Wireless 802.11 a/b/g Outdoor AP
EOC5611P
2.4GHz / 5GHz 54Mbps 802.11 a/b/g 24V Po
EOC5611P is a long range outdoor wireless Access Point / Client Bridge that
operates in both 5GHz and 2.4GHz frequency It provides high bandwidth up to
54Mbps and features dual polarization antenna with high transmitted output
power as well as superior sensitivity EOC5611P extends radio coverage, avoids
unnecessary roaming between Access Points and ensures a stable wireless
connection while reduces the number of required equipments
EOC5611P provides user friendly interface including user friendly distance
control ranges from 1KM up to 30KM and RSSI LED indicator offering real time
signal status It comes with PoE injector for convenient outdoor installation
EOC5611P enforces transmission security with full support of latest encryption
mechanism including 64/128-bit WEP, WPA and WPA2 With 14dBi internal
antenna and superior performance, EOC5611P makes an optimal wireless
solution for both small and large scale projects
Package Content
1 x Wireless 802 11a/b/g Outdoor Device(EOC5611P)
1 x PoE Injector (EPE-1212)
1 x Power Adaptor(24V/1A)
1 x CD with User’s Manual
1 x QIG
1 x Metal strap
2 x Special screw set
* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice. 2/2/2012
Features
Wireless
- 5GHz / 2.4GHz It works in 5GHz / 2.4GHz frequency spectrum
- High output power Transmit output power programmable for ifferent country selections
- High Data Rate High spee transmitting rate up to 54Mbps, supports large payloa such as vi eo
streaming
- ultifunction application Access Point/Client Bri ge/Client Router/WDS AP/WDS CB
- Long range transmitting Transmit power control an istance control (ACK timeout)
- Signal Strength Display LED in icators have the best transmit an receive signal for traffic
communication. An RF signal strength status shown LEDs of 3 colors, making network buil -up easier
- Narrow Bandwidth Provi e 5MHz/10MHz/20MHz ban wi th selection.
- ultiple SSID 4 SSID supporte . Each SSID can set itself wireless or WAN access setting.
- QoS(W ) Enhance performance an ensity
Networking
- PPPoE Point-to-Point Protocol over Ethernet at Client Router mo e. This function will keep trying when
faile or isconnecte
- PPTP Point-to-Point Tunneling Protocol (PPTP) is a metho for implementing virtual private networks
- VPN Pass Through
Security
- 802.11i WEP, WPA, WPA2 (Encryption support TKIP/AES)
- AC address functions MAC a ress filter (AP mo e)
- 802.1x IEEE802.1x Authenticator
- Station isolation L2 Isolation
anagement
- Firmware Upgrade Upgra ing firmware via web browser, setting are reserve after upgra e
- Reset & Backup Reset to factory efault. User can export all setting into a file via WEB
- IB MIB I, MIB II(RFC1213), Private MIB
- SN P V1, V2c
* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice. 2/2/2012
Technical Specifications
Hardware Specification
Memory 32MB SDRAM
Flash 8MB
Physical Interface 1 x 10/100 Fast Ethernet RJ-45
1 x Reset Button
1 x Antenna Switch ( Internal and External Switch )
2 x SMA Connector ( One is for 2 4GHz and another is for 5GHz )
LED indicators Power/ Status
LAN (10/100Mbps)
WLAN (Wireless is up)
3 x Link Quality (Client Bridge mode)
• Green: Good Quality
• Yellow: Marginally Acceptable Quality
• Red: Bad Quality
Power Requirements Active Ethernet (Power over Ethernet) Proprietary PoE design
Power Adapter 24V / 1A DC
Regulation Certifications FCC Part 15C/15B/15E, EN301 893, EN 300 328, EN 301 489-1/-17, EN60950,
IC Certification
RF Specification
Frequency Band 802.11a = 5 150~5 350GHz, 5 470~5 725GHz, 5 725~5 825GHz
802.11b/g = 2 412~2 472GHz
Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM
DSSS = DBPSK, DQPSK, CCK
Operating Channels 802.11a =
See the Table1
802.11b/g = 11 for North America, 14 for Japan, 13 for Europe
Receive Sensitivity (Typical)
802.11a
-92dBm @ 6Mbps,
-73dBm @ 54Mbps
802.11g
-92 dBm @ 6Mbps,
-75 dBm @ 54Mbp
802.11b
-97 dBm @ 1Mbps
-91 dBm @ 11Mbps
Available transmit power
(Average power)
(The Max. Power may be
different depending on
local regulations)
FCC ETSI
Frequency Power Frequency Power
5 150~5 350
GHz
I 802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5 150~5 350
GHz
I 802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5 470~5 725
GHz
I 802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
5 470~5 725
GHz
I 802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice. 2/2/2012
20dBm@54Mbps 20dBm@54Mbps
5 725~5 825
GHz
I 802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
5 725~5 825
GHz
I 802.11a
26dBm@6~24Mbps
24dBm@36Mbps
22dBm@48Mbps
20dBm@54Mbps
2 412~2 462
GHz
I 802.11g
26dBm@6~24Mbps
24dBm@36Mbps
23dBm@48Mbps
22dBm@54Mbps
2 412~2 472
GHz
I 802.11g
26dBm@6~24Mbps
24dBm@36Mbps
23dBm@48Mbps
22dBm@54Mbps
2 412~2 462
GHz
I 802.11b
27dBm@1~11Mbps
2 412~2 472
GHz
I 802.11b
27dBm@1~11Mbps
Antenna Specification
Gain 14dBi
Radiation Directional
Frequency Band Range 5.1-5.9GHz
Horizontal -3dB Bandwidth 35
O
Internal Antenna
(Dual Polarization)
Vertical -3dB Bandwidth 15
O
Antenna Pattern
Horizontal Azimuth
Horizontal Elevation
Vertical Azimuth
Vertical Elevation
External Antenna 2 x SMA connector (for 2 4GHz and 5GHz individually)
Software Features
General
Topology Infrastructure
Protocol / Standard IEEE 802 3 (Ethernet)
IEEE 802 3u (Fast Ethernet)
IEEE 802 11a/b/g (5GHz/2 4GHz WLAN)
Operation Mode 802.11 a/b/g
Access Point
Client Bridge
Client Router
WDS AP/CB
* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice. 2/2/2012
LAN DHCP Server
DHCP Client
VPN VPN Pass through
Wireless Channel Selection (Setting varies by countries)
Transmission Rate
11 a/b/g：54, 48, 36, 24, 18, 12, 11, 9, 6, 5 5, 2, 1 Mbps
Long distance transmission : 1km to 30km (Ack timeout)
Auto Channel Selection
Traffic Shaping
Transmit power table
AP Detection
Narrow Bandwidth 5MHz/10MHz/20MHz Support
Signal Strength indication using LEDs
PPPoE & PPtP ( CR mode )
Preferred SSID
MSSID & VLAN Tagging
Security WEP Encryption-64/128/152 bit
WPA/WPA2 Personal (WPA-PSK using TKIP or AES)
WPA/WPA2 Enterprise (WPA-EAP using TKIP)
802 1x Authenticator
L2 Isolation
Hide SSID in beacons
MAC address filtering, up to 50 field
Wireless STA (Client) connected list
QoS WMM
Management
Configuration Web-based configuration (HTTP)
Firmware Upgrade - Upgrade firmware via web-browser
- Keep latest setting when f/w update
Administrator Setting Administrator password change
Reset Setting - Reboot (Press 1 second)
- Reset to Factory Default (Press 5 seconds)
System monitoring Status, Event Log
SNMP V1, V2c
MIB MIB I, MIB II (RFC1213)
Backup & Restore Settings through Web
Time setting NTP (Auto-setting of time)
Time setting manually
nvironment & Mechanical
Temperature Range Operating -20°C~70°C
Storage -30°C to 80°C
* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.
Network conditions and environmental factors lower actual throughput rate.
** All specifications are subject to change without notice. 2/2/2012
Humidity (non-condensing) 0%～95% typical
IP Rating IP55
Dimensions 260mm (L) x 84mm (W) x 55mm (H)
Weight 300g
Table1
(Americas (FCC)):
2 412 to 2 462 GHz; 11 channels
5 180 to 5 320 GHz; 8 channels
5 500 to 5 700 GHz, 8 channels (excludes 5 600 to 5 640 GHz)
5 745 to 5 825 GHz; 5 channels
(China):
2 412 to 2 472 GHz; 13 channels
5 745 to 5 825 GHz; 5 channels
( TSI):
2 412 to 2 472 GHz; 13 channels
5 180 to 5 320 GHz; 8 channels
5 500 to 5 700 GHz, 11 channels
(Israel):
2 412 to 2 472 GHz, 13 channels
5 180 to 5 320 GHz; 8 channels
(Korea):
2 412 to 2 472 GHz; 13 channels
5 180 to 5 320 GHz; 8 channels
5 500 to 5 620 GHz, 7 channels
5 745 to 5 805 GHz, 4 channels
(Japan2):
2 412 to 2 472 GHz; 13 channels
5 180 to 5 320 GHz; 8 channels
(Singapore):
2 412 to 2 472 GHz; 13 channels
5 180 to 5 320 GHz; 8 channels
5 745 to 5 825 GHz; 5 channels
(Taiwan):
2 412 to 2 462 GHz; 11 channels
5 280 to 5 320 GHz; 3 channels
5 500 to 5 700 GHz, 11 channels
5 745 to 5 825 GHz; 5 channels
