Epson PowerLite S1 Manuel utilisateur

User’s Guide

EPSON PowerLiteS1

Meaning of Symbols

The terms ‘this unit’ and ‘this projector’ which appear in this manual may also refer to the accessories supplied with the projector and other optional products.

recording, or otherwise, without the prior written permission of SEIKO EPSON CORPORATION. The information contained herein is designed only for use with this EPSON

product. EPSON is not responsible for any use of this information as applied to other products.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses incurred by

purchaser or third parties as a result of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.)

failure to strictly comply with SEIKO EPSON CORPORATION’s operating and maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those designated

as Original EPSON Products or EPSON Approved Products by SEIKO EPSON CORPORATION.

EPSON is a registered trademark of SEIKO EPSON CORPORATION.

EPSON Connection, EPSON Store, and Extra Care are service marks; and PrivateLine, Presenters Club, and PowerLite are registered trademarks of Epson America, Inc.

General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. EPSON disclaims any and all rights in

those marks.

cIndicates the possibility that people may be injured or the equipment may be damaged if these symbols are ignored.

pIndicates important related information or useful information and things you should know.

sIndicates related topics and pages which contain more detailed information.

gProvides terminology definitions. See “Glossary” on page 61.

Features

Auto setup (Computer

connections)

The projector analyzes the signal of the

computer to which it is connected and

automatically makes adjustments to

ensure optimal projection results. See

“Functions for Enhancing Projection”on

page 29.

Color mode

Image quality can be selected

according to the type of scene. See

“Selecting a color mode” on page 29.

Compact and lightweight

The projector is compact and easy to

carry.

◗Dimensions:

10.4 (d) × 14.6 (w) × 4.2 (h) inches

26.5 (d) × 37 (w) × 10.6 (h) cm

◗Weight:

approximately 7 lbs (3.2 kg)

Clear, vivid, images

The projector's high resolution and high

luminance achieves a legible display.

Project sharp, detailed images, even in

bright places.

Ease of use

Various projector operations can be easily

performed using the included remote

controls, as follows:

◗pausing projection

◗zooming in on important areas of an


Unique presentation function

The mouse pointer can be moved

around on the computer screen during

projection using the included

presentation remote control.

(wireless mouse)

Contents

Before Using the Projector

Part Names and Functions 6

Front/Top 6

Control panel 7

Rear 8

Base 9

Remote Control 10

Installation 12

Installation method 12

Projection distance and screen size 12

Other installation methods 13

Connecting to a Computer 14

Compatible computers 14

Projecting images from a computer 14

Playing sound from a computer 15

Connecting to an external monitor 16

Presentation Remote Control 16

Connecting to Video Equipment 20

Projecting video images 20

Playing sound from video equipment 21

Basic Operation

Turning on the Projector 22

Turning off the Projector 24

Adjusting the Display 25

Adjusting the projection size 25

Setting the focus 25

Adjusting the projection angle 26

Keystone 27

Selecting the Input Source 28

Advanced Operation

Functions for Enhancing Projection 29

Adjusting computer generated images 29

Selecting a color mode 29

A/V Mute 30

Freeze 30

Projecting in widescreen (changing aspect ratio) 31

E-Zoom 31

Configuration Menus 32

Menu operation 33

Function list 36

Troubleshooting

When You Suspect a Problem 43

Power indicator 43

Warning indicator 44

When the indicators provide no help 45

Where to Get Help 53

Telephone Support Services 53

Appendix

Projector Care 54

Cleaning 54

Replacing consumables 56

Optional Accessories 60

Glossary 61

Cable Format 63

Supported Display Resolutions 64

Specifications 65

Important Safety Instructions 66

FCC Compliance Statement 68

Warranty 69

Index

Part Names and Functions

Before Using the Projector

Part Names and Functions

Front/Top

•remote control infrared receiver sP. 11

Receives signals from the remote control.

•ventilation outlet

•lens cover

Attach when not using the projector to prevent the

lens from becoming dirty or damaged.

•focus ring sP.25

Adjusts the image focus.

•front foot (left) sP.26

Another front foot is located on the

right side.

Extend and retract to adjust the

projection angle.

•foot button (left) sP.26

Another foot button is located on the

right side.

Press both buttons when extending

and retracting the front feet.

•speaker

•handle

Pull out this handle to use when

carrying the projector.

•control panel sP. 7

Part Names and Functions

Control panel

•[Power] button sP.22

Turns the projector on and off.

•Power indicator sP.22, P.43

Flashes or lights in different colors to

indicate the operating status of the

projector.

•[u][d][l][r] buttons sP.33

•[u][d]: keystone correction buttons sP.27

Press to correct keystone distortion in images.

•[Wide][Tele]: zoom buttons sP.25

•Warning indicator sP.44

Flashes or lights in different colors to

alert you to problems with the projector.

•[Menu] button sP.32

Displays or hides the

configuration menus.

•[Source] button sP.28

Switches the input source

between the Computer/

Component Video port,

S-Video port and Video port

each time the button is pressed.

•[e] button sP.34

Accepts a menu item or

advances to the next screen or

menu when viewing

configuration menus.

•[Esc] button sP.35

Stops the current function.

Displays the previous screen or

menu when viewing

configuration menus.

Part Names and Functions

Rear

•Computer/Component Video port

sP. 14, P. 20

Inputs analog video signals from a

computer and Component Videog

signals from other video sources.

•Monitor Out port sP. 16

Outputs the projected analog

computer signal to an external

monitor. This feature is not available

for video signals.

•remote control infrared receiver

sP. 11

Receives signals from the remote

control.

•power inlet sP.22

Connects the power cable.

•Video port sP. 20

Inputs Composite Videogsignals to

the projector.

Connect using an A/V cable.

•S-Video port sP. 20

Inputs S-Videogsignals to the

projector.

Connect using an S-Video cable.

•security lock sP.62

•Audio port sP. 15, P. 21

Inputs audio signals to the projector.

Connect using an A/V cable, or a stereo

RCA cable.

When using computer and video

equipment alternately, swap the cable or

use an audio switch.

•Control (RS-232C) port sP.63

Connects the projector to a computer using an

RS-232C cable. This port is for control use and

should not be used by the customer.

•remote control holder sP. 11

Store the remote control in here when

not in use.

Part Names and Functions

Base

•ceiling mount holes (3 points)

Install the optional ceiling mount

here when suspending the projector

from the ceiling.

•lamp cover sP.57

Open this cover when replacing the

lamp inside the projector.

•air filter (air intake vent) s

P.55, P.59

Prevents dust and other foreign

particles from being drawn into

the projector. When replacing

the lamp, replace the air filter

also.

•handle

Pull out this handle to use when

carrying the projector.

•rubber foot

Remote Control

•remote control infrared transmitter

Transmits remote control signals.

•[Aspect] button sP.31

Changes the aspect ratio of images from 4:3 to 16:9.

•[Source] buttons sP.28

[Computer]: Switches to the signal source being input

to the Computer/Component Video port.

[S-Video/Video]: Switches between the signal source

being input to the S-Video port and the Video port.

•[E-Zoom] buttons sP.31

z: Enlarges part of the image without changing the size

of the projection area.

x: Reduces the part of the image that has been

enlarged using the [z] button.

•[Esc] button sP.35

Stops the current function.

Displays the previous screen or menu when viewing

configuration menus.

•[e] button sP.34

Accepts a menu item or advances to the next

screen or menu when viewing configuration menus.

•[u][d][l][r] buttons sP.33

Selects menu items and setting values.

•[Power] button sP.22

Turns the projector on and off.

•[A/V Mute] button sP.30

Momentarily turns off the audio and video. •[Freeze] button sP.30

Keeps the current image on the screen.

•[Auto] button sP.29

Use this button to automatically adjust computer

images to their optimum settings when automatic

setup has been set to “OFF.”

•[Color Mode] button sP.29

Selects the color mode. The color mode changes in

the order of Dynamic, Presentation, Theatre, Living

Room and sRGBgeach time the button is pressed.

•[l][r]: volume buttons

Adjusts the volume.

•[Menu] button sP.32

Displays or hides the configuration menus.
