EnGenius ENS500-AC Manuel utilisateur

Maximum data rates are based on IEEE 802.11 standards. Actual throughput and range may vary

depending on many factors including environmental conditions, distance between devices,

radio interference in the operating environment, and mix of devices in the network. Features

and specications subject to change without notice. Trademarks and registered trademarks

Version1.1

ENS500-AC

ENS610EXT

ENS620EXT

ENS500EXT-AC

A) To

In the address bar of web browser, enter

192.168.1.1 and hit enter.

conﬁgure the AP/Bridge, open a web browser.

B) A login screen will appear. By default, the user-

name of the AP/Bridge is admin and the password

is admin. Enter the current username and

password of the AP/Bridge and then click Login.

Technical Support

Notes

4Switching ModesAP/Bridge Setup

Pole Mounting the Access Point

A) Thread the open end of the Pole Strap through

the two tabs on the Pole Mount Bracket.

B) Lock and tighten Pole Strap to secure Pole

Mount Bracket to the pole.

computer

* It may take up to 90 seconds for device to initially

power up.

Screw on the provided antennas to the top of

devices (External Antennas devices only).

A) Determine where the Access Point to be placed

and mark location on the surface for the two

mounting holes. Use the appropriate drill bit to drill

two 8.1mm diagram and 26mm depth holes in the

markings and hammer the bolts into the openings.

B) Screw the anchors unto the holes until they are

ush with the wall.

C) Screw the included screws into the anchors.

D) Place the Access Point against wall with the

mounting screw heads.

Wall Mounting the Access Point

The device can operate in the following modes:

Access Point, Client Bridge, WDS AP, WDS Bridge,

and WDS Station.

2.4GHz

5GHz

2.4GHz

5GHz

Detachable Antennas

(ENS500EXT-AC: 2x 5GHz Antennas ; ENS610EXT/

ENS620EXT: 2x 2.4GHz Antennas, 2x 5GHz Antennas)

Wireless Network.

Strap x1

)

ENS620EXT

ENS610EXT

ENS500EXT-AC 5GHz

5GHz

A B

Service Center

Country of Purchase Service Information

www.engeniustech.com

Europe

Africa

CIS

Middle East

Russia

www.engenius-me.com

www.engeniustech.com.sg

www.engeniusnetwork.com

North America

www.engeniuscanada.com

Canada

Los Angeles, USA

Netherlands

Dubai, UAE

Asia

Oceania

Singapore

Others Taiwan, R.O.C.

[email protected]

Toll Free: (+1) 888 397 2788

Local: (+1) 905 940 8181

[email protected]

Toll Free: (+1)888 735 7888

Local: (+1)714 432 8668

www.engeniusnetworks.eu

[email protected]

(+31) 40 8200 887

[email protected]

Toll Free:

U.A.E.: 800-EnGenius

800-364-364-87

General:

(+971) 4 357 5599

www.engeniustech.com.sg/

e_warranty_formtechsupport

@engeniustech.com.sg

Toll Free:

Singapore: (+65) 6 227 1088

[email protected]

6709A3203010

2017/05/15
