Epson SC-V7000 Manuel utilisateur

Safety Precautions

Original instructions

Contents

Before Use....................................................................................... 3

oMeaning of Symbols................................................................................................................................................... 3

Handling the Printer Safely............................................................ 4

oRestrictions on Usage................................................................................................................................................. 4

User restrictions .............................................................................................................................................................................. 4

Location Restrictions..................................................................................................................................................................... 4

oNotes on Installation................................................................................................................................................... 5

oNotes on Handling ...................................................................................................................................................... 6

oNotes on the Power Supply...................................................................................................................................... 8

oNotes on Consumables.............................................................................................................................................. 9

oOther Information ....................................................................................................................................................... 9

oResidual Safety Risks.................................................................................................................................................10

oWarning Labels ...........................................................................................................................................................13

Label Meanings .............................................................................................................................................................................13

Label Attachment Positions......................................................................................................................................................14

oSafety Equipment ......................................................................................................................................................16

Emergency Stop Button.............................................................................................................................................................16

Proximity Sensor ...........................................................................................................................................................................16

Jam Detection Sensor .................................................................................................................................................................17

Before Use

To use this printer safely, make sure you read the instruction manuals before use. Using the printer in anyway not

instructed in the instruction manuals may cause a malfunction or accident to occur. Store the instruction manuals

close to the printer so that you can access it at any time.

Meaning of Symbols

This guide and the product use the following symbols to ensure safe use of the printer and to prevent injuries or

damage. The following explains the meaning of the symbols.

Warning labels are also attached to dangerous areas on the printer. See "Warning Labels" on page 13 for more details.

DDANGER Indicates information that, if ignored, could result in mishandling the printer causing

imminent death or serious injury.

DWARNING Indicates information that, if ignored, may result in mishandling the printer causing

death or serious injury.

DCAUTION Indicates information that, if ignored, may result in mishandling the printer causing

injury or property damage.

Indicates actions that must not be performed (prohibited actions).

Indicates items (instructions or actions) that must be performed.

Do not disassemble

Do not touch

No flames

Alternating current

Power on

Stop

Power off

Handling the Printer Safely

This section explains actions that you must perform to ensure that you use the printer safely and to prevent injury to

workers and others and damage to property.

Restrictions on Usage

User restrictions

This printer contains the following dangerous parts. Before using the printer, make sure you attend the appropriate

training to fully understand the dangers involved. (Warning labels are attached to dangerous areas. NSee "Warning

Labels" on page 13)

•Operating at high speed

•High temperature areas

•Irradiates ultraviolet light

Only use the printer when you understand the contents of this guide.

Location Restrictions

Persons who have not received proper training must not enter within the following area around the printer.

Install this printer in a dedicated room, or setup a fence around it, so that no one can accidentally enter the restricted

area.

1. Rear: 150 cm or more 4. Length: 509 cm or more

2. Left and right: 100 cm or more 5. Width: 653 cm or more

3. Front: 150 cm or more

Handling the Printer Safely

Notes on Installation

DDANGER

Do not use the printer near hazardous materials.

The printer is not constructed of explosion proof material. An explosion could occur if the

printer is used in a location containing hazardous material.

Install the printer in a well-ventilated room. When installing the printer in a sealed or poorly

ventilated room, be sure to install a ventilator.

Since ink vapor is heavier than air, vents should be located as close to the floor as possible.

Long-term or repeated exposure to ink can cause organ damage.

Do not use the printer near fires.

Otherwise, a fire may occur if the ink or cleaning liquid ignite.

DWARNING

Do not use flammable sprays or solvents near the printer. Do not place them near the printer.

Otherwise, a fire or electric shock may occur.

Do not place small pieces of metal or containers with liquid such as water on or near the printer.

If metal or liquid enters the printer, a fire or electric shock may occur.

Store ink bottles in a cool, dry place.

Do not install the printer in locations subject to oily smoke and dust, or in locations subject to

humidity or where it could easily get wet.

An electric shock or fire could occur.

Do not block the vents on the printer.

Otherwise, internal parts will overheat and may cause a fire.

To prevent children from causing accidents, do not install the printer in an environment near

children.

Otherwise, injuries could occur.

DCAUTION

Make sure you adjust the horizontal feet (adjusters) to keep the unit flat.

Using the printer while it is unstable may cause an injury or unexpected accident to occur.

Notes on Handling

DDANGER

Do not remove any covers or parts of the printer.

Otherwise, electric shock could occur.

In the following situations, turn off the printer immediately and contact your local dealer or

Epson support. Continuing to use the printer may cause fire or electric shock to occur.

•If you hear an unusual noise

•If you notice an unusual odor

•If smoke is emitted

•If a piece of metal, water, or other liquid has entered the printer

•The power cord is damaged

Do not place flammable items such as paper or cloth near the UV lamp.

Otherwise, a fire or smoke may occur.

Do not touch the UV lamp during printing.

It can become extremely hot and could cause injuries or burns. When performing maintenance,

allow the lamp to cool for at least six minutes before you start.

If UV light from the printer is continuously irradiated onto combustible material for a few

seconds, it could ignite. If any pieces of media remain on the lamp, remove them.

DWARNING

Keep your clothes and body away from moving parts. Also, do not wear bracelets and so on

around the printer.

Otherwise, you could be caught by the moving parts and injured.

Do not look directly at the UV light or allow it to irradiate your skin. Also, make sure you are at

least 1 m away from the UV lamp during printing.

Harmful ultraviolet light (UV) can cause severe burns to the skin and loss of vision.

Wear industrial safety glasses that block UVA, UVB, and blue light.

Wear appropriate clothing that protects the skin from UV light.

Do not place a chair within 5 m of the printer.

The UV light emissions are at their highest at a height of 90 cm (35 inches) from the floor and

increase significantly as you approach the lamp. It is dangerous to sit near this printer while it is

operating.

Handling the Printer Safely

Do not touch parts with high temperature warning labels.

Otherwise, injuries or burns could occur. Wear heat-resistant gloves if you need to touch hot

parts.

Do not touch the gantry or put your hand under the gantry while the printer is operating.

Otherwise, injuries could occur.

Do not touch the cable carrier while the printer is operating.

Otherwise, you could be caught by the printer parts and injured.

Do not disassemble or re-model the printer.

Otherwise, injury, electric shock, or fire could occur.

Do not use the printer if dust has accumulated inside the printer.

Doing so could cause a fire or malfunction to occur. Contact your local dealer or Epson support

to request cleaning for the inside of the printer.

DCAUTION

Do not sit on the media table.

Otherwise, an injury could occur or the level of the table could be lowered.

Clean the printer regularly.

If dust or dirt accumulates on parts of the printer, it could cause a short circuit or insulation to

deteriorate, resulting in a fire or smoke.

Make sure that the warning labels on the printer are not dirty and that the displayed content is

legible.

If the warning labels are illegible, contact your local dealer or Epson support.

Do not touch the operation buttons or switches accidentally.

Doing so could cause the printer to operate causing an injury or unexpected accident to occur.

Make sure you perform daily inspections and replace parts regularly.

Never start the printer if it is damaged.

Otherwise, a malfunction or accident could occur. Check the following every day before starting

operations.

•There is no visible damage to the printer

•There are no ink stains etc. on the media table

•There are no leaks in the ink system or the ink receiver

•All safety devices (emergency stop button, proximity sensor, alarm, signal lamp) are

functioning correctly

DWARNING

Notes on the Power Supply

Do not disassemble or modify the suction pump. Also, do not block the exhaust vents.

Doing so will cause the strength of the suction to decrease resulting in the pump overheating or

malfunctioning.

Do not put your hands into the vents of the suction pump.

The strength of the exhausted air could cause an injury.

When disposing of the printer, entrust it to an industrial waste disposal company, or contact the

Epson support.

DDANGER

When installing, relocating, or disposing of the printer, be sure to use a qualified electrician to

perform any electrical work.

Since the unit generates a high voltage, there is a risk of electric shock.

Do not touch live parts when opening the cover.

Otherwise, electric shock could occur.

DWARNING

Do not use a power supply other than the one displayed on the printer.

Otherwise, a fire or electric shock may occur.

Do not use a frequency other than the frequency displayed on the printer.

Otherwise, a fire or electric shock may occur.

DCAUTION

Check the following points at least once a year.

•The internal wire for the power cord is not exposed or broken

•There are no cracks or dents in the power cord

•No parts of the power cord are hot

•The power cord is not damaged

If there are any issues with the printer, stop using it immediately and contact your local dealer or

Epson support. Otherwise, a fire or electric shock may occur.

DCAUTION

Handling the Printer Safely

Notes on Consumables

Other Information

The UVLED controller on this printer contains hydrofluorocarbons (HFC).

For USA only

The inks for this printer were specifically designed for its use only. Use of these inks in process for which they were

not designed is not recommended. One or more of these inks contain a substance subject to a TSCA section 5 SNUR

codified at 40 C.F.R. 721.5185. Please refer to 40 C.F.R. Part 721 and 40 C.F.R. 721.5185.

DWARNING

If ink is not handled correctly, it can have a detrimental effect on the body. Before using this

printer, be sure to read the Safety Data Sheet (SDS) and follow the instructions. You can

download the safety data sheet from Epson's Website at www.epson.com.

Post the guidelines described in the SDS in your workplace and ensure workers are aware of

them.

Be sure to read the notes on the label of the ink bottles carefully.

Read and follow instructions in the SDS for other chemicals such as cleaning liquid, anti-freeze,

and grease.

Avoid allowing un-cured print media to come into contact with your skin. When ink has not

been cured, handle the print outs with gloves.

DCAUTION

Be careful not to spill the ink.

Do not subject the ink bottles to shocks. Otherwise, ink may leak.

Store ink bottles and cleaning liquid in storage facilities designed for flammable liquids.

Type of F-Gas: R410A

Total F-Gas mass (kg): 0.5

Total eq(CO2-kg): 1045

GWP: 2090

When disposing of the printer, be sure to follow the rules and regulations of your country and region.

Residual Safety Risks

Performing any of the following while using the printer may cause an injury.

Do not put your hands between the gantry

and the carriage

Do not put your hands between the carriage

and media table

If your hands get caught between the gantry and the

carriage, it may cause an injury.

If your hands get caught between the carriage and

the media table, it may cause an injury.

Do not place your hands within the operating

range of the carriage

Keep hands and objects away from the gan-

try and carriage

The carriage could hit your hand, or your hand may

be trapped causing an injury.

The gantry or carriage could hit your hand causing an

injury.

Autres manuels pour SC-V7000

Table des matières

Autres manuels Epson Imprimante

Epson

Epson WF-3520 Series Guide de l'utilisateur

Epson

Epson 11880 - Stylus Pro Color Inkjet Printer Manuel utilisateur

Epson

Epson SC-p400 series Manuel utilisateur

Epson

Epson 1400 - Stylus Photo Color Inkjet Printer Manuel utilisateur

Epson

Epson Stylus Pro 7900 Manuel utilisateur

Epson

Epson CR-420i Dimensions

Epson

Epson 4000 - Stylus Pro Color Inkjet Printer Mode d’emploi

Epson

Epson Stylus NX430 Small-in-One Manuel utilisateur

Epson

Epson SureColor F7070 Manuel utilisateur

Epson

Epson Stylus DX3800 Series Mode d’emploi

Epson

Epson Epson Stylus Photo P50 Series Mode d’emploi

Epson

Epson SureLab D700 Series Mode d’emploi

Epson

Epson SC-p400 series Mode d’emploi

Epson

Epson Stylus Color 800N Manuel utilisateur

Epson

Epson SC-F6300 Series Manuel utilisateur

Epson

Epson EPL-6000 Manuel utilisateur

Epson

Epson Stylus Photo 1410 Series Manuel utilisateur

Epson

Epson Stylus Photo 700 Manuel utilisateur

Epson

Epson Stlyus Photo 1500W Manuel utilisateur

Epson

Epson Stylus Photo - Ink Jet Printer Manuel d'installation et d'exploitation

Epson

Epson TM-C3500 Series Manuel de l'opérateur

Epson

Epson FX-980 - Impact Printer Manuel utilisateur

Epson

Epson Stylus Pro 9900 Manuel utilisateur

Epson

Epson DFX-8500 - Impact Printer Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur
