvement, the ‘Gemini’ software is updated on a

regular basis. The firmware of the actual programmer is also periodically updated. If you

would like to receive an automatic e-mail every time a new version is released, please make

sure you have registered your system with Equinox and you have quoted your e-mail address.

You may cancel this service at any time.

The Meridian software updates can currently be downloaded from the following

places:

Internet : www.equinox-tech.com

Select <Software> This will take you to the software download page

Software Updates

User Guide V0.90

About Philips Microcontrollers

Philips manufacture a complete family of In-System Programmable (ISP) 8051 FLASH

microcontrollers each with differing FLASH & SRAM. Data sheets for these devices

can be viewed and printed using the Acrobat pdf reader software supplied on the

Philips CD-ROM. As data sheets are often updated on a regular basis, it is

recommended that you consult the Philips web site for the latest information.

A few sources of further information about Philips microcontrollers are listed below:

Philips web site : http://www.philips.com

Equinox web site : www.equinox-tech.com/philips

If you have any silicon related technical support question about Philips 8051 FLASH

microcontrollers which can not be answered by looking at the Philips/Equinox web

sites, please e-mail us with a detailed description of the problem at:

[email protected]

Important - Please note

Equinox Technologies are unable to answer direct technical support questions

concerning Philips microcontrollers. Please contact your local Philips distributor or

sales office if you require any further information.

User Guide V0.90

Contents

Introduction.........................................................................1

Device Support....................................................................2

System Specifications .........................................................3

Hardware Overview ...........................................................4

Hardware/Software Installation Overview ......................5

Gemini for Windows Overview .........................................6

Hardware Installation Instructions ....................................7

Serial Port Selection............................................................9

Software Overview...........................................................10

Device Programming Guide .............................................12

In-System Programming Overview..................................18

ISP Header Pin Assignments ............................................19

Target System Requirements ...........................................20

Philips 8051 FLASH Microcontroller - ISP Notes .............21

Upgrading the Programmer Firmware............................23

Gemini-1 Compatible Target Systems .............................24

Troubleshooting Guide .....................................................25

User Guide V0.90

Introduction

Supports In-System Programming (ISP) of

the following microcontroller families:

• Philips P89C51Rx+ (+12V Vpp)

• Philips P89C51Rx2 (No Vpp required)

• Powerful ‘GEMINI’ programmer

interface software:

••Compatible with Windows 3.1, 95, 98 and NT

••Device commands include Check Signature,

Blank Check, Erase, Read, Write, Verify, Security,

Auto-program

••Powerful buffer system with Blank Check, Erase,

Fill, Goto and Checksum commands

••Supports reading and writing of target device

fuse bits and lock bits

••Supports Binary and Intel HEX file formats

••User-configurable

~ RESET polarity

~ RESET timing state machine

~ Target Baud Rate

••Context-sensitive help system

•Field upgradable firmware via

Internet downloadable utility -

caters for new programmer

algorithms in the future

• On-board Vpp generator (+12V)

•Programmer ‘Active’ signal - used to

drive an LED on the target system

• Connects to spare PC COM (serial)

port

• Robust ‘EMC-friendly’ design plus

I/O pin protection

• CE compliant product

The GEMINI-1 is a state-of-the-art device

programmer supporting the new range of

In-System Programmable (ISP)

microcontrollers from Philips. These

microcontrollers feature serially

downloadable memory allowing both CODE

and DATA (if device features EEPROM) areas

to be updated in-system without physically

removing the target device from the

application board. The serial programming

is through the on-chip UART.

Please Note:

This programmer is designed for development

use only.

GEMINI-1 DEVICE PROGRAMMER

HIGHLIGHTS

Order Code: EQ-GEM1 (4.8-5.0V)

Device FLASH Code SRAM I/O Pins Vpp Programming

Size (Bytes) (Bytes) Mode Supported

P89C51RA+ 8K 32 +12V ISP

P89C51RB+ 16K 32 +12V ISP

P89C51RC+ 32K 512 32 +12V ISP

P89C51RD+ 64K 1K 32 +12V ISP

P89C51RB2 16K 512 32 +5V ISP

P89C51RC2 32K 512 32 +5V ISP

P89C51RD2 64K 1K 32 +5V ISP

User Guide V0.90

Device Support

Philips FLASH Microcontroller Family

CAUTION: Make sure you do not exceed the maximum voltage of the target device.

Key

ISP = In-System Programming Mode

User Guide V0.90

System Specifications

Minimum System Contents

•GEMINI-1 Serial Download Programmer

• PC Serial extension cable set

• Windows Driver Software

• Equinox CD-ROM

• GEMINI-1 User Guide

GEMINI-1 Serial Programmer Specifications

Programmer Size : 55 x 53 x 16mm

Shipped Weight : Approx 0.10kg

PC Connection : Serial Port 25-pin female D Connector

Programming Cable : Length 300mm

Header : 10-way IDC 0.1” pitch bump polarised

Power Supply : Requires power from target system or external power supply.

GEMINI-1 Vcc. 4.8 - 6.0V

- Is(supply) approx 50mA when programming

- Is(supply) approx 27mA in standby

Minimum PC requirements

The minimum hardware and software requirements to ensure that the programmer operates

correctly are as follows:

• 100% IBM compatible 386+

• Windows 3.1 or higher

• Minimum 4MB RAM

• Minimum 1MB free hard disk space

• Spare PC serial port

Table des matières

Autres manuels Equinox Systems Carte mère

Equinox Systems

Equinox Systems ISPnano IV-ATE Series Instructions d'utilisation

Equinox Systems

Equinox Systems Micro-ISP IV Series Manuel utilisateur

Equinox Systems

Equinox Systems AVR Professional Starter System Manuel utilisateur

Equinox Systems

Equinox Systems ISP juno Manuel utilisateur

Equinox Systems

Equinox Systems PPM3 MK2 Manuel utilisateur

Equinox Systems

Equinox Systems FS2003 Manuel utilisateur

Equinox Systems

Equinox Systems Epsilon 5 Manuel utilisateur

Manuels Carte mère populaires d'autres marques

DFI

DFI SD170 Manuel utilisateur

ASROCK

ASROCK ROMED8-2T Manuel utilisateur

Asus

Asus P2L97A Manuel utilisateur

Winmate

Winmate IC70 Manuel utilisateur

Asus

Asus MES-B Manuel utilisateur

Grantech

Grantech SYS8F377VGGA-3OMN Manuel utilisateur

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuel utilisateur

Gigabyte

Gigabyte GA-9IVDT Manuel utilisateur

Texas Instruments

Texas Instruments ADS8372EVM Manuel utilisateur

Commell

Commell MS-C73 Manuel utilisateur

IBT Technologies

IBT Technologies MB860 Manuel utilisateur

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur

Biostar

Biostar M7VIT Bravo Instructions d'utilisation et d'installation

Intel

Intel D33217CK Manuel utilisateur

Asus

Asus F1A55-M LX PLUS R2.0 Manuel utilisateur

EPC

EPC EPC9147C Manuel utilisateur

Asus

Asus EX-B760M-V5 D4 Manuel utilisateur

EPOX

EPOX MU-8KHA0010 Manuel utilisateur
