EPSON ELP-3500 Multimedia Projector

input/output connectors

“Ymte

contra,

foot release lever

Projector Specifications

General

Type of display

Size of liquid

crystal panels

Resolution

Image size

Projection

distance

Projection

method

Remote control

range

Internal speaker

system

optical aspect

ratio

Zoom ratio

Liquid crystal panel, Thin Film

Transistor (TFT)

1.32 inches (33.6 mm)

640 (horizontal) x 480 (vertical) pixels

21 to 300 inches (0.5 to 7 meters)

4 to 40 feet (1.2 to 12.3 meters)

Front projection only; no rear or upside-

down projection

33 feet (10 meters)

3 W monaural

4 x 3 (horizontal x vertical)

1:1.4

Projector lamp

Type UHP, AC

Power

100 W, 85 V

Part number

ELPLP02

Mechanical

Height

Width

Depth

Weight

Electrical

Voltage

Rated frequency

Power

Consumption

5.9 inches (13.7 cm)

11.2 inches (28.3 cm)

15.0 inches (38.1 cm)

14.8 lb (6.7 kg)

100 to 120

VAC and 200 to 240 VAC

50/60 Hz

150 W, 6 W in Sleep mode

ENERGY STAR Compliance

100 to 120

VAC, 1.5 A, 50/60 Hz

200 to 240 VAC, 0.8 A, 50/60 Hz

Environmental

Temperature

Humidity

Operation: 32 to

104”

F (0 to 40” C)

Storage: -4 to 140” F (-10 to

GO”

Operation: 20 to 80% RH,

non-condensing

Storage: 10 to 90% RH,

non-condensing

Supported monitor displays

The projector displays images at a resolution of 640 x 480

pixels. To display a higher resolution image, the projector

scales it to 640 x 480. The following table lists the display

formats supported by the projector:

Computer type Formats Resolutions

IBM PC and

VGA, VESA, JEGA

640 x 480

IBM PC compatible

CGA

640 x 200

640 x 400

SVGA

800 x 600

Apple Macintosh Standard 8 and

640 x 480

24-bit color monitor

832 x 624’

NEC PC

640 x 480

Note: The frequencies of some computers may not allow the image

to be displayed correctly.

Note: This projector is compatible with DDC-capable graphic

sub-systems and boards only.

The horizontal viewing area is adjustable.

11/96

ELP-3500 Multimedia Projector - 1

EPSON ELP-3500 Multimedia Projector

Projector Placement Guidelines

The distance between the projector and the screen determines

the actual image size. Use the general guidelines in the table

below to determine the proper distance.

Horizontal distance from

the projector

scraen

Vertical

distanoe


sixe

from the

projactor

(diagonal) Minimum

Maximum to the screen

300 inches N/A

484.3 inches 20.1 inches (51 cm)

(12.3

200

inches

;;;.Bmjnches

460.2 inches

13.4 inches

(34

cm)

(11.7

100 inches 161.4 inches 228.3 inches 6.7 inches

(17

cm)

(4.1

(5.8

80 inches 126 inches 181

inches 5.5 inches (14 cm)

(3.2

(4.6

60 inches 94.5 inches 137.8 inches 3.9 inches

(10

cm)

(2.4

(3.5

40 inches 63 inches 90.6 inches 2.8 inches

cm)

(1.6 ml

(2.3

30 inches 47.2 inches 66.9 inches

2.0 inches

cm1

(1.2

(1.7

21 inches

47.2 inches N/A

1.2 inches

cm)

Il.2

Status Lights

The control panel lights let you know the status of the

projector at a glance, as described below.

Status light

Function

Power

Steady orange:

Sleep mode.

Crhe

projector is plugged in, but

not operational.)

Steady green: Power is on, the projector lamp is lit, and the

projector is projecting.

Flashing green: The projector is cooling down.

Video,

Camp

Indicates whether video equipment Wiieo) or a

computer Camp) is currently selected as the

image source.

1, 2, 3

Indicates the currently selected setup memory

area.

Note: You cannot turn on theprojector when the power light is

flashing green to indicate the lamp is cooling down.

Monitor and VGA Connector Pin

Assignments

The monitor connector is a female video RGB, 15-pin micro-

D-style connector, and the VGA connector is a male video

RGB, 15-pin micro-D-style connector. The pin assignments

for both connectors are:

Input pin Signal

Red analog input

Green analog input with composite sync

3Blue analog input

4GND

GND

Red GND

Green GND

Blue GND

9+5v

Sync GND

GND

SDA

Horizontal sync/composite sync input

Vertical sync input

SCL+

Information Reference List

Engineering Change Notices

None.

Technical Information Bulletins

None.

Product Support Bulletins

None.

Related Documentation

4006226

EPSON ELP-3500 Multimedia Projector

User’s Guide

PL-ELP3500

EPSON ELP-3500 Multimedia Projector

Parts Price List

2 - ELP-3500 Multimedia Projector

11/96
