Epson EMP-710 Manuel utilisateur

Important Information

Please read the following important information about your

projector.

Important Safety Information

Warning:

Never look into the projector lens when the lamp is

switched on as the bright light can damage your eyes. Never let

children look into the lens when it is on.

Warning:

Never open any covers on the projector except the

lamp and filter covers. Dangerous electrical voltages inside

the projector can cause severe injury. Except as specifically

directed in this Owner’s Manual, do not attempt to service

this product yourself. Refer all servicing to qualified service

personnel.

Warning:

Keep the plastic bags for the projector, accessories

and optional parts out of the reach of children. Children

covering their heads with bags may result in death by

suffocation. Be particularly careful around small children.

Caution:

When you replace the lamp, never touch the new

bulb with your bare hands. The invisible residue left by the oil

on your hands may be shorten the bulb life. Use a cloth or

gloves to handle the new bulb.

Button Function

Power Turns the projector on or off.

Help Displays the Help menu.

Source Switches the image source in order of computer

→

S-video

→

composite video.If there is no S-video input, the switch toggles

between computer and composite video.

Enter Selects a menu option when the Help menu is displayed.

Keystone +/- Adjusts a trapezoid distorted image to normal.

Select Scrolls up and down, or right and left when the Help menu is

displayed.

operation panel operation indicator

zoom ring

focus ring

front foot

foot adjust lever

speaker

remote

control

receiver

Power

Source

Enter

Help

Keystone

Select

Operation Panel

EMP-710/700/500

UICK

TART

Button Function

Freeze Keeps the current computer or video image on the screen.

A/V Mute Turns off the audio and video output of the projector. To turn on the audio and video output,

press either the A/V mute button or Esc button again.

E-Zoom Pressing the right side of the button enlarges the image, pressing the left side of the button

reduces the image.

To display a portion of the enlarged image which is outside of the display area, press the

Enter button to scroll the image.

Power Turns the projector on or off.

Effect buttons Use to display special effects that have been assigned in the Effect menu.

Enter Use the enter button to navigate the menus or use the remote as a mouse pointer when the

projector is connected to the computer with the computer cable and the mouse cable.

You can also select a menu option by pressing the center of this button (Enter).

If you press the Enter when a menu or help is displayed, you access the next menu or screen.

When the image source is a computer, the Enter button acts as the mouse left click.

Illumination

button Lights up all buttons on the remote control for 10 seconds.

Esc Terminates the current function.

If you press the Esc button when a menu or help is displayed, you go back to the previous

screen or menu.

When the image source is a computer, the Esc button acts as the mouse right click.

Menu Displays or hides the menu.

Help Displays the Help menu.

Comp Switches to the computer image from Computer.

S-Video Switches to the video image from S-Video.

Video Switches to the image from Video.

Auto Optimizes the computer image.

Resize Switches between the Window display and Resizing display.

P in P Displays a subscreen on the main display. To display the subscreen, press the PinP button

once. To hide the subscreen, press it again.

To set the subscreen being displayed, press in the following order :

[Menu]

→

[Setting]

→

[P in P].

The default settings are as follows;

Subscreen size:1/9 division

Main screen input source:Computer

Subscreen input source:Video

To change the subscreen position, press the Enter button. The subscreen will move to the

selected direction.

Volume +/- Adjusts the volume.

Power

Freeze

A/V Mute

E-Zoom

R/C ON

OFF

Enter

Esc

Remote control

EMP-710/700/500

UICK

TART

DATA/VIDEO PROJECTOR

Owner’s Manual

retrieval system, or transmitted in any form or by any means, electronic,

mechanical, photocopying, recording, or otherwise, without the prior written

permission of SEIKO EPSON CORPORATION. No patent liability is

assumed with respect to the use of the information contained herein. Neither

is any liability assumed for damages resulting from the use of the information

contained herein.

Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to

the purchaser of this product or third parties for damages, losses, costs, or

expenses incurred by purchaser or third parties as a result of: accident, misuse,

or abuse of this product or unauthorized modifications, repairs, or alterations

to this product, or (excluding the U.S.) failure to strictly comply with SEIKO

EPSON CORPORATION’s operating and maintenance instructions.

SEIKO EPSON CORPORATION shall not be liable against any damages or

problems arising from the use of any options or any consumable products

other than those designated as Original EPSON Products or EPSON

Approved Products by SEIKO EPSON CORPORATION.

EPSON is a registered trademark and PowerLite is a trademark of SEIKO

EPSON CORPORATION.

General Notice:

The following trademarks and registered trademarks are the

property of their respective owners and are used in this publication for

identification purposes only.

•EPSON/Seiko Epson Corp.

•Macintosh, PowerBook/Apple Computer Corp.

•IBM/International Business Machines, Inc.

•Windows/Microsoft Corp.

Other product names used herein are also for identification purposes only and

may be trademarks of their respective owners. EPSON disclaims any and all

rights in those marks.

■ ■ ■ ■ ■ ■ ■ ■

iii

■

Contents

Contents iii

Introduction vii

Getting the Most Out of Your Projector................................ix

Optional Accessories...................................................................ix

About This Manual.................................................................x

Safety Instructions.................................................................xi

Where to Get Help..............................................................xiii

World Wide Web site................................................................xiii

Transporting your projector......................................................xiv

1 Installation 1

Unpacking the Projector.........................................................2

Additional Components.............................................................. 3

Setting Up the Projector.........................................................4

Connecting to a Computer.....................................................6

Connecting to a PC Desktop Computer ..................................... 7

Connecting to a PC Laptop Computer..................................... 10

Connecting to a Desktop Macintosh.........................................13

Connecting to a PowerBook..................................................... 17

Connecting to a Video Source ..............................................22

Connecting to an External Speaker or

PA System............................................................................25

2 Using the Projector 27

Contents

■ ■ ■ ■ ■ ■ ■ ■

Turning the Equipment On and Off.....................................29

Turning the Projector On and Off............................................ 29

Focusing and Positioning the Screen Image ..........................31

Resize Button........................................................................... 33

Controlling the Projector......................................................34

Using the Remote Control.......................................................35

Using the Operation Panel .......................................................38

Projector Status Indicators....................................................39

Operation Indicator.................................................................. 39

Lamp Indicator......................................................................... 40

Temperature Indicator.............................................................. 40

3 Using the Projector Menus 41

Accessing the Main Menu.....................................................42

Changing a Menu Setting.....................................................43

Menu Options......................................................................45

Video Menu (Image source = Computer) ................................. 45

Video Menu (Image source = Video)........................................ 47

Audio Menu............................................................................. 48

Effect Menu ............................................................................. 49

Setting Menu ........................................................................... 49

User's Logo Menu ...................................................................50

Reset All Menu......................................................................... 52

Advanced Menu ....................................................................... 53

About Menu............................................................................. 54

4 Maintenance 55

Cleaning the Lens.................................................................56

Cleaning the Projector Case..................................................56

Cleaning the Air Filter..........................................................57

Replacing the Lamp..............................................................58

5 Troubleshooting 61

Problems with the Projector..................................................62

Problems with the Image or Sound.......................................64

■ ■ ■ ■ ■ ■ ■ ■

Technical Specifications 67

Supported Monitor Displays.................................................69

Computer In connector pin assignments...............................71

Glossary 73

Index 75

World-Wide Warranty Terms 77

Contents

■ ■ ■ ■ ■ ■ ■ ■
