* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 4/26/2010

Wireless 802.11 a AP/CB

EOC

5GHz 54Mbps 802.11 a 24V PoE

EOC5510 is a long range outdoor wireless Access Point / Client Bridge that

operates in 5GHz frequency. t provides high bandwidth up to 54Mbps and

features high transmitted output power as well as superior sensitivity.

EOC5510 extends radio coverage, avoids unnecessary roaming between

Access Points and ensures a stable wireless connection while reduces the

number of required equipments.

EOC5510 provides user friendly interface including user friendly distance

control ranges from 1KM up to 30KM and RSS LED indicator offering real

time signal status. t comes with PoE injector for convenient outdoor

installation.

EOC5510 enforces transmission security with full support of latest

encryption mechanism including 64/128-bit WEP, WPA and WPA2. With

13dBi internal antenna and superior performance, EOC5510 makes an

optimal wireless solution for both small and large scale projects.

Packa e Content

1* EOC5510

1* PoE njector (EPE-1212)

1* Power Adaptor(24V/0.6A)

1* CD with User’s Manual

1* Q G

1* Metal strap

2* Special screw set

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 4/26/2010

Features

Wireless

- 5GHz t works in 5GHz frequency spectrum

- High output power Transmit output power programmable for different country selections

- High Data Rate High speed transmitting rate up to 54Mbps, supports large payload such as MEPG video

streaming

- Multifunction application Access Point/Client Bridge/Client Router/WDS AP/WDS Bridge

- Long range transmitting Transmit power control and distance control (ACK timeout)

- ignal trength Display LED indicators have the best transmit and receive signal for traffic

communication. And RF signal strength status shown LEDs of 3 colors, making network build-up easier

- Public wireless solution An AP interface that is especially useful in public areas such as hotspots and

enterprise

- Qo (WMM) Enhance performance and density

Networkin

- PPPoE Point-to-Point Protocol over Ethernet at Client Router mode. This function will keep trying when

failed or disconnected

- VPN Pass Through

Security

- 802.11i WEP, WPA, WPA2 (Encryption support TK P/AES)

- MAC address functions MAC address filter (AP mode)

- 802.1x EEE802.1x Authenticator

- tation isolation

Mana ement

- Firmware Upgrade Upgrading firmware via web browser, setting are reserved after upgrade

- Reset & Backup Reset to factory default. User can export all setting into a file via WEB

- MIB M B , M B (RFC1213)

- NMP V1, V2c

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 4/26/2010

Technical Specifications

Hardware Specification

MCU/RF Atheros AR2313+AR5112

Memory 32MB SDRAM

Flash 8MB

Physical nterface 1 x 10/100 Fast Ethernet RJ-45

1 x Reset Button

1 x Antenna Switch ( nternal and External Switch )

1 x SMA Connector

LED indicators Power/ Status

LAN (10/100Mbps)

WLAN (Wireless is up)

3 x Link Quality (Client Bridge mode)

• Green: Good Quality

• Yellow: Marginally Acceptable Quality

• Red: Bad Quality

Power Requirements Active Ethernet (Power over Ethernet) Proprietary PoE design

Power Adapter 24V / 0.6A DC

Regulation Certifications FCC Part 15E, EN301 893, EN 301 489-1/-17, EN60950, C Certification

RF Specification

Frequency Band 802.11a = 5.150~5.350GHz, 5.470~5.725GHz, 5.725~5.825GHz

Modulation Technology OFDM = BPSK, QPSK, 16-QAM, 64-QAM

Operating Channels 802.11a =

See the Table1

Receive Sensitivity (Typical)

802.11a -92dBm @ 6Mbps, -73dBm @ 54Mbps

Available transmit power

(Average power)

FCC ETS

Frequency Power Frequency Power

5.150~5.350

GHz

IEEE802.11a

23dBm@6~24Mbps

23dBm@36Mbps

22dBm@48Mbps

20dBm@54Mbps

5.150~5.350

GHz

IEEE802.11a

23dBm@6~24Mbps

23dBm@36Mbps

22dBm@48Mbps

20dBm@54Mbps

5.470~5.725

GHz

IEEE802.11a

23dBm@6~24Mbps

23dBm@36Mbps

22dBm@48Mbps

20dBm@54Mbps

5.470~5.725

GHz

IEEE802.11a

23dBm@6~24Mbps

23dBm@36Mbps

22dBm@48Mbps

20dBm@54Mbps

5.725~5.825

GHz

IEEE802.11a

23dBm@6~24Mbps

23dBm@36Mbps

22dBm@48Mbps

20dBm@54Mbps

5.725~5.825

GHz

IEEE802.11a

23dBm@6~24Mbps

23dBm@36Mbps

22dBm@48Mbps

20dBm@54Mbps

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 4/26/2010

Internal Antenna

(Dual Polarization)

Antenna Specification

Gain 10dBi

Radiation Directional

Frequency Band Ran e 5.1-5.8GHz

Horizontal -3dB Bandwidth 40

Vertical -3dB Bandwidth 40

Internal Antenna Pattern

External Antenna 1 x SMA connector

Software Features

General

Topology nfrastructure

Protocol / Standard EEE 802.3 (Ethernet)

EEE 802.3u (Fast Ethernet)

EEE 802.11a(2.4GHz WLAN)

Operation Mode 802.11 a

Access Point

Client Bridge

Client Router

WDS AP/CB

LAN DHCP Server

DHCP Client

VPN VPN Pass through

Wireless Channel Selection (Setting varies by countries)

Transmission Rate

11 a : 54, 48, 36, 24, 18, 12, 11, 9, 6, 5.5, 2, 1 Mbps

Long distance transmission : 1km to 30km

Transmit power table

Antenna Diversity with Dual Polarization

Signal Strength indication using LEDs

PPPoE(CR mode) and PPTP

Narrow Bandwidth 5MHz/10MHz/20MHz Support

P NG function and Trace Route function

MSS D Support

VLAN Support

Preferred SS D

Security WEP Encryption-64/128/152 bit

WPA/WPA2 Personal (WPA-PSK using TK P or AES)

WPA/WPA2 Enterprise (WPA-EAP using TK P)

802.1x Authenticator

* Theoretical wireless signal rate based on IEEE standard of 802.11b, g chipset used. Actual throughput may vary.

Network conditions and environmental factors lower actual throughput rate.

** All specifications are subject to change without notice. 4/26/2010

Hide SS D in beacons

MAC address filtering, up to 50 field

Wireless STA (Client) connected list

QoS WMM

Management

Configuration Web-based configuration (HTTP)

Firmware Upgrade - Upgrade firmware via web-browser

- Keep latest setting when f/w update

Administrator Setting Administrator password change

Reset Setting - Reboot (Press 1 second)

- Reset to Factory Default (Press 5 seconds)

System monitoring Status, Event Log

SNMP V1, V2c

M B M B , M B (RFC1213)

Backup & Restore Settings through Web

Time setting NTP (Auto-setting of time)

Time setting manually

Environment & Mechanical

Temperature Range Operating -20°C~70°C

Storage -30°C to 80°C

Humidity (non-condensing) 0%～95% typical

Dimensions 200mm (L) x 50mm (W) x 45mm (H)

Weight 195g

Table1

(Americas (FCC)):

2.412 to 2.462 GHz; 11 channels

5.180 to 5.320 GHz; 8 channels

5.500 to 5.700 GHz, 8 channels (excludes 5.600 to 5.640 GHz)

5.745 to 5.825 GHz; 5 channels

(China):

2.412 to 2.472 GHz; 13 channels

5.745 to 5.825 GHz; 5 channels

(ETSI):

2.412 to 2.472 GHz; 13 channels

5.180 to 5.320 GHz; 8 channels

5.500 to 5.700 GHz, 11 channels

(Israel):

2.412 to 2.472 GHz, 13 channels

5.180 to 5.320 GHz; 8 channels

(Korea):

2.412 to 2.472 GHz; 13 channels

5.180 to 5.320 GHz; 8 channels

5.500 to 5.620 GHz, 7 channels

5.745 to 5.805 GHz, 4 channels

(Japan2):

2.412 to 2.472 GHz; 13 channels

5.180 to 5.320 GHz; 8 channels

(Sin apore):

2.412 to 2.472 GHz; 13 channels

5.180 to 5.320 GHz; 8 channels

5.745 to 5.825 GHz; 5 channels

(Taiwan):

2.412 to 2.462 GHz; 11 channels

5.280 to 5.320 GHz; 3 channels

5.500 to 5.700 GHz, 11 channels

5.745 to 5.825 GHz; 5 channels
