Epson SC-V7000 Guide d'installation

Epson®SureColor®V7000 Installation and

Training Checklist

Please check off each task when completed.

Installation Tasks

Completed

Pre-installation Site survey has been completed and signed by Epson

representative and End user

Unboxing and set up of the printer will be completed by Epson team

member. (Unboxing and installation will take 4 business days)

Hardware installation consists of:

-Unboxing ofthe main unit

-Leveling the main unit at its permanent location

-Removing all shipping brackets

-Installing the print heads (Separate box:SC-V7000 Print head

Kit)

-Installation ofUVLED Chiller

-Confirm adequate print room ventilation

Once Printer hardware is assembled, a certified electrician will need to

be provided to connect the power from the building to the printer

Ink initialization and filling the chiller with coolant (2 bottles of White

Ink and Varnish are recommended during ink initialization)

The Windows PC provided by the customer will be installed and

prepared for software installation (2 PC’s are recommended for the

installation; one will be used to run UV Controller and the other is to

run your Windows RIP software

Epson team member will install the printer drivers, Epson Edge Print

RIP software and UV Controller on the provided PC’s

To download drivers please visit the SureColor V7000 Support Page.

Follow this checklist to ensure proper installation of the Epson SureColor V7000 printer

Please read the documentation provided with the SureColor printer

After printer initialization, Epson team member will ensure all nozzles

are firing and will provide customer a copy of the nozzle test

Epson team member will conduct all necessary printing alignments

Epson team member will print a test file to ensure the quality test

meets Epson standards and will provide the printed sample and a

reference sample to the customer

Hardware Training Tasks

Completed

Epson team member will conduct the following hardware training/

operation training/safety training

Hardware / Operation Training consists of:

- Understanding safety features

- Proper maintenance of the printer

- How to replace ink (see below for required PPE and safe handling

of ink)

- Media thickness check

- Alignment pin operation

- Media Thickness (Z axis check)

- Turn off/on vacuum zones

- Replace waste ink bottle

- Properly turn off/on the SC-V7000

Maintenance PPE Requirements and Ink Handling Training

Completed

Confirm training on proper use of PPE and ink handling. Under

practiced maintenance conditions, some ink splashes and ink aerosol

conditions can occur, and maintenance technicians should be prepared

with proper PPE:

- Gloves - Ansell Edmont Neoprene 865, Solvex Nitrile Rubber

number 275, or equivalent gloves.

- Face mask - N95 style face mask with charcoal linings to cover

mouth, nose, and lower jaw.

- Eye protection - Sufficient to protect eyes from ink splash and

aerosols. Full coverage goggles or similar.

- Protective clothing - Sufficient to protect skin from ink splash and

aerosols.

Epson Cloud Solution PORT Tasks (Reference: ECSP Guide)

Completed

Navigate to the ECSP website https://port.epson.com/eai and have

customer accept the Terms & Conditions and Privacy Statement

Activate account and record “organization ID”

Install all necessary software

Connect the printer to the Customer’s Epson Cloud Solution PORT

account

Confirm communication to the Epson Cloud Solution PORT

Tour the ECSP Dashboard

Software Training Tasks

Completed

Epson team member will conduct software training.

Ensure complete understanding of UV Controller:

-Media Thickness (Z axis check)

-X,Y start position

-Cleaning functions

-Layered Prints

-Understanding of error logs

-Basic end-user troubleshooting

Epson Edge Print Training (Reference: Epson Edge Print Resource

Guide)

Completed

Install Epson Edge Print using “Main Installer” file

Install V7000 Edge Print Printer installer “EEP_SCV7000_verX.X.X.exe”

Launch Epson Edge Print and authenticate with software license

Connect toSC-V7000 using USB 3.0 orTCPIP connection

Load image to be printed

Set preferred print settings (Basic or Advanced)

Set preferred Color Management settings

RIP and print loaded image

Tour Quick Set & Hot Folder features

Ensure complete understanding of Epson Edge Print:

- Import File

- Choosing the correct media/resolution

- Multi-layer Printing (white and Varnish printing)

- Color replacement

- Mirror images

- Uni-directional printing and bi-directional printing Media

positioning

Additional Support Information

Completed

Provided technical support number: (888) 377-6611

Customer Acceptance Sign-off*

Customer Name (Printed)

Customer Signature

Date

*By signing, customer confirms that the above steps have been completed.

Installer Name (Printed)

Installer Signature

Date

Complete the Customer Installation Form

Dealer and Epson Technician

Completed

Fill out form and submit to https://profocus.epson.com

6/13/2021 Rev. 3
