Epson SureColor SC-S70600 Manuel

Epson SureColor

Media Setup

SureColor SC-S70600 & SC-S50600

Monday, 3 December 12

Media Setup

•The new SureColor printers have speciﬁc setups for

handling media

•It is important that the rollers are set correctly to

allow for faultless operation

•Follow this guide to correctly set up the printer

•Engaging Low Pressure Rollers for Normal printing and

Single Pass printing when using White and Metallic

•Engaging High Pressure Rollers for Multi Pass printing

using White and Metallic

Monday, 3 December 12

Setting the Rollers to be

Engaged and Disengaged

•To disengage rollers move them away from

the Set Marks on the printer

Roller Set Marks

Rollers Disengaged

Monday, 3 December 12

Setting the Rollers to be

Engaged and Disengaged

•To engage rollers move them over the Set

Marks on the printer

Roller Set Marks

Rollers Engaged

Monday, 3 December 12

Single Pass Low Pressure

Roller Setup

•Setup for 64 inch media

Disengage High Pressure Rollers

Align Media to edge of Set Mark 1

Monday, 3 December 12

Single Pass Low Pressure

Roller Setup

•Setup for 60 inch media

Align Media to edge of Set Mark 2

Disengage High Pressure Rollers

Monday, 3 December 12

Single Pass Low Pressure

Roller Setup

•Setup for 54 inch media

Align Media to edge of Set Mark 2

Disengage High Pressure &

unused Low Pressure Rollers

Monday, 3 December 12

Single Pass Low Pressure

Roller Setup

•Setup for 50 inch media

Disengage High Pressure &

unused Low Pressure Rollers

Align Media to edge of Set Mark 3

Monday, 3 December 12

Single Pass Low Pressure

Roller Setup

•Setup for 44 inch media

Disengage High Pressure &

unused Low Pressure Rollers

Align Media to edge of Set Mark 3

Monday, 3 December 12

Single Pass Low Pressure

Roller Setup

•Setup for 40 inch media

Disengage High Pressure &

unused Low Pressure Rollers

Align Media to edge of Set Mark 1

Monday, 3 December 12
